Page 361
Low Band PCBs / Schematics / Parts Lists4-61C1035 2113740F50 CAP, 91pF C1036 2113743E20 CAP, 0.1uF C1037 2113740F62 CAP, 300pF C1038 2113740F65 CAP, 390pF C1039 2113740F65 CAP, 390pF C1040 2113740F62 CAP, 300pF C1041 2113740F59 CAP, 220pF C1042 2113740F59 CAP, 220pF C1101 2113740F53 CAP, 120pF C1102 2113740F50 CAP, 91pF C1103 2113740F58 CAP, 200pF C1104 2113743E20 CAP, 0.1uF C1105 2113743E20 CAP, 0.1uF C1106 2113743E20 CAP, 0.1uF C1107 2113740F49 CAP, 82pF C1108 2113743E20 CAP, 0.1uF C1109 2113740F40...
Page 362
4-62Low Band PCBs / Schematics / Parts ListsC1466 2113741A45 CAP, .01uF C1467 2113740A53 CAP, 82pF C1468 2113741A45 CAP, .01uF C1469 2113741W01 CAP, 1uF C1470 2113741W01 CAP, 1uF C1471 2113741A45 CAP, .01uF C1472 2113741M69 CAP, 0.1uF C1473 2113741M69 CAP, 0.1uF C1474 2113741A45 CAP, .01uF C1475 2113741W01 CAP, 1uF C1476 2113741A45 CAP, .01uF C1477 2111078B59 CAP, 470pF C1478 2111078B59 CAP, 470pF C1479 2111078B49 CAP, 180pF C1480 Not Placed C1481 2111078B58 CAP, 430pFC1482 2113928E01 CAP, 1uF C1484...
Page 363
Low Band PCBs / Schematics / Parts Lists4-63Q0177 4880048M01 DTC144EKA Q0181 4880048M01 DTC144EKA Q0183 4880048M01 DTC144EKA Q0185 4880048M01 DTC144EKA Q0271 4880214G02 MMBT3904 Q0641 4880048M01 DTC144EKA Q0661 4805921T02 FMC2A Q0662 4880214G02 MMBT3904 Q0663 4880048M01 DTC144EKA Q0681 4880052M01 RXT-A28 Q1001 4880182D44 MMBR951 Q1002 4813824A17 MMBT3906 Q1003 4813824A17 MMBT3906 Q1101 4813827A07 MMBR941 Q1102 4813823A05 MMBFU310L Q1103 4813823A05 MMBFU310L Q1104 4813823A05 MMBFU310L Q1105 4880048M01...
Page 364
4-64Low Band PCBs / Schematics / Parts ListsR 1111 0662057A17 RES, 47 R1113 0662057A64 RES, 4.3K R 111 4 0662057A64 RES, 4.3K R1115 0662057A75 RES, 12K R 111 6 Not Placed R1117 0662057A37 RES, 330R 111 8 0662057A56 RES, 2K R1119 0662057A83 RES, 27K R1120 0662057A18 RES, 51 R1121 0662057A71 RES, 8.2K R1122 0662057A73 RES, 10K R1123 0662057A51 RES, 1.2K R1124 Not Placed R1125 Not PlacedR1126 Not Placed R1127 Not PlacedR1128 0662057A73 RES, 10K R1129 0662057A73 RES, 10K R1130 0662057A73 RES, 10K R1131...
Page 365
Low Band PCBs / Schematics / Parts Lists4-65R1621 0662057A68 RES, 6.2K R1622 0662057A49 RES, 1K R1626 0662057A18 RES, 51 R1627 0662057A73 RES, 10K R1628 0662057A55 RES, 1.8K R1629 0662057A67 RES, 5.6K R1630 0662057A53 RES, 1.5K R1631 0662057A18 RES, 51 R1632 0662057A82 RES, 24K R1633 Not Placed R1635 0662057B47 RES, 0 R1636 0662057A42 RES, 510 R1637 0662057A59 RES, 2.7K R1638 0662057A55 RES, 1.8K SH1201 Not Placed SH1202 Not PlacedSH1301 Not Placed SH1302 2680473U01 VCO SHIELDU0101 5102226J56...
Page 366
4-66Low Band PCBs / Schematics / Parts ListsLow Band Range 2 PCB 8486207B07 Parts List Circuit RefMotorola Part No.DescriptionC0101 2113740F51 CAP, 100pF C0102 Not Placed C0103 Not Placed C0104 Not PlacedC0105 Not Placed C0106 Not PlacedC0107 2113741F25 CAP, 1000pF C0108 Not Placed C0111 Not Placed C0112 2113743E20 CAP, 0.1uFC0121 2113743E20 CAP, 0.1uF C0122 2113743E20 CAP, 0.1uF C0123 Not Placed C0131 2113740F35 CAP, 22pFC0132 2113740F35 CAP, 22pF C0141 2113743E20 CAP, 0.1uF C0151 2113741F49 CAP,...
Page 367
Low Band PCBs / Schematics / Parts Lists4-67C1035 2113740F46 CAP, 62pF C1036 2113743E20 CAP, 0.1uF C1037 2113740F59 CAP, 220pF C1038 2113740F62 CAP, 300pF C1039 2113740F62 CAP, 300pF C1040 2113740F59 CAP, 220pF C1101 2113740F53 CAP, 120pF C1102 2113740F50 CAP, 91pF C1103 2113740F58 CAP, 200pF C1104 2113743E20 CAP, 0.1uF C1105 2113743E20 CAP, 0.1uF C1106 2113743E20 CAP, 0.1uF C1107 2113740F49 CAP, 82pF C1108 2113743E20 CAP, 0.1uF C1109 2113740F40 CAP, 36pF C1110 Not Placed C 1111 2113740L03 CAP, 2.4pF...
Page 368
4-68Low Band PCBs / Schematics / Parts ListsC1466 2113741A45 CAP, .01uF C1467 2113740A46 CAP, 47pF C1468 2113741A45 CAP, .01uF C1469 2113741W01 CAP, 1uF C1470 2113741W01 CAP, 1uF C1471 2113741A45 CAP, .01uF C1472 2113741M69 CAP, 0.1uF C1473 2113741M69 CAP, 0.1uF C1474 2113741A45 CAP, .01uF C1475 2113741W01 CAP, 1uF C1476 2113741A45 CAP, .01uF C1477 2111078B42 CAP, 100pF C1478 2111078B42 CAP, 100pF C1479 2111078B52 CAP, 240pF C1480 2111078B54 CAP, 300pF C1481 2111078B54 CAP, 300pF C1482 2113928E01 CAP,...
Page 369
Low Band PCBs / Schematics / Parts Lists4-69Q0185 4880048M01 DTC144EKA Q0271 4880214G02 MMBT3904 Q0641 4880048M01 DTC144EKA Q0661 4805921T02 FMC2A Q0662 4880214G02 MMBT3904 Q0663 4880048M01 DTC144EKA Q0681 4880052M01 RXT-A28 Q1001 4880182D44 MMBR951 Q1002 4813824A17 MMBT3906 Q1003 4813824A17 MMBT3906 Q1101 4813827A07 MMBR941 Q1102 4813823A05 MMBFU310L Q1103 4813823A05 MMBFU310L Q1104 4813823A05 MMBFU310L Q1105 4880048M01 DTC144EKA Q1106 4813827A07 MMBR941 Q1107 4880214G02 MMBT3904 Q1201 4813824A17...
Page 370
4-70Low Band PCBs / Schematics / Parts ListsR 111 5 0662057A75 RES, 12K R1116 Not Placed R 111 7 0662057A37 RES, 330 R1118 0662057A56 RES, 2K R 111 9 0662057A83 RES, 27K R1120 0662057A18 RES, 51 R1121 0662057A71 RES, 8.2K R1122 0662057A73 RES, 10K R1123 0662057A51 RES, 1.2K R1124 Not Placed R1125 Not Placed R1126 Not PlacedR1127 Not Placed R1128 0662057A73 RES, 10KR1129 0662057A73 RES, 10K R1130 0662057A73 RES, 10K R1131 0662057A77 RES, 15K R1132 0662057A58 RES, 2.4K R1133 0662057A61 RES, 3.3K R1134...
