11
Getting Started
( page 21) (
  “Battery Power”) Use only a monaural condenser microphone (miniature jack).  Using an
input source other than a monaural condenser microphone may not allow
audio to be input or may damage the equipment.
Microphone Jack
Use this jack to connect  headphones or ampli-
fier-equipped speakers.  Audio output from the
internal speaker is disabled when headphones
or external speakers are connected.
(  “USB Devices (External Mouse etc.)”) (
  “External Display”)
USB Ports
DC-IN...

12
Getting Started
First-time Operation
Read the steps below to help you learn what parts are included, and to gain an understanding of
some basic computer-related operations.
1Confirm the inclusion of all parts.
Make sure the parts shown in the figure have been supplied.  If any of these items are
missing or is not working properly, contact your technical support office (
 page 50).
Model No : CF-AA1623A
AC adaptor.......... 1
Model No : CF-VZSU27A
AC Cord............... 1Battery Pack ........ 1
Product...

13
Getting Started
Connect your computer to a power outlet.
CAUTION
Be sure the AC adaptor is connected until completing the first-time use opera-
tion.
When using the computer for the first time, do not connect any peripheral de-
vice except the battery pack and AC adaptor to the computer.
Handling the AC adaptor
Do not twist or pull the AC power cord forcefully.  Doing so may damage the
connections.
Use only the specified AC adaptor with your computer.  Using an AC adaptor
other than the one supplied...

14
Getting Started
6Enter the correct date, time and the time zone, then select [Next].
The computer will restart.
CAUTION
Remember this password!  If the password is forgotten, Windows cannot be
operated.
7Enter your administrator password and select .
5Enter your computer name and administrator password and then select [Next].
NOTE
It may take some time before the computer restarts and the screen of step  7
is displayed. Wait, and do not press any keys, or touch the touch pad, etc.
If the keyboard or...

15
Getting Started
Depending on the Windows settings, installed applications, and drivers, menus and
other displays may differ, or some functions (such as use of the password reset disk)
may be inoperable.  Check with your system administrator for details.
You can select Classic view for the Control Panel or select the Classic Start menu.
You can also change the way a user logs on or off.
The procedure in this manual uses the method or view of the Windows XP default
setting (not Classic view nor Classic...

16
Operation
1Open the display.
Starting Up/Shutting Down
Starting Up
1Press and hold the latch (A) located at the front.
2Lift open the display.
CAUTION
Do not open the display wider than necessary (170° or more).
Do not apply excessive pressure to the LCD.  Also, do not hold the LCD when
opening or closing the display.
2Turn your computer on.
Slide the power switch  and hold it for approximately one second until the power
indicator
 turns on before releasing it.
CAUTION
  Do not slide the power switch...

17
Operation
The power saving function is factory set, so if there is no input from a key, the touch
pad or an external mouse (when one is connected) for a certain interval of time, the
power to the LCD and hard disk may be turned off.  The LCD will resume operation
when the touch pad or an external mouse (when one is connected) is used or a key is
pressed.
The power to the LCD may be turned off even when an application software is being
installed.  In this case, because it is conceivable that a...

18
Operation
Shutting Down (power off your computer)
1Save important data and close each application.
2Select [start] - [Turn Off Computer].
3Select [Turn Off].
Your computer will power off automatically.
Restarting your computer (without shutting down):
Select [Restart].
To shut down using the keyboard:
Press
   ,U   , and select [Turn Off] with                    , then press
 Enter   .
CAUTION
Do not do the following during the shutdown/restart procedure.
• Connecting or disconnecting the AC adaptor....

19
Operation
Touch Pad
Use the touch pad to move the cursor on the screen and perform computer operations.
or Function Operation
Moving the Cursor
Tapping/Clicking
Double-Tapping/
Double-Clicking
Dragging
Vertical Scroll
Horizontal Scroll
Move the tip of your finger
lightly over the work surface.
tappingclicking
A. Work Surface (Touch Pad)
B. Left Button
C. Right Button
Refer to [Mouse Properties] for information on basic operations other than the above.
To display [Mouse Properties], select [start] -...

20
Operation
Reference Manual
The Reference Manual and the Important Tips can be accessed on your computer. When a
printer is connected, these manuals can also be printed.
Illustrations may be difficult to view depending on the magnification.  If the illustra-
tion is too small, magnify the display.
If a printer is connected, we recommend printing the pages required.  The illustrations
and display samples may not be printed with a high quality.
NOTE
Reference Manual
The Reference Manual explains...
