Here you can view all the pages of manual Panasonic Indoor Pan Tilt Head Aw Ph400 Operating Instructions . The Panasonic manuals for Camera Accessories are available online for free. You can easily download all the documents as PDF.
Page 11
$Assembling the pan/tilt head 1Attaching the camera mounting base Attach the camera mounting base to the rotary arm using the three screws. The mounting direction differs depending on the installation method used. 2Attaching the rotary arm Attach the rotary arm to the rotary head using the four screws. The mounting direction differs depending on the installation method used. 3Mounting the tally lamp Remove the four screws to remove the top cover. Remove the two screws to remove the blank panel. Mount the...
Page 12
Indoor Pan/Tilt Head AW-PH400 11 (E) Installation(Be sure to ask your dealer to install the unit.) $Setting the mounting direction switch Set the switch as follows when the unit is to be installed on the ceiling. (This switch was set to the stand-alone installation position at the factory.) 1Remove the four screws, and gently remove the pedestal connector panel. 2Set switch S1 on the PCB inside the pan/tilt head as follows. For stand-alone installation: Set S1 to the rear position (T). (Factory...
Page 13
Indoor Pan/Tilt Head AW-PH400 12 (E) ENGLISH Installation(Be sure to ask your dealer to install the unit.) $Setting the PCB switches The switches on the CONNECTOR PCB will need to be set in accordance with the signals to be transmitted and the equipment to be connected to the pan/tilt head. (The switches are set to support analogue/SDI at the factory.) ≥Analogue/SDI support IP/IEEE switch: IEEE 422/IP switch: 422 ≥Web card support IP/IEEE switch: IP 422/IP switch: IP ≥IEEE1394 card support IP/IEEE...
Page 14
Indoor Pan/Tilt Head AW-PH400 13 (E) Installation(Be sure to ask your dealer to install the unit.) $Changing the mounting position of the pedestal connector panel If necessary, the position at which the pedestal connector panel is mounted can be moved to the opposite side of the unit. 1Remove the four screws for the pedestal connector panel, and pull out the pedestal connector panel. 2Disconnect all six connectors of the PCB at the back of the pedestal connector panel. 3Remove the four screws for the...
Page 15
Indoor Pan/Tilt Head AW-PH400 14 (E) ENGLISH Installation(Be sure to ask your dealer to install the unit.) $Installing the pan/tilt head When installing the pan/tilt head, follow the instructions below carefully. In order to prevent accidents resulting when the product becomes dislodged or falls down, be absolutely sure to proceed as instructed. Do not install the pan/tilt head on its side since its prescribed operation and performance cannot be ensured. ≥After the pan/tilt head has been installed,...
Page 16
Indoor Pan/Tilt Head AW-PH400 15 (E) Installation(Be sure to ask your dealer to install the unit.) $Mounting the camera 1Select the positions of the guide pin and camera mounting screws in accordance with the camera and lens to be used, and mount the camera. When mounting the camera on the pan/tilt head, be very careful to ensure that the camera does not fall off or fall down. For a stand-alone installation For installation on the ceiling Guide pin Guide pin Flat washers Flat washers Camera mounting...
Page 17
Indoor Pan/Tilt Head AW-PH400 16 (E) ENGLISH Installation(Be sure to ask your dealer to install the unit.) $Attaching the chain When mounting the AW-E750 camera 1Use the chain mounting screw (M4!8 mm with flat washer and spring washer) to attach one end of the chain to the pan/tilt head’s arm. 2Mount the mounting spacer on the top panel of the camera. 3Use the chain mounting screw (M4!6 mm with flat washer and spring washer) to attach the other end of the chain to the screw hole of the mounting spacer....
Page 18
Indoor Pan/Tilt Head AW-PH400 17 (E) Replacing the consumable parts $Replacing the battery The battery has a service life of approximately 5 years. The unit stores the preset positions, limiters and other data in its memory. This data is retained even when the power is turned off, but if the internal battery has reached the end of its service life, the data will be lost when the power is turned off. Replace a battery that has lost its charge with a new one. (Battery used: CR2032 manganese...
Page 19
Indoor Pan/Tilt Head AW-PH400 18 (E) ENGLISH Specifications Genlock input:BNC Black burst or composite video signal Prompter input (PROMPTER IN):BNC Through output to PROMPTER connector Prompter output (PROMPTER OUT):D-SUB 15-pin Camera video output VIDEO: BNC, 75-ohm output, 1 Vp-p Connecting cable: 5C-2V, max. 1000 meters Y, Pr/C, Pb: Y/C Y: 1 Vp-p/75 ohms C: 0.285Vp-p/75 ohms (burst) Component video: Y: 1 Vp-p/75 ohms Pr: 0.7Vp-p/75 ohms Pb: 0.7Vp-p/75 ohms Connecting cable: 5C-2V, max. 1000 meters...
Page 20
Pan/Tilt Head Controller AW-RP400 19 (E) Introduction Accessories ≥This pan/tilt head controller enables up to five AW-PH400 indoor pan/tilt heads to be controlled. ≥By connecting the AW-CB400 remote operation panel or WV-CB700A remote control box to the controller, the convertible cameras mounted on the pan/tilt heads can be controlled at the same time. ≥By installing an additional controller, two of the five units in the pan/tilt head system can be controlled at the same time. ≥Up to ten tracing...
