E – 14 3-1-6-3. Remove the PC card from the slave projector. NOTE: If you select the RGB1 input on the master projector, you must select the same input on the slave projector and the RGB2 on the master projector and the slave projector. NOTE: After adjusting and registering signals as mentioned above, you must change the input to RGB on the Entry Edit Command window for Link Mode. See Entry List Edit on page E-29 for changing to RGB source. 3-1-6-4. Display the desired source. 4) Display the internal...
Page 22
E – 15 Projector Orientation An image can be projected from in front or behind a screen, and the projector can be installed on the ceiling*. Ceiling Front Projection Use [Projector Options] →[Setup] →[Page 1] →[Orientation] to select Ceiling Front. (See page E-36.) Ceiling Rear Projection Use [Projector Options] →[Setup] →[Page 1] →[Orientation] to select Ceiling Rear. (See page E-36.) Desktop Rear Projection Use [Projector Options] →[Setup] →[Page 1] →[Orientation] to select Desktop Rear. (See page...
Page 23
E – 16 When used in standalone operation Connecting Your PC Or Macintosh Computer Connecting your PC or Macintosh computer to XT5100/XT4100 Pro- jector will enable you to project your computers screen image for an impressive presentation. To connect to a PC or Macintosh : 1. Turn off the power to your projector and computer. 2. Use a signal cable (not provided) to connect your PC or Macintosh computer to the projector. 3. Turn on the projector and the computer. 4. If the projector goes blank after a...
Page 24
E – 17 When Used with One Switcher (ISS-6020/ISS-6020G) Up to 10 input signals can be accepted when the projector is connected to one Switcher. Using the projector with the Switcher allows easy adjustment and signal selection. •Select [Advanced Menu] → [Projector Options] → [Switcher Control] → [SW1 Level]. See page E-37 for the information in detail. •For more information on the Switcher, refer to the users manual accompanying the ISS-6020/ISS-6020G Switcher. •All cables mentioned above are sold...
Page 25
E – 18 When Used with Two or More Switchers (100 Inputs) Up to 100 inputs can be accepted using the NEC ISS-6020 Switcher. How to make connections: 1. Connect the REMOTE 1 terminal of the master Switcher to the RE- MOTE 1 of the projector using the optional control cable (15p-15p/ CTL-6010). 2. Next connect the REMOTE 2 terminal of the master Switcher to the REMOTE 1 terminal of the first slave Switcher using the same op- tional control cable as mentioned above. Third, connect the REMOTE 2 terminal of...
Page 26
E – 19 Set the DIP switch (S8601) of the Switcher as follows: The Projector Slot 1 of the Master Slot 2 of the Master Slot 3 of the Master Slot 4 of the Master Slot 5 of the Master Slot 6 of the Master Slot 7 of the Master Slot 8 of the Master Slot 9 of the Master Slot 10 of the MasterMaster Slave 1 Slave 2 Slave 3 Slave 4 Slave 5 Slave 6 Slave 7 Slave 8 Slave 9 Slave 10 ISS-6020 ISS-6020GOutput toSetting of S8601 NOTE: Slave numbers 1 to 10 must correspond to the master’s slot numbers 1 to 10. OPEN...
Page 27
E – 20 REMOTE 1 Connector Pin Configuration of Optional CTL-6010 Cable REMOTE 1 connector of the Switcher mini D- sub 15 pin (female) REMOTE 1 connector of the Projector mini D-sub 15 pin (female) Shield (frame ground) Pins without a number are open. 51423 10 11 12 13 14 156 978 This connector is used for either connecting the ISS-6020/ISS-6020G Switcher or a third par ty external control device (Contact Closure). When the Switcher is used, connect it with the optional control cable (15-15 pin; 50...
Page 28
E – 21 When used in stand alone operation. Pin No. 14 5 10 4,8,12,11SHORT/OPEN SHORT OPEN SHORT OPEN SHORT OPENFUNCTION External control mode ON External control mode OFF POWER ON POWER OFF PICTURE MUTE ON PICTURE MUTE OFF * When the combinations other than specified in the above table are selected, the input will be forcefully switched to RGB 1. * The term “SHORT” means to connect with pin 15 * When in the external control mode, the POWER, INPUT, PICTURE MUTE and SOUND MUTE buttons on the remote control...
Page 29
E – 22 REMOTE2 INPUT7S-VIDEO1 Y C IN OUT Operating Multiple Projectors with Remote Control You can operate multiple projectors with the same remote control in wireless operation. To do so: 1. Select [Menu] → [Projector Options] → [Setup] → [Page 5] → [Projector ID] and assign an ID number to each projector. See also page E-39. 2. On the remote control specify the ID number of the projector to be adjusted. Press and hold the CTL and press MENU (ADDRESS) button to enter the ID number. You can operate the...
Page 30
E – 23 Using the RGB DIGITAL connectors (XT5100 only) The Link mode function allows you to adjust or set multiple projectors using the RGB DIGITAL and OPTION connectors. The DVI DIGITAL input accepts up to the XGA (1024 x 768 @85Hz) signal. NOTE: The Auto Adjust feature does not work for DVI digital signal. When DVI signal is selected and the image position is not corrected, adjust the horizontal andvertical position using the Position screen. See page E-31 for more details. Connection for Triple...
