Page 131
![Page 131
- 131 -
Connecting to other equipment
1Press 3.
2Press 3/4 to select an item and then press [MENU/SET].
3Press 3 to select [Print start] and then press [MENU/SET].
•If the print check screen has appeared, select [Yes], and print the pictures.•Refer to P132 for the items which can be set before starting to print the pictures.
•Disconnect the USB connecti on cable after printing.
Selecting a single picture and printing it
1Press 2/1 to select the picture and then press [MENU/
SET].
2Press 3 to select...](http://img.usermanuals.tech/thumb/58/66166/w300_dmc-sz8_en_adv_om_d-130.png "Page 131
- 131 -
Connecting to other equipment
1Press 3.
2Press 3/4 to select an item and then press [MENU/SET].
3Press 3 to select [Print start] and then press [MENU/SET].
•If the print check screen has appeared, select [Yes], and print the pictures.•Refer to P132 for the items which can be set before starting to print the pictures.
•Disconnect the USB connecti on cable after printing.
Selecting a single picture and printing it
1Press 2/1 to select the picture and then press [MENU/
SET].
2Press 3 to select...")
- 131 - Connecting to other equipment 1Press 3. 2Press 3/4 to select an item and then press [MENU/SET]. 3Press 3 to select [Print start] and then press [MENU/SET]. •If the print check screen has appeared, select [Yes], and print the pictures.•Refer to P132 for the items which can be set before starting to print the pictures. •Disconnect the USB connecti on cable after printing. Selecting a single picture and printing it 1Press 2/1 to select the picture and then press [MENU/ SET]. 2Press 3 to select...
Page 132
![Page 132
- 132 -
Connecting to other equipment
Select and set the items both on the screen in step 2 of the “Selecting a single picture
and printing it” and in step
3 of the “Selecting multiple pictures and printing them”
procedures.
•
When you want to print pictures in a paper size or a layout which is not supported by the camera, set
[Paper Size] or [Page Layout] to [ {] and then set the paper size or the layout on the printer.
(For details, refer to the operating instructions of the printer.)
•If the...](http://img.usermanuals.tech/thumb/58/66166/w300_dmc-sz8_en_adv_om_d-131.png "Page 132
- 132 -
Connecting to other equipment
Select and set the items both on the screen in step 2 of the “Selecting a single picture
and printing it” and in step
3 of the “Selecting multiple pictures and printing them”
procedures.
•
When you want to print pictures in a paper size or a layout which is not supported by the camera, set
[Paper Size] or [Page Layout] to [ {] and then set the paper size or the layout on the printer.
(For details, refer to the operating instructions of the printer.)
•If the...")
- 132 -
Connecting to other equipment
Select and set the items both on the screen in step 2 of the “Selecting a single picture
and printing it” and in step
3 of the “Selecting multiple pictures and printing them”
procedures.
•
When you want to print pictures in a paper size or a layout which is not supported by the camera, set
[Paper Size] or [Page Layout] to [ {] and then set the paper size or the layout on the printer.
(For details, refer to the operating instructions of the printer.)
•If the...
Page 133
![Page 133
- 133 -
Connecting to other equipment
•Paper sizes not supported by the printer will not be displayed.
[Paper Size]
{Settings on the printer are prioritized.
[L/3.5 qk5q]
89 mmk127 mm
[2L/5 qk7q] 127 mmk178 mm
[POSTCARD] 100 mmk148 mm
[16:9] 101.6 mmk180.6 mm
[A4] 210 mmk297 mm
[A3] 297 mmk420 mm
[10 k15cm] 100 mmk150 mm
[4 qk6 q] 101.6 mmk152.4 mm
[8 qk10q ] 203.2 mmk254 mm
[LETTER] 216 mmk279.4 mm
[CARD SIZE] 54 mmk85.6 mm](http://img.usermanuals.tech/thumb/58/66166/w300_dmc-sz8_en_adv_om_d-132.png "Page 133
- 133 -
Connecting to other equipment
•Paper sizes not supported by the printer will not be displayed.
[Paper Size]
{Settings on the printer are prioritized.
[L/3.5 qk5q]
89 mmk127 mm
[2L/5 qk7q] 127 mmk178 mm
[POSTCARD] 100 mmk148 mm
[16:9] 101.6 mmk180.6 mm
[A4] 210 mmk297 mm
[A3] 297 mmk420 mm
[10 k15cm] 100 mmk150 mm
[4 qk6 q] 101.6 mmk152.4 mm
[8 qk10q ] 203.2 mmk254 mm
[LETTER] 216 mmk279.4 mm
[CARD SIZE] 54 mmk85.6 mm")
- 133 -
Connecting to other equipment
•Paper sizes not supported by the printer will not be displayed.
[Paper Size]
{Settings on the printer are prioritized.
[L/3.5 qk5q]
89 mmk127 mm
[2L/5 qk7q] 127 mmk178 mm
[POSTCARD] 100 mmk148 mm
[16:9] 101.6 mmk180.6 mm
[A4] 210 mmk297 mm
[A3] 297 mmk420 mm
[10 k15cm] 100 mmk150 mm
[4 qk6 q] 101.6 mmk152.4 mm
[8 qk10q ] 203.2 mmk254 mm
[LETTER] 216 mmk279.4 mm
[CARD SIZE] 54 mmk85.6 mm
Page 134
![Page 134
- 134 -
Connecting to other equipment
•An item cannot be selected if the printer does not support the page layout.
∫Layout printing
When printing a picture several times on 1 sheet of paper
For example, if you want to print the same picture 4 times on 1 sheet of paper, set
[Page Layout] to [ ä] and then set [Num.of prints] to 4 for the picture that you want to print.
When printing different pictures on 1 sheet of paper
For example, if you want to print 4 different pictures on 1 sheet of paper, set...](http://img.usermanuals.tech/thumb/58/66166/w300_dmc-sz8_en_adv_om_d-133.png "Page 134
- 134 -
Connecting to other equipment
•An item cannot be selected if the printer does not support the page layout.
∫Layout printing
When printing a picture several times on 1 sheet of paper
For example, if you want to print the same picture 4 times on 1 sheet of paper, set
[Page Layout] to [ ä] and then set [Num.of prints] to 4 for the picture that you want to print.
When printing different pictures on 1 sheet of paper
For example, if you want to print 4 different pictures on 1 sheet of paper, set...")
- 134 - Connecting to other equipment •An item cannot be selected if the printer does not support the page layout. ∫Layout printing When printing a picture several times on 1 sheet of paper For example, if you want to print the same picture 4 times on 1 sheet of paper, set [Page Layout] to [ ä] and then set [Num.of prints] to 4 for the picture that you want to print. When printing different pictures on 1 sheet of paper For example, if you want to print 4 different pictures on 1 sheet of paper, set...
Page 135
- 135 - Others Screen Display ∫In recording 1 Recording Mode 2 Recording Quality (P80) Picture Size (P69) 3 Flash (P49) 4 Optical Image Stabilizer (P78) Jitter alert (P23) : 5 White Balance (P71) Creative control adjustment display (P55) : 6 Battery indication (P13) 7 Burst (P76) 8 Intelligent Exposure (P75) 9 Focus (P30) 10 AF area (P30) 11 Self-timer (P53) 12 Shutter speed (P29) 13 Aperture value (P29) 14 ISO sensitivity (P70) 15 AF assist lamp (P77) 16 Exposure compensation (P54) 17 Age...
Page 136
- 136 - Others ∫In playback • The information of images recorded with other devices, such as their icons or recording information, may not be displayed correctly. In addition, the functions of the camera may not be available for them. 1 Playback Mode (P81) 2 Protected picture (P91) 3 Date stamped display (P79) 4 After Creative Retouch (P86) 5 Picture Size (P69) 6 Battery indication (P13) 7 Picture number Total pictures Elapsed playback time (P34): ¢ 8 Location Information display (P87, 102) 9...
Page 137
![Page 137
- 137 -
Others
Message Display
Confirmation messages or error messages will be displayed on the screen in some cases.
The major messages are described below as examples.
[This picture is protected]
•
Delete the picture after canceling the protect setting. (P91)
[Some pictures cannot be deleted]/[This picture cannot be deleted]
•
Pictures not based on the DCF standard cannot be deleted.
Perform formatting (P45) on this unit after saving necessary data on a PC, etc.
[Built-in memory full. Please insert...](http://img.usermanuals.tech/thumb/58/66166/w300_dmc-sz8_en_adv_om_d-136.png "Page 137
- 137 -
Others
Message Display
Confirmation messages or error messages will be displayed on the screen in some cases.
The major messages are described below as examples.
[This picture is protected]
•
Delete the picture after canceling the protect setting. (P91)
[Some pictures cannot be deleted]/[This picture cannot be deleted]
•
Pictures not based on the DCF standard cannot be deleted.
Perform formatting (P45) on this unit after saving necessary data on a PC, etc.
[Built-in memory full. Please insert...")
- 137 - Others Message Display Confirmation messages or error messages will be displayed on the screen in some cases. The major messages are described below as examples. [This picture is protected] • Delete the picture after canceling the protect setting. (P91) [Some pictures cannot be deleted]/[This picture cannot be deleted] • Pictures not based on the DCF standard cannot be deleted. Perform formatting (P45) on this unit after saving necessary data on a PC, etc. [Built-in memory full. Please insert...
Page 138
![Page 138
- 138 -
Others
[Memory Card Error]/[This memory card cannot be used]
•
Use a card compatible with this unit. (P18)
[Insert SD card again]/[Try another card]
•
An error has occurred accessing the card.
Insert the card again.
•Insert a different card.
[Read Error/Write Error
Please check the card]
•
It has failed to read or write data.
Remove the card after turning this unit off. Insert the card again, turn this unit on, and try to read or
write the data again.
•The card may be broken.•Insert a different...](http://img.usermanuals.tech/thumb/58/66166/w300_dmc-sz8_en_adv_om_d-137.png "Page 138
- 138 -
Others
[Memory Card Error]/[This memory card cannot be used]
•
Use a card compatible with this unit. (P18)
[Insert SD card again]/[Try another card]
•
An error has occurred accessing the card.
Insert the card again.
•Insert a different card.
[Read Error/Write Error
Please check the card]
•
It has failed to read or write data.
Remove the card after turning this unit off. Insert the card again, turn this unit on, and try to read or
write the data again.
•The card may be broken.•Insert a different...")
- 138 - Others [Memory Card Error]/[This memory card cannot be used] • Use a card compatible with this unit. (P18) [Insert SD card again]/[Try another card] • An error has occurred accessing the card. Insert the card again. •Insert a different card. [Read Error/Write Error Please check the card] • It has failed to read or write data. Remove the card after turning this unit off. Insert the card again, turn this unit on, and try to read or write the data again. •The card may be broken.•Insert a different...
Page 139
![Page 139
- 139 -
Others
[Failed to connect wireless access point]/[Connection failed]/[No destination found]
•
Check following regarding the wireless access point.–The wireless access point information set on this unit is wrong.
Check the authentication type, encryption type, and encryption key. (P116)
–Power of the wireless access point is not turned on.–Setting of the wireless access point is not supported by this unit.
•Check the network setting of the destination.•Radio waves from other devices may block the...](http://img.usermanuals.tech/thumb/58/66166/w300_dmc-sz8_en_adv_om_d-138.png "Page 139
- 139 -
Others
[Failed to connect wireless access point]/[Connection failed]/[No destination found]
•
Check following regarding the wireless access point.–The wireless access point information set on this unit is wrong.
Check the authentication type, encryption type, and encryption key. (P116)
–Power of the wireless access point is not turned on.–Setting of the wireless access point is not supported by this unit.
•Check the network setting of the destination.•Radio waves from other devices may block the...")
- 139 - Others [Failed to connect wireless access point]/[Connection failed]/[No destination found] • Check following regarding the wireless access point.–The wireless access point information set on this unit is wrong. Check the authentication type, encryption type, and encryption key. (P116) –Power of the wireless access point is not turned on.–Setting of the wireless access point is not supported by this unit. •Check the network setting of the destination.•Radio waves from other devices may block the...
Page 140
- 140 - Others Troubleshooting First, try out the following procedures (P140–151) . • This phenomenon occurs when charging in a location where the temperature is very high or very low. > Reconnect the USB connection cable (supplied) in a location where the ambient temperature (and the temperature of battery) is in a 10 oC to 30 oC (50 oF to 86 oF) range, and try charging again. •Disconnect the USB connection cable (supplied) and connect it again. •If your PC is not capable of supplying sufficient...
