70          Maintaining and Troubleshooting Your E-4200 System
Introduction
If your system does not operate correctly, re-read the instructions for the
procedure(s) you have performed. If an error occurs in an application,
consult the documentation supplied with the software.
This section identif ies solutions to common problems. If the suggestions in
this chapter do not resolve your problem, call Technical Support.
Troubleshooting checklist
Before turning on the system, make sure that:
•The power...

Troubleshooting     71
Troubleshooting guidelines
As you troubleshoot your system, follow these guidelines:
•Never remove the system cover while the system is turned on.
•Do not attempt to open the monitor; it is extremely dangerous.
Even if the monitor’s power is disconnected, stored energy within
the monitor’s components can cause a painful or harmful
experience.
•If a peripheral such as the keyboard, mouse, drive, or printer does
not appear to work, verify that all connections are secure.
•If an...

72          Maintaining and Troubleshooting Your E-4200 System
CD-ROM problems
An audio CD produces no sound.
The CD-ROM drive is not recognized by the system.
Probable CauseSolution
The CD is loaded
incorrectly.Make certain the label is facing upward, and
then try again.
The speakers are not
connected.Check the speaker cables. Make certain
they are connected properly and securely.
The speaker volume is
turned down.Check the volume control.
The speakers may be
muted via the Multime-
dia volume...

Troubleshooting     73
Hard disk problems
The SCSI drive is not recognized by the system.
The secondary IDE
device may be dis-
abled.Restar t your computer, and then press F1 to
enter the setup program. From the Peripheral
Configuration
| Advanced
 menu, set the Sec-
ondary IDE Interface
 to Auto
 and make certain
the Secondary IDE Status
 is Enabled
.
The CD cables are not
installed correctly.Open the system and check all cables
between the CD controller and the CD-ROM
dr ive.
Probable...

74          Maintaining and Troubleshooting Your E-4200 System
The IDE drive is not recognized by the system.
Memory/Processor problems
Memory errors were detected during system start up.
Probable CauseSolution
The primary IDE
device may be config-
ured incorrectly.Restar t your computer, and then press
F1 to
enter the setup program. From the Main

menu, set the Primar y IDE Master
 to Auto Con-
figured
.
The drive may not be
configured properly.Consult the hard disk user’s guide for
instructions...

Troubleshooting     75
A new processor is not recognized by the system.
Modem problems
The modem is not recognized by the system.
Probable CauseSolution
The processor was
installed incorrectly or
in the wrong socket.Check the installation. The processor should
be recognized automatically if it was
installed correctly.
The processor speed
was not selected on
the system board.If your system board enables you to select
the processor speed, make sure you have
selected the speed properly.
A pin was...

76          Maintaining and Troubleshooting Your E-4200 System
Peripheral/Adapter problems
A SCSI device is not recognized by the system.
The diskette drive is not recognized by the system.
Probable CauseSolution
The device needs to
be added as new hard-
ware.From the Control Panel window (Start
|
Settings
| Control Panel
), double-click Add New
Hardware
. Follow the directions for adding
the device. If you are not experienced with
this procedure, call Technical Suppor t.
The SCSI ID may be...

Troubleshooting     77
The diskette drive will not read, write, or format.
The diskette drive LED lights continuously.
An adapter card is not recognized by the system.
Probable CauseSolution
The diskette is not IBM
formatted.Make certain the diskette you are trying to
format is IBM-compatible. If it is, tr y refor-
matting it.
The diskette is cor-
rupted.Run ScanDisk on the diskette. If errors are
detected and corrected, try accessing the
diskette again.
The disk is write pro-
tected.Make certain the...

78          Maintaining and Troubleshooting Your E-4200 System
Printer problems
The printer will not turn on.
The printer is turned on but will not print.
The printer prints garbled text.
Probable CauseSolution
The printer is not
plugged in.Check the power cable. Make certain it is
plugged into a live power source.
The printer is not
turned on.Make certain the printer’s power switch is
On. If power is applied to the printer, the
green power LED should be lit.
The printer is defec-
tive.Try another...

Troubleshooting     79
System problems
The system will not start up.
The keyboard doesn’t work.
Probable CauseSolution
The system is not con-
nected to an AC outlet.Check the power cable(s) and make certain
it is connected to an AC power source.
Voltage selection
switch not set correctly.Make certain the voltage selection switch is
set for the correct power source.
One power supply is
not supplying power to
the load share module.Verify both power cords are plugged into
working AC outlets.
Verify...
