3020 ThinkPad Dock top cover
NoteThis section is only for the ThinkPad Dock (FRU no.
08N1546). The top cover and screw kit for ThinkPad
Dock (FRU no. 12P4143) is not available for the
ThinkPad Dock with extension plate (FRU no.
08N1537) .
1
(Rear view)
Step Screw (quantity) Torque

1M2.5×4.8 mm (2) 0.392 Nm
(4 kgfcm)
(continued)
Removing and replacing a FRU
ThinkPad T30127

2
2
2
(Bottom view)
Step Screw (quantity) Torque

2M2.5×4.8 mm (8) 0.392 Nm
(4 kgfcm)
(continued)
Removing and replacing a FRU
128ThinkPad T30 (MT 2366, 2367)

Make sure that the system lock keyAis set to the Unlock
position. Release the front latches in step
3, and then
remove the top cover
4. For step
5, see the inside
view, shown in the circle.
54
3A
Removing and replacing a FRU
ThinkPad T30129

When replacing the top cover, do the following:
vMake sure that the springs are placed correctly.
vMake sure that the device release lever is seated
correctly.
(continued)
Removing and replacing a FRU
130ThinkPad T30 (MT 2366, 2367)

vMake sure that the release button works correctly.
Removing and replacing a FRU
ThinkPad T30131

Locations
Front view

1Bluetooth on-off switch (for some models)

2Bluetooth status indicator (for some models)

3Power status indicators

4Power switch

5Infrared port

6Ultrabay Plus
Note:The Ultrabay Plus accepts several
storage devices, such as a DVD drive, a
CD-RW drive, or a DVD/CD-RW combo
drive, and also accepts an Ultrabay Plus
carrier.

7Ultrabay Plus device eject lever

8Ultrabay Plus latch

9Ultrabay Plus status indicator

10Built-in microphone

11TrackPoint pointing stick...

12
3
4
5
6
7
8
9
10
11
12
13
14
16
15
17
18
Locations
ThinkPad T30133

Rear view

1Security keyhole

2AC power connector

3Video-out connector

4Universal serial bus (USB) connectors

5Ethernet connector

6Modem connector

7External-monitor connector

8Parallel connector

9Serial connector

10Power status indicators

11Bluetooth status indicator (for some models)
23456789
1
10
11
Locations
134ThinkPad T30 (MT 2366, 2367)

Bottom view

1Battery pack

2Shock absorber

3Battery pack latches

4DIMM slots

5Docking connector

6Mini PCI card and communication daughter card
slots

7PC Card slots

8PC Card eject buttons

9Stereo headphone jack

10Stereo line-in jack

11Microphone jack

12Hard-disk drive

13LCD latches

14Built-in stereo speakers
1234
56
7
8
9
10
1113
13
14
12
Locations
ThinkPad T30135

Parts list
T30 series model matrix
The T30 series includes several models. The following
table summarizes the characteristics of each model, to
help you determine which FRU in the part list meets your
need.
Model CDC Mini PCI
adapterLCD Bay
deviceCPU
T30 (memory, 256 MB; video memory, 16 MB; HDD, 20 GB)
2366-21x, 61x
TPMDC—14.1-in.
XGA with
antennaDVD-
ROMN1.6G
2366-23x, 63x
2367-21x, 61x
TP
2367-23x, 63x
2366-D1x, H1x
TPDVD/
CD-RW
2366-E2x, K2x
*1 TPBDC 802.11b/
ModemCD-RW
2366-N6x, R6x MDC—DVD/...
