Page 161
Optical aspectratio PowerLite 92/93/95/905/1835 : (width-to-height) 4:3 PowerLite 96W/915W/935W : 16:10 Focus adjustment Manual Zoom adjustment Manual Zoom ratio PowerLite 92/93/95/96W : (Tele-to-Wide) 1:1.2 PowerLite 905/915W/935W/1835 : 1:1.6 Internal soundsystem 16 Wmonaural Noise level PowerLite 92/93/95/96W/905 : 33 dB (Normal PowerConsumption mode) 28 dB (ECO Power Consumption mode) PowerLite 915W/1835 : 37 dB (Normal PowerConsumption mode) 29 dB (ECO Power Consumption...
Page 162
Projector LampSpecifications Type UHE (Ultra HighEfficiency) Power consumption PowerLite 92/93/95/96W/905 : 200 W PowerLite 915W/1835 : 230 W PowerLite 935W: 275 W Lamp life PowerLite 92/93/95/96W/905 : Normal PowerConsumption mode: Up toabout 5000hours ECO Power Consumption mode: Up toabout 6000hours PowerLite 915W/1835 : Normal PowerConsumption mode: Up toabout 4000hours ECO Power Consumption mode: Up toabout 6000hours PowerLite 935W: Normal PowerConsumption mode: Up toabout...
Page 163
Remote ControlSpecifications Reception range 19.7 feet(6m) Batteries Two alkaline ormanganese AA Parent topic:Technical Specifications Projector Dimension Specifications Height 3.66 inches (93mm) (excluding feet) Width 15.6 inches (345mm) Depth 10.4 inches (263mm) Weight PowerLite 92/93: 6.91 lb(3.13 kg) PowerLite 95: 6.97 lb(3.16 kg) PowerLite 96W: 7.19 lb(3.26 kg) PowerLite 905: 7.39 lb(3.35 kg) PowerLite 915W/1835 : 7.42 lb(3.36 kg) PowerLite 935W: 7.50 lb(3.40 kg) Parent...
Page 164
Power supply 100 to240 VAC ±10% PowerLite 92/93/95: 3.2 to1.4 A PowerLite 96W/905: 3.2 to1.5 A PowerLite 915W/1835 : 3.6 to1.6 A PowerLite 935W: 4.1 to1.8 A 164
Page 165
Power consumption Operating: (100 to120 V) PowerLite 92/93/95: Normal PowerConsumption mode:312W ECO Power Consumption mode:261W PowerLite 96W/905: Normal PowerConsumption mode:313W ECO Power Consumption mode:264W PowerLite 915W/1835 : Normal PowerConsumption mode:355W ECO Power Consumption mode:263W PowerLite 935W: Normal PowerConsumption mode:403W ECO Power Consumption mode:329W Standby: PowerLite 92: 0.31 W(Communication Off),N/A(Communication On) PowerLite 93: 0.31...
Page 166
Power consumption Operating: (200 to240 V) PowerLite 92/93/95: Normal PowerConsumption mode:299W ECO Power Consumption mode:254W PowerLite 96W/905: Normal PowerConsumption mode:300W ECO Power Consumption mode:253W PowerLite 915W/1835 : Normal PowerConsumption mode:337W ECO Power Consumption mode:252W PowerLite 935W: Normal PowerConsumption mode:386W ECO Power Consumption mode:313W Standby: PowerLite 92: 0.40 W(Communication Off),N/A(Communication On) PowerLite 93: 0.40...
Page 167
Projector Environmental Specifications Temperature Operating: 41to95 ºF (5 to35 ºC) Storage: 14to140 ºF (– 10 to60 ºC) Humidity Operating: 20to80% (relative, non-condensing) Storage: 10to90% Operating altitude Up to4921 feet(1500 m) Up to7500 feet(2286 m)with High Altitude Modeenabled Parent topic:Technical Specifications Projector SafetyandApprovals Specifications United States FCC Part15Class B(DoC) UL60950-1 Canada ICES-003 ClassB CSA C22.2 No.60950-1 Parent topic:Technical...
Page 168
Display format Refresh rate(inHz) Resolution (inpixels) XGA 60/70/75/85 1024 ×768 WXGA 60 1280 ×768 60 1360 ×768 60/75/85 1280 ×800 SXGA 70/75/85 1152 ×864 60/75/85 1280 ×960 60/75/85 1280 ×1024 SXGA+ 60/75 1400 ×1050 WXGA+ 60/75/85 1440 ×900 UXGA 60 1600 ×1200 WSXGA+* , ** 60 1680 ×1050 WUXGA (Reduced Blanking) 60 1920 ×1200 MAC13 67 640 ×480 MAC16 75 832 ×624 MAC19 75 1024 ×768 59 1024 ×768 MAC21 75 1152 ×870 Composite video TV (NTSC) 60 720 ×480...
Page 169
Display format Refresh rate(inHz) Resolution (inpixels) HDTV (720p) 50/60 1280 ×720 HDTV (1080i) 50/60 1920 ×1080 HDMI inputsignals VGA 60 640 ×480 SVGA 60 800 ×600 XGA 60 1024 ×768 WXGA 60 1280 ×800 SXGA 60 1280 ×960 60 1280 ×1024 SXGA+ 60 1400 ×1050 UXGA 60 1600 ×1200 SDTV (480i/480p) 60 720 ×480 SDTV (576i/576p) 50 720 ×576 HDTV (720p) 50/60 1280 ×720 HDTV (1080i) 50/60 1920 ×1080 HDTV (1080p) 24/30/50/60 1920 ×1080 * PowerLite 96W/915W/935W only **...
Page 170
Notices Check thesesections forimportant noticesaboutyourprojector. Recycling Important SafetyInformation Important SafetyInstructions FCC Compliance Statement Trademarks Software Copyright Copyright Notice Recycling Epson offersarecycling programforend oflife products. Pleasegotowww.epson.com/recycle for information onhow toreturn yourproducts forproper disposal. Parent topic:Notices Important SafetyInformation Caution: Neverlookintotheprojector lenswhen thelamp isturned on;thebright...
