Panasonic Cf Y2 Owners Manual

41
Appendix
A. MEI vous octroie par les présentes le droit et la licence personnels, non cessibles et non exclusifs dutiliser les
Logiciels conformément aux termes, clauses et conditions de ce Contrat. Vous reconnaissez ne recevoir quun
droit limité dutiliser les Logiciels et la documentation les accompagnant et vous vous engagez à nobtenir aucun
droit de titre, propriété ni aucun autre droit vis-à-vis des Logiciels et de la documentation les accompagnant ni vis-
à-vis des algorithmes, concepts, dessins,...

42
Appendix
Hard Disk Backup Function
The hard disk backup function creates a backup area (storage area) on the hard disk. This area is to back up (store) hard disk
contents or restore backed up contents to their original locations.
By backing up the data on your hard disk to a backup area, you can protect your data from loss or damage resulting from operational
errors or other factors.  Also, you can back up or restore hard disk contents using this computer alone, without having to use other
media or...

43
Appendix
1Turn the computer on, and press   F2   while [Panasonic] boot screen is displayed.
The Setup Utility will start up.
If a password has been set, enter the Supervisor Password.
You cannot register [Boot] menu with a User Password.
2Select [Boot] menu, then select [CD/DVD Drive] and press   F6    until [CD/DVD Drive] is at
the top of [Boot] menu.
3Place the Product Recovery DVD-ROM into the DVD-ROM & CD-R/RW drive.
When disk cover does not open:
[CD/DVD Drive Power] has been set to [Off] in the...

44
Appendix
Hard Disk Backup Function

Select [2], enter the partition size (GB), and press   Enter   .
• You can cancel this operation by pressing    0   .
• The data partition size will be the maximum settable size less the number entered above.
The maximum settable size will differ depending on models.
8At the confirmation message, press    Y   .
The backup area is then created.
9When the message [You must reboot in order to enable the Backup function.] appears, remove
the Product Recovery DVD-ROM,...

45
Appendix
To disable the hard disk backup function
Perform the reinstallation procedure. All data in the backup area and the hard disk will be erased.
Conduct steps
1-7 for [Reinstalling Software]  ( page 38). Select [1] or [2] to execute the
reinstallation at the screen for executing the reinstallation.
• When [1] is selected, the hard disk backup function can be disabled.
• When [2] is selected, the hard disk backup function can be disabled, but in this case, because
the hard disk has been divided...

46
Appendix

If you select [3] in step
8 ( page 38) and execute reinstallation, the drive name for the second
partition (data partition) may be switched with that of the SD Memory Card.  You can still use the
drives after the names have been switched, but you can also return the drive names to their original
state using the following procedures.
(The following procedure assumes that before reinstallation, the second partition (data partition)
was Drive D:, and the SD Memory Card was Drive E:)
1Disable...

47
Appendix
Hard Disk Data Erase Utility
This computer is equipped with a utility for erasing hard disk data.
When disposing of or transferring ownership of this device, erase all data on the hard disk in order to prevent the theft of hard disk
data following the steps below.
The hard disk data erase utility erases data using an overwriting method, but there is a possibility that due to malfunctions or
other operational errors, data may not be completely erased. There are also specialized devices that...

48
Appendix
Specifications
Model No.
CPU/Cache
Memory
Video Memory
Hard Disk Drive
LCD Type
Displayed Colors*5
External Display
DVD-ROM & CD-R/RW Drive
Supports DVD
CD
DVD-ROM read*9
CD-ROM read*9
CD-R write*10
CD-RW write
High-Speed CD-RW write
Ultra Speed CD-RW write*11
Slots PC Card Slot
Allowable current
RAM Module Slot*13
SD Memory Card Slot
Interface External Display Port
Microphone Jack
Headphone Jack
USB Ports
Modem
LAN
Wireless LAN
Keyboard/Pointing Device
Sound
*
11 MB = 1,048,576 bytes
*2There...

49
Appendix
Main Specifications
Battery Pack
Operating Time*1
Charging Time*4
Clock Battery
AC Adaptor*5Input
Output
Power Consumption*6
EnvironmentOperationTemperature
Humidity
Storage Temperature
Humidity
Physical Dimensions (W × H × D)
Weight
Operating System
Utility ProgramsLi-ion 7.4 V, 7.05 Ah
Approx. 4 hours - 7hours*2 (Approx. 5 hours*3)
Approx. 5.5 hours
Coin type lithium battery 3.0 V
100 V - 240 V AC, 50 Hz/60 Hz
16 V DC, 2.5 A
Approx. 40 W (Maximum when recharging in the ON state)
5 °C to...

50
Appendix
PANASONIC PERSONAL COMPUTER AND PERIPHERALS LIMITED WARRANTY
Panasonic Computer Solutions Company (referred to as “Panasonic”) will repair this product (other than software, which is covered by a separate
warranty) with new or rebuilt parts, free of charge in the U.S.A. for three (3) years from the date of original purchase in the event of a defect in
materials or workmanship. This warranty includes the AC adaptor but excludes the batteries and all other options and accessories which are...
