Panasonic Hair Straighttener Eh Hs95 Operating Instructions

11
English
 Tips for best straightening results
Tips for effective styling
 ●You can achieve a greater effect by dampening your hair.
 ●If it is difficult to straighten, please apply a styling product
(for hair straightening) bef

ore using the straightener.
1
1Brush your hair. •
Ensure that it is lying in the same direction.
2
2Slightly dampen your hair. •
When dampening your hair, do so ev enly on the inside
and outside.
►Notes
 • If your hair is too wet, it will not set properly

.
In this case,...

12
English
Styling order
Start styling from the
bottom on the back of your
head in the order of 1
 to
5  (6
 to  :
 as well).5
43
2
1:
9
8
7
6
Hair types and straightening guidelines
The hair straightening effect may differ among individuals by
the degree of curliness and hair type.
Hard-to-straighten hair Coarse hair, Kinked hair
About hair-straightening products • Do not use the straightener immediately after a home
straight perm liquid is used.
 Doing so may damage your
hair. (The straightener...

13
English
4
4Set a temperature by using
the Temperature Level
Adjustment Switches (F)
according to the
characteristics and
condition of your hair.
Fahrenheit display*
Indicator Temperature
(Approx. )
395
355
300
340
375
395 °F Wavy Less damaged
375
 °F
355 °F Your hair typeYour hair condition
340 °F
300 °F Straight Damaged
Celsius display*
Indicator Temperature
(Approx. )
200
180
150
170
190
200 °C Wavy Less damaged
190
 °C
180 °C Your hair typeYour hair condition
170 °C
150 °C Straight Damaged
 •...

14
English
Using the straightener
Before use, confirm that the LED Temperature Level Display
(C) has stopped blinking and glows.
Straightening
1
1Hold a bundle of hair with a width of
approximately 1-31/32″ (5
 cm). •
Do not take too much hair as it may be difficult to
straighten your hair
.
2
2Clamp the bundle of hair in
the center of the Iron Plate
(G).
 •
Use both hands and hold both
Press Plate Tips (A) to str
aighten
curly hair.
 • Do not use excessive force as it
ma

y place a strain on...

15
English
About the Intelligent Sensing System
1. If you leave the straightener for a certain amount of time when it is set to a high temperature, the temperature
automatically falls to 340/170* to prevent this unit from
becoming too hot.
(The LED Temperature Level Display (C) will alternate
blinking between the set temperature and 340/170*.)
Fahrenheit display*
Set Temperature Time Left Alone Decreased
Temperature
395
375 15 minutes
340
355 20 minutes
Celsius display*
Set Temperature Time Left...

16
English
About nanoe™
What is nanoe™?
(nanoe™ generation method: High-voltage discharge)
nanoe™ is charged fine water particles, generated by applying
high voltage in order to split water. Its diameter is smaller than
1/100 of steam (approx. 6000–8000
 nm), and it cannot be
seen with the naked ey

e. Since nanoe™ is generated by
collecting water in the air, it may be difficult to generate in
certain cases depending on the environment.
How nanoe™ works
Generally hair has properties which make it...

17
English
Cleaning the straightener
 ●When this unit has become dirty or styling products, etc.
ha
ve gotten onto it, please soak a rag in soapy water, wring
it out, and wipe the unit clean.
 ● Do not use alcohol, thinner, benzine or remover

.
Doing so may crack or discolor the surface of the
straightener.
Troubleshooting
Problem
 ● Sparks are generated inside the nanoe™ Outlet. ●The nanoe™ Outlet emits a noise (crackling noise).
Possible cause
Dust, styling products, etc. are
adhered to the...

18
English
Specifications
Power sourceSee the name plate on the main body.
Power consumption
Iron temperature Approx. 395
 ˚F*
Approx. 200 ˚C*
* According to the country, the v

alue of temperature differs
between Fahrenheit and Celsius.
This product is intended for household use only.
USER
MAINTENANCE
INSTRUCTIONS
This straightener is virtually maintenance free. No lubrication
is needed.
For proper operating performance, the straightener must be
kept clean.
When cleaning is needed, unplug the...

19
Español
Instrucciones de funcionamiento
(Electrodoméstico) Alisador de pelo
Modelo n.º EH-HS95
Muchas gracias por comprar este producto Panasonic.Antes de utilizar esta unidad, lea estas instrucciones de principio a fin y guárdelas para poder consultarlas en el futuro.
nanoe™ es una marca comercial de Panasonic Corporation .
Una nanoe™ es una partícula muy pequeña de iones cubierta con
partículas de agua.
Índice
Precauciones de seguridad ..... 22
Identificación de las piezas
 ��������������26...

20
Español
INSTRUCCIONES DE
SEGURIDAD
IMPORTANTES
Cuando utilice aparatos eléctricos, especialmente ante la
presencia de niños, observe siempre unas precauciones de
seguridad básicas, como las que se describen a continuación.
LEA LAS INSTRUCCIONES ANTES DE
UTILIZAR EL PRODUCTO
MANTENGA EL PRODUCTO ALEJADO DEL AGUA
PELIGROAl igual que con la mayoría de los aparatos eléctricos, los
componentes eléctricos acostumbran a llevar tensión, aunque
el aparato esté apagado.
Para reducir el riesgo de muerte...
