Page 1
Crowded data centers and racks filled to capacity with storage devices, monitors, servers communications devices, and other equipment are driving the need for uninterruptible power with increased power density and power efficiency. The HP 3 Phase Uninterruptible Power Systems provide just that. These rack-mountable Uninterruptible Power Systems provide up to 12,000 watts (W) of power in a 6-U rack form factor. This equates to 2 KW per U space, which leads the industry in power density....
Page 2
Key Features Key FeaturesKey Features Key Features Unity Rated, volt amperage out equals wattage out Highest wattage per U space. Up to 12000 VA/12KW in only 6U! Industry leading efficiency with On-line On Demand hybrid technology Attached line cords for easier and faster connection to your facility power Hot-swappable battery and electronics modules provide ease of maintenance and faster time to repair (MTTR) Industry leading efficiency with On-line On Demand hybrid technology...
Page 3
Superior Battery Superior BatterySuperior Battery Superior Battery Management ManagementManagement Management HP UPS HP 3 PHASE UPS incorporates Enhanced Battery Management: an exclusive, patented technology that doubles battery service life, optimizes battery recharge time, and provides advance notice of pending battery failure. With Enhanced Battery Management, you have a lower total cost of ownership and receive the best in the industry protection for your critical equipment. Ease...
Page 4
Warranty WarrantyWarranty Warranty Standard three year warranty with first year including parts and labor. HP UPSs are backed by a standard three year limited warranty; 3 year parts, 1 year Labor, 1 year onsite. Optional UPS HP Care Pack and packaged services are also available for purchase. You can choose the precise level of support based on your needs, from basic to business critical. Pre-Failure Battery Warning and its associated Warranty. The Pre-Failure Battery Warning is...
Page 5
Extended Runtime Module Extended Runtime ModuleExtended Runtime Module Extended Runtime Module Extended Runtime Module (WW) NOTE: NOTE: NOTE: NOTE: HP 3 PHASE UPS supports a maximum of four Extended Runtime Modules (ERM), to further increase your battery back-up time. Each ERM is 3U high and can be automatically detected and configure when attached to the UPS. For more information on battery back up times, please refer to the Back-up Times Chart. AF434A UPS Management...
Page 6
HP Power Cables HP Power CablesHP Power Cables HP Power Cables 10A, IEC320 C-14 to IEC320 C-13 Cables, 4.5ft (1.37m), 15 pack 142257-007 10A, IEC320 C-14 to IEC320 C-13 Cables, 4.5ft (1.37m), single 15 pack 142257-006 10A, IEC320 C-14 to IEC320 C-13 Cables, 1.6ft (0.5m), single pack 142257-B28 16A, IEC320 C-19 to IEC320 C-20 Cables, 8ft (2.5m), single pack 295633-B22 16A, IEC320 C-19 to IEC320 C-20 Cables, 6.5ft (2m), single pack AF574A 16A,...
Page 7
R8000/3 NA R8000/3 NAR8000/3 NA R8000/3 NA R8000/3 INTL R8000/3 INTLR8000/3 INTL R8000/3 INTL R12000/3 NA R12000/3 NAR12000/3 NA R12000/3 NA R12000/3 INTL R12000/3 INTLR12000/3 INTL R12000/3 INTL Electrical Output Electrical OutputElectrical Output Electrical Output Power Output Power OutputPower Output Power Output 8kVA/8KW @ 208v 3F Delta 8kVA/8KW @ 400v 3F Wye 12kVA/12KW @ 208v 3F Delta 12kVA/12KW @ 400v 3F Wye...
Page 8
Safety Conformance Safety ConformanceSafety Conformance Safety Conformance UL 1778 4th edition; CSA C22.2, No. 107.3 EN and IEC 62040-1-1 UL 1778 4th edition; CSA C22.2, No. 107.3 EN and IEC 62040-1-1 EMC EMCEMC EMC (Class A) FCC Part 15 EN 62040-2 FCC Part EN 62040-2 Unit Dimensions Unit DimensionsUnit Dimensions Unit Dimensions (WxDxH) 14.4 x 26 x 10.3 in (441 x 660 x 261 mm) 6U Shipping Dimensions Shipping DimensionsShipping...
Page 9
© Copyright 2007 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. QuickSpecs HP Rackmountable 3 Phase Uninterruptible...
