ELECTRICAL TROUBLESHOOTING MANUAL ETM Y5 Ground Distribution (300Tdi with EDC) 9 DISCOVERY Z132 Engine Control Module (ECM) 3 C245 S268 B Y5-10 0.5 B 0.5 B 0.5 BZ203 Injector Needle Lift Sensor Shield0.5 B 19 2.0 BZ204 Engine Speed Sensor Shield X127 Data Link Connectors 18 C243 3 C197
Page 482
ELECTRICAL TROUBLESHOOTING MANUA L Y5 ETM Ground Distribution (300Tdi with EDC) 10 DISCOVERY 2 C145 Z135 Glow Plug Timer Unit Y5-9 X113 Condenser Fan Coolant Tem- perature SwitchK107 Compressor Clutch 0.5 B 0.5 B 2.0 BB 2 C146 4 C159 300Tdi with EDC B E103 1.0 B
Page 483
ELECTRICAL TROUBLESHOOTING MANUAL ETM Y5 Ground Distribution 11 DISCOVERY E108 Starter M107 Front Wiper Motor E110 E104 Chassis E106 EngineE105 Ignition Coil Braided Strap Braided Strap Braided Strap
Page 484
ELECTRICAL TROUBLESHOOTING MANUA L Y5 ETM Ground Distribution 12 DISCOVERY K191 Ignition Key Lock Solenoid 0.5 B2 C2014 S248 Z111 Radio X229 Key±In Switch 8 C230 X124 Front Wipe/Wash SwitchX124 Front Wipe/Wash Switch 3 C2011 3 C2011 S248 1.5 B 0.5 B 1.5 B 0.5 B 1 C202 1.5 B 1.5 B1.5 B 2 C2028 1 E200 PartialJapanNot used Mid Line Radio With Shift Interlock Without Shift Interlock 1.5 B0.5 B 1.5 B Without Cruise Control With Cruise Control Without Cruise Control 3 C2013 10 C2055 1.0 BS272 5 C268 0.5 B 1.5...
Page 485
ELECTRICAL TROUBLESHOOTING MANUAL ETM Y5 Ground Distribution 13 DISCOVERY Z162 Sunroof Control Unit D C383M143 Front Sunroof Motor M144 Rear Sunroof Motor 0.5 B E200 Partial 3 C388 3 C387 1.5 B S307 S308X263 Rear Sunroof Lockout Switch 1.5 B 3.0 B 3 1 C336 C2028 X261 Front Sunroof Switch 4 C384 X262 Rear Sunroof Switch 4 C385 1.5 B 0.5 B 0.5 B 1 C386 1.5 B
Page 486
ELECTRICAL TROUBLESHOOTING MANUA L Y5 ETM Ground Distribution 14 DISCOVERY 3 C437 Z176 Subwoofer Amplifier 1 C412 C Y5-15 7 C212 Z199 Subwoofer Am- plifier Shield E200 Partial S122 1.5 B 4 C2028 M121 Right Condenser Fan Motor 2 C182 M113 Left Condenser Fan Motor 2 C183 B B
Page 487
ELECTRICAL TROUBLESHOOTING MANUAL ETM Y5 Ground Distribution 15 DISCOVERY 1.5 B8 C230 S272 11 C2055 Z111 Radio C Y5-14 8 C230 Z111 Radio 2 Z111 Radio 8C230 2.0 B 0.5 B1.5 B Except Japan Low Line Radio Mid Line Radio High Line Radio13 C2055 1.5 B 5 C2028 E200 PartialS272 1.5 B Z199 Subwoofer Am- plifier Shield 2.0 B
Page 488
ELECTRICAL TROUBLESHOOTING MANUA L Y5 ETM Ground Distribution 16 DISCOVERY 0.5 B X233 Radio Tune Switch S217 D Y5-174 5 C2056 X234 Radio Waveband Switch 45 C2057 X235 Radio Volume Up Switch 45 C2058 S277 X236 Radio Volume Down Switch 45 C2059 E Y5-17 0.5 B
Page 489
ELECTRICAL TROUBLESHOOTING MANUAL ETM Y5 Ground Distribution 17 DISCOVERY Z117 Clock S216 F Y5-18 X220 Hazard Switch B152 Glove Box Lamp X221 Rear Screen Wipe Switch X115 Cruise Control Switch D Y5-16 X154 Rear Fog Guard Lamps Switch X130 Headlamp Level Switch E Y5-16 2 C270 1 C272 5 C250 5 C26210 C267 5 C263 1 C259 S253 HJ8 S2059 X132 Heated Rear Screen Switch 4 C264 0.5 B 0.5 B0.5 B 0.5 B0.5 B 0.5 B 0.5 B 0.5 B 0.5 B 0.5 B
Page 490
ELECTRICAL TROUBLESHOOTING MANUA L Y5 ETM Ground Distribution 18 DISCOVERY Z151 Air Bag Diagnostic Control Module 4 C252 G Y5-19Y5-17 0.5 B 1 C255 X146 Mirror Adjustment Switch Z143 Instrument Illumi- nation Rheostat X222 Rear Screen Wash Switch Z142 Instrument Cluster 1 C221 10 C222 8 C207 13 C2020 4 C228 3 C214 5 C249 0.5 B 0.5 B0.5 B 0.5 B 1.5 B4 C2060Z111 Radio 0.5 B 0.5 B S207 S255 HJ8 F
