Vivitar Vivicam 3712xi Users Manual

Downloaded from www.Manualslib.com manuals search engine  21
Installing Software


Software Overview and Features
The Digital Camera includes a mass storage driver that provides fast and easy video and image
download. Also included are Ulead PhotoExpress software. These programs
provide powerful and user-friendly tools to edit, enhance, and organize the digital pictures and videos.

Digital Camera Driver

• Mass storage  function - provides easy and fast downloads

Ulead Photo Express 4.0...

Downloaded from www.Manualslib.com manuals search engine


.

















  Software:
.


















1. Press “Image Editing Software”.
2. Follow the on-screen instructions to comp lete installing of the software. The software installation
will be in the order of the menu above.   3. Select the language you to install from the table






4. On the welcome screen, click “Next” to continue setup.










....

Downloaded from www.Manualslib.com manuals search engine  245. On the license agreem
ent screen, click “Yes” to accept license agreement to continue setup.








6.  Enter your registration information  and serial number and then click  “Next” . The serial number will be
labeled on the CD cover.








7.  Chose the destination location of whe re you’d like to install the software and click “Next”.








8.  Click “Next” on the select program folder screen....

Downloaded from www.Manualslib.com manuals search engine  25
Making Connections


How to Connect to the PC

1.  Make sure the camera’s power is OFF.
2.   Connect the small end of the USB cable to the USB port on the camera.
3.  Connect the larger end of the USB cable to the USB port on the computer.
4.  The camera’s red LED will light to indicate  PC-connection, the computer will detect a
new hardware, and display the following message: “New Hardware Found, COACH
DSC, Mass Storage Driver“....

Downloaded from www.Manualslib.com manuals search engine Downloading Files

to the computer to transfer the files without using a third party application or installing a TWAIN driver.
However, only the newer versions of Windows operating systems (2000/ME/XP) support mass storage
feature. If using a Windows 98SE operating syst em, install the mass storage driver first.

How to Download Files to a PC

For Windows 98SE/2000/ME Users
1. Connect the camera to the computer.  Refer to the “Making...

Downloaded from www.Manualslib.com manuals search engine



How  to Dowload Pictures via Ulead Photo Express 4.0

1. Power ON
  the camera by  sliding the lens cover to the left.

2. Connect the camera to the computer.  Refer to the “Making connections” section on page 25 .









    3

.  Start the Ulead Photo Express 4.0 software as follows: Start à Programme à Ulead Photo








  Express 4.0 SEà Ulead Photo Expr ess 4.0 SE







5.  You will now see that...

Downloaded from www.Manualslib.com manuals search engine  28
Camera Maintenance

Places to Avoid
Do not store or use the camera in the following environments:
-  Very humid, dirty or dusty places
-   In direct sunlight or in places subject to extrem e temperature rises, such as in a closed car in
     summer/winter
-   Extremely cold places
-   Places subject to strong vibrations
-   Places affected by smoke or steam
-   Places subject to strong magnetic fields (such  as places near motors,...

Downloaded from www.Manualslib.com manuals search engine  29
Safety Rules

♦  Do not use the flash close to anyone’s eyes,  especially when taking pictures of a baby.
♦   When a fault arises, power OFF the camera immediately and remove the batteries or disconnect the
USB connection with a PC.
♦   Power OFF the camera and remove the batteries or disconnect the USB connection with a PC when
the camera becomes very warm, emit smoke, emit  unusual odor or in any other abnormal state.
Continuing the...

Downloaded from www.Manualslib.com manuals search engine  30
Product Specifications

Image sensor ½” CMOS sensor with 3.2 million pixels
6M  High Normal    Low  Image resolution
2848x2136* 2048x1536 2048x1536  2048x1536
Image capacity ** 17 17 27 36
Video resolution  320x240 @10 fps
Video capacity  ** 120 seconds (60 sec/clip)
Audio capacity **  17 minutes (60 sec/clip)
File format  JPEG (still) , AVI (video), WAV (audio)
MP3 player  Built-in
Memory  Built-in 16MB flash
Memory expansion...

Downloaded from www.Manualslib.com manuals search engine  31
Troubleshooting

Problem   Possible cause  Solution
The batteries are discharged. Replace the batteries with freshly
charged ones.

The batteries are inserted
incorrectly.
 Check the battery orientation.
The camera has no
power.
Is the camera connected to a
computer?  The camera’s buttons are not
functional when connected to a PC.
Disconnect the camera to take more
pictures.

Is the camera’s power on?  The camera powers off...
