NEC Neax2000 Ivs Isdn System Manual

ND-45857 (E) CHAPTER 4
Addendum-001 Page 126-1
AUGUST, 1998 Revision 3.1
SYSTEM DATA PROGRAMMING
3.7.2 Virtual Trunk Data Assignment
• Home-Side Trunk Data Assignment
DESCRIPTION DATA
Assign a trunk number to each channel  on the
Home-Side Trunk.
Note:The Virtual Channel number on the
Home-Side Trunk must be an even number
(00, 02, 04, ... 30).
• YY=05
(1)
(2)32XX: Virtual Channel No. 00-30 (Even
No.) of the Home-Side Trunk
Trunk No. (D000-D255)
Assign a trunk route number to each trunk. • YY=00
(1)...

CHAPTER 4 ND-45857 (E)
Page 126-2 Addendum-001
Revision 3.1 AUGUST, 1998
SYSTEM DATA PROGRAMMING
This page is for your notes.
DESCRIPTION DATA
• YY=05
(1)
(2)
•
(1)
(2)Trunk Route No. (00-63)
1  : Release Signal arrives
YY=09
Trunk Route No. (00-63)
06:  2nd DT/Timing Start
Specify the PAD patterns on Event Based CCIS
connection to the voice channel route.• YY=19
(1)
(2)Trunk Route No. (00-63)
PAD Pattern No. (0-7)
See CM35 in the Command Manual
Specify trunk seizure sequence. • YY=83
(1)
(2)Trunk Route...

ND-45857 (E) CHAPTER 4
Addendum-001 Page 126-3
AUGUST, 1998 Revision 3.1
SYSTEM DATA PROGRAMMING
• Mate-Side Trunk Data Assignment
DESCRIPTION DATA
Assign a trunk number to each channel  on the
Mate-Side trunk.
Note:The Virtual Channel number on the Mate-
Side Trunk must be an odd number (01,
03, 05, ... 31).
• YY=05
(1)
(2)32XX: Virtual Channel No. 00-30 (Even
No.) of the Home-Side Trunk
Trunk No. (D000-D255)
Assign a trunk route number to each trunk. • YY=00
(1)
(2)Trunk No. (000-255)
Trunk Route No....

CHAPTER 4 ND-45857 (E)
Page 126-4 Addendum-001
Revision 3.1 AUGUST, 1998
SYSTEM DATA PROGRAMMING
This page is for your notes.
DESCRIPTION DATA
Specify whether the virtual tie line is released
when there are no calls for predetermined time.
If the second data is set to “1”, the virtual tie
line keeps connecting even if all calls finished.
Specify the voice channel and common signal-
ing channel route as the Event Based CCIS
route.• YYY=127
(1)
(2)
•
(1)
(2)Trunk Route No. (00-63)
0: Released
1 : Not...

ND-45857 (E) CHAPTER 4
Addendum-001 Page 126-5
AUGUST, 1998 Revision 3.1
SYSTEM DATA PROGRAMMING
3.7.3 Access Code/Terminating Number Assignment
DESCRIPTION DATA
Assign the memory allocation to store the termi-
nating number of the opposite office on Event
Based CCIS connection.(1)
(2)66
XXX
XXX
*a *b
*a: First Memory Slot No. (000-299)
*b: Number of Memory Slot allocated
(001-032)
Set the stored number (terminating number of
the opposite office: access code for ISDN line +
ISDN subscriber number) to...

CHAPTER 4 ND-45857 (E)
Page 126-6 Addendum-001
Revision 3.1 AUGUST, 1998
SYSTEM DATA PROGRAMMING
This page is for your notes.3.7.4 Channel Release Timer Assignment
DESCRIPTION DATA
Specify the timer data to release the voice chan-
nels of virtual tie line. If there are no calls for
predetermined time, the voice channels used for
Event Based CCIS is released. •Y=0
(1)
(2)87: Virtual Tie Line Release Timer
(For Voice channels)
02: 2.4-4.8 sec. (2.4 sec. increments)
30: 69.6-72.0 sec.
32: 24 sec. (24 sec....

ND-45857 (E) CHAPTER 4
Addendum-001 Page 126-7
AUGUST, 1998 Revision 3.1
SYSTEM DATA PROGRAMMING
3.7.5 CCH Data Assignment
DESCRIPTION DATA
Assign a slot number to the CCH card. The slot
number must correspond to the SENSE switch
setting on the card.(1) Slot No. (04-15)
(2) 11:  CCH Card
Assign a CCIS channel number to each CCH
card.
Provide the system with No. 7 CCIS facilities.• YY=07
(1) CCIS Channel No. (0-3)
(2) Slot No. of CCH Card (04-15)
(1)
(2)53:  No. 7 CCIS
0:    Provided
Assign the trunk...

CHAPTER 4  ND -4 5857 ( E)
S YST EM  DATA P RO G RA MMING
CM A7
A
END
CM A8

ND-45857 (E) CHAPTER 4
Addendum-001 Page 126-9
AUGUST, 1998 Revision 3.1
SYSTEM DATA PROGRAMMING
3.7.6 E-CCIS Tandem Connection Assignment
• When providing Tandem Connection (ISDN to CCIS/CCIS to ISDN), do the following programming.
START
DESCRIPTION DATA
Specify the combination of Trunk Routes allow-
ing the tandem connection.
Note:The Home-Side Virtual Tie line routes must
be included for all Tandem combinations.
(1) XX XX
00-63 (Incoming Trunk Route)
00-63 (Outgoing Trunk Route)
(2) 0/1 :...

CHAPTER 4 ND-45857 (E)
Page 126-10 Addendum-001
Revision 3.1 AUGUST, 1998
SYSTEM DATA PROGRAMMING
This page is for your notes.
