Land Rover Discovery Etm 1995 2nd Edition Rover Manual
Here you can view all the pages of manual Land Rover Discovery Etm 1995 2nd Edition Rover Manual. The Land Rover manuals for Automobile are available online for free. You can easily download all the documents as PDF.
Page 521
![Page 521
\
Component Location Manual View
Left Rear Lamp Assembly
(B121) . . . . . . . . . . . . . . . . . . LH side of luggage compartment . . . . . . . . . . . . . . . . . 86 173. . . . . . . . . .
Left Rear Wheel Speed Sen-
sor (X140) . . . . . . . . . . . . . . . behind LH rear wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 76. . . . . . . . . . . .
Left Rear Window Console...](http://img.usermanuals.tech/thumb/2848/48430/w300_discovery-etm-1995-2nd-edition-rover-520.png "Page 521
\
Component Location Manual View
Left Rear Lamp Assembly
(B121) . . . . . . . . . . . . . . . . . . LH side of luggage compartment . . . . . . . . . . . . . . . . . 86 173. . . . . . . . . .
Left Rear Wheel Speed Sen-
sor (X140) . . . . . . . . . . . . . . . behind LH rear wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 76. . . . . . . . . . . .
Left Rear Window Console...")
\ Component Location Manual View Left Rear Lamp Assembly (B121) . . . . . . . . . . . . . . . . . . LH side of luggage compartment . . . . . . . . . . . . . . . . . 86 173. . . . . . . . . . Left Rear Wheel Speed Sen- sor (X140) . . . . . . . . . . . . . . . behind LH rear wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 76. . . . . . . . . . . . Left Rear Window Console...
Page 522
![Page 522
\
Component Location Manual View
Passengers Rear Sunroof
Switch (X264) . . . . . . . . . . . . centre of roof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76 119. . . . . . . . . . .
Phase Tap Resistor (K184)
300Tdi . . . . . . . . . . . . . . . . . . lower LH side of engine on Generator . . . . . . . . . . . . . 86 16. . . . . . . . . . . .
Phase Tap Resistor...](http://img.usermanuals.tech/thumb/2848/48430/w300_discovery-etm-1995-2nd-edition-rover-521.png "Page 522
\
Component Location Manual View
Passengers Rear Sunroof
Switch (X264) . . . . . . . . . . . . centre of roof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76 119. . . . . . . . . . .
Phase Tap Resistor (K184)
300Tdi . . . . . . . . . . . . . . . . . . lower LH side of engine on Generator . . . . . . . . . . . . . 86 16. . . . . . . . . . . .
Phase Tap Resistor...")
\
Component Location Manual View
Passengers Rear Sunroof
Switch (X264) . . . . . . . . . . . . centre of roof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76 119. . . . . . . . . . .
Phase Tap Resistor (K184)
300Tdi . . . . . . . . . . . . . . . . . . lower LH side of engine on Generator . . . . . . . . . . . . . 86 16. . . . . . . . . . . .
Phase Tap Resistor...
Page 523
![Page 523
\
Component Location Manual View
Rear Blower Motor (M145) . . LH side of luggage compartment on rear A/C evap-
orator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82 169. . . . . . . . . .
Rear Blower Motor Relay
(K193) . . . . . . . . . . . . . . . . . . LH side of luggage compartment on rear A/C evap-
orator . . . . . . . . . . . . . . . . . . . . . . . ....](http://img.usermanuals.tech/thumb/2848/48430/w300_discovery-etm-1995-2nd-edition-rover-522.png "Page 523
\
Component Location Manual View
Rear Blower Motor (M145) . . LH side of luggage compartment on rear A/C evap-
orator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82 169. . . . . . . . . .
Rear Blower Motor Relay
(K193) . . . . . . . . . . . . . . . . . . LH side of luggage compartment on rear A/C evap-
orator . . . . . . . . . . . . . . . . . . . . . . . ....")
\ Component Location Manual View Rear Blower Motor (M145) . . LH side of luggage compartment on rear A/C evap- orator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82 169. . . . . . . . . . Rear Blower Motor Relay (K193) . . . . . . . . . . . . . . . . . . LH side of luggage compartment on rear A/C evap- orator . . . . . . . . . . . . . . . . . . . . . . . ....
Page 524
![Page 524
\
Component Location Manual View
Right Headlamp Level Unit
(Z155) . . . . . . . . . . . . . . . . . . behind RH headlamp . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Right Heated Oxygen Sensor
(X160) . . . . . . . . . . . . . . . . . . lower RH side of engine . . . . . . . . . . . . . . . . . . . . . . . . . 19 66. . . . . . . . . . . .
Right Horn (K134) . . . . . . . . ....](http://img.usermanuals.tech/thumb/2848/48430/w300_discovery-etm-1995-2nd-edition-rover-523.png "Page 524
\
Component Location Manual View
Right Headlamp Level Unit
(Z155) . . . . . . . . . . . . . . . . . . behind RH headlamp . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Right Heated Oxygen Sensor
(X160) . . . . . . . . . . . . . . . . . . lower RH side of engine . . . . . . . . . . . . . . . . . . . . . . . . . 19 66. . . . . . . . . . . .
Right Horn (K134) . . . . . . . . ....")
\
Component Location Manual View
Right Headlamp Level Unit
(Z155) . . . . . . . . . . . . . . . . . . behind RH headlamp . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Right Heated Oxygen Sensor
(X160) . . . . . . . . . . . . . . . . . . lower RH side of engine . . . . . . . . . . . . . . . . . . . . . . . . . 19 66. . . . . . . . . . . .
Right Horn (K134) . . . . . . . . ....
Page 525
![Page 525
\
Component Location Manual View
Starter Solenoid (K136)
MFI ± T16 . . . . . . . . . . . . . . . lower RH side of engine . . . . . . . . . . . . . . . . . . . . . . . . . 86 64. . . . . . . . . . . .
Starter Solenoid (K136)
MFI ± V8 . . . . . . . . . . . . . . . . lower RH side of engine . . . . . . . . . . . . . . . . . . . . . . . . . 86 63. . . . . . . . . . . .
Starter...](http://img.usermanuals.tech/thumb/2848/48430/w300_discovery-etm-1995-2nd-edition-rover-524.png "Page 525
\
Component Location Manual View
Starter Solenoid (K136)
MFI ± T16 . . . . . . . . . . . . . . . lower RH side of engine . . . . . . . . . . . . . . . . . . . . . . . . . 86 64. . . . . . . . . . . .
Starter Solenoid (K136)
MFI ± V8 . . . . . . . . . . . . . . . . lower RH side of engine . . . . . . . . . . . . . . . . . . . . . . . . . 86 63. . . . . . . . . . . .
Starter...")
\ Component Location Manual View Starter Solenoid (K136) MFI ± T16 . . . . . . . . . . . . . . . lower RH side of engine . . . . . . . . . . . . . . . . . . . . . . . . . 86 64. . . . . . . . . . . . Starter Solenoid (K136) MFI ± V8 . . . . . . . . . . . . . . . . lower RH side of engine . . . . . . . . . . . . . . . . . . . . . . . . . 86 63. . . . . . . . . . . . Starter...
Page 526
![Page 526
\
Connector Location View
C100 (3±W) . . . . . . . . . . . . . . . RH front of engine compartment on Engine Compartment Fuse Box 40. . .
C101 (4±W) . . . . . . . . . . . . . . . RH front of engine compartment on Engine Compartment Fuse Box 40. . .
C103 (3±B) . . . . . . . . . . . . . . . . RH front of engine compartment on Right Headlamp 28. . . . . . . . . . . ....](http://img.usermanuals.tech/thumb/2848/48430/w300_discovery-etm-1995-2nd-edition-rover-525.png "Page 526
\
Connector Location View
C100 (3±W) . . . . . . . . . . . . . . . RH front of engine compartment on Engine Compartment Fuse Box 40. . .
C101 (4±W) . . . . . . . . . . . . . . . RH front of engine compartment on Engine Compartment Fuse Box 40. . .
C103 (3±B) . . . . . . . . . . . . . . . . RH front of engine compartment on Right Headlamp 28. . . . . . . . . . . ....")
\
Connector Location View
C100 (3±W) . . . . . . . . . . . . . . . RH front of engine compartment on Engine Compartment Fuse Box 40. . .
C101 (4±W) . . . . . . . . . . . . . . . RH front of engine compartment on Engine Compartment Fuse Box 40. . .
C103 (3±B) . . . . . . . . . . . . . . . . RH front of engine compartment on Right Headlamp 28. . . . . . . . . . . ....
Page 527
![Page 527
\
Connector Location View
C144 (2±RU) MFI ± T16 . . . . . RH rear corner of engine compartment on Evaporative Emission
Canister Purge Valve 68. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
C144 (2±RU) MFI ± V8 . . . . . . RH side of engine compartment on Evaporative Emission Canister
Purge Valve 67. . . . . . . . . . . . . . . . . . . . . . . . . . ....](http://img.usermanuals.tech/thumb/2848/48430/w300_discovery-etm-1995-2nd-edition-rover-526.png "Page 527
\
Connector Location View
C144 (2±RU) MFI ± T16 . . . . . RH rear corner of engine compartment on Evaporative Emission
Canister Purge Valve 68. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
C144 (2±RU) MFI ± V8 . . . . . . RH side of engine compartment on Evaporative Emission Canister
Purge Valve 67. . . . . . . . . . . . . . . . . . . . . . . . . . ....")
\ Connector Location View C144 (2±RU) MFI ± T16 . . . . . RH rear corner of engine compartment on Evaporative Emission Canister Purge Valve 68. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C144 (2±RU) MFI ± V8 . . . . . . RH side of engine compartment on Evaporative Emission Canister Purge Valve 67. . . . . . . . . . . . . . . . . . . . . . . . . . ....
Page 528
![Page 528
\
Connector Location View
C170 (2±R) . . . . . . . . . . . . . . . . LH rear of engine compartment on Front Screen Wash Pump 2. . . . . . . . . .
C171 (3±B) . . . . . . . . . . . . . . . . LH rear of engine compartment on Inertia Fuel Shut±Off Switch 1. . . . . . . .
C173 (2±B) . . . . . . . . . . . . . . . . LH rear of engine compartment on Headlamp Wash Pump 2....](http://img.usermanuals.tech/thumb/2848/48430/w300_discovery-etm-1995-2nd-edition-rover-527.png "Page 528
\
Connector Location View
C170 (2±R) . . . . . . . . . . . . . . . . LH rear of engine compartment on Front Screen Wash Pump 2. . . . . . . . . .
C171 (3±B) . . . . . . . . . . . . . . . . LH rear of engine compartment on Inertia Fuel Shut±Off Switch 1. . . . . . . .
C173 (2±B) . . . . . . . . . . . . . . . . LH rear of engine compartment on Headlamp Wash Pump 2....")
\
Connector Location View
C170 (2±R) . . . . . . . . . . . . . . . . LH rear of engine compartment on Front Screen Wash Pump 2. . . . . . . . . .
C171 (3±B) . . . . . . . . . . . . . . . . LH rear of engine compartment on Inertia Fuel Shut±Off Switch 1. . . . . . . .
C173 (2±B) . . . . . . . . . . . . . . . . LH rear of engine compartment on Headlamp Wash Pump 2....
Page 529
![Page 529
\
Connector Location View
C222 (10±W) . . . . . . . . . . . . . . on Instrument Cluster 139. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
C223 (5±U) . . . . . . . . . . . . . . . . on Instrument Cluster 139. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
C224 (6±W) . . . . . . . . . . . . . . . behind RH...](http://img.usermanuals.tech/thumb/2848/48430/w300_discovery-etm-1995-2nd-edition-rover-528.png "Page 529
\
Connector Location View
C222 (10±W) . . . . . . . . . . . . . . on Instrument Cluster 139. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
C223 (5±U) . . . . . . . . . . . . . . . . on Instrument Cluster 139. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
C224 (6±W) . . . . . . . . . . . . . . . behind RH...")
\ Connector Location View C222 (10±W) . . . . . . . . . . . . . . on Instrument Cluster 139. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C223 (5±U) . . . . . . . . . . . . . . . . on Instrument Cluster 139. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C224 (6±W) . . . . . . . . . . . . . . . behind RH...
Page 530
![Page 530
\
Connector Location View
C274 (6±W) Except Japan . . . behind LH side of fascia on Theft Alarm Unit 93. . . . . . . . . . . . . . . . . . . . . . . .
C274 (6±W) Japan . . . . . . . . . behind LH side of fascia on Central Locking Control Unit 93. . . . . . . . . . . . .
C277 (23±W) . . . . . . . . . . . . . . behind LH side of fascia 91. . . . . . . . . . . . . . . . . . . . . . . . ....](http://img.usermanuals.tech/thumb/2848/48430/w300_discovery-etm-1995-2nd-edition-rover-529.png "Page 530
\
Connector Location View
C274 (6±W) Except Japan . . . behind LH side of fascia on Theft Alarm Unit 93. . . . . . . . . . . . . . . . . . . . . . . .
C274 (6±W) Japan . . . . . . . . . behind LH side of fascia on Central Locking Control Unit 93. . . . . . . . . . . . .
C277 (23±W) . . . . . . . . . . . . . . behind LH side of fascia 91. . . . . . . . . . . . . . . . . . . . . . . . ....")
\
Connector Location View
C274 (6±W) Except Japan . . . behind LH side of fascia on Theft Alarm Unit 93. . . . . . . . . . . . . . . . . . . . . . . .
C274 (6±W) Japan . . . . . . . . . behind LH side of fascia on Central Locking Control Unit 93. . . . . . . . . . . . .
C277 (23±W) . . . . . . . . . . . . . . behind LH side of fascia 91. . . . . . . . . . . . . . . . . . . . . . . . ....
