Pan/Tilt Head Controller  AW-RP400
20 (E)
ENGLISH
Parts and their function
1EXT CONT [M/S] switch
This switch is normally kept at the [M] (master) position.
When an additional AW-RP400 controller has been
installed, set the EXT CONT switch on the additional unit
to [S] (slave).
If no additional AW-RP400 controller is going to be
installed, the EXT CONT switch on this controller must be
kept at the [M] (master) position without fail.
2OPERATE lamp
This lights up green when the (3) OPERATE switch is at
ON....

Pan/Tilt Head Controller  AW-RP400
21 (E)
Parts and their function
7IRIS [AUTO/MANU/LOCK] button
Use this to select the method for adjusting the lens iris of
the cameras in the currently selected pan/tilt head
system.
Each time it is pressed, the setting is switched in the
sequence of AUTO, MANU and LOCK.
AUTO:The cameras automatically adjust the lens iris in
accordance with the light quantity, and the IRIS
button lamp lights.
MANU:The lens iris is adjusted manually using the IRIS
dial. At this setting,...

Pan/Tilt Head Controller  AW-RP400
22 (E)
ENGLISH
Parts and their function
BMEMORY button
When one of the (C) PRESET MEMORY selection
buttons [1] to [50] is pressed while holding down the
MEMORY button, the settings of the pan/tilt head system
can be registered in that PRESET MEMORY selection
button.
The MEMORY button flashes if the pan/tilt head selected
by the (H) CONTROL SELECT button is not connected
or its power has not been turned on.
CPRESET MEMORY selection buttons [1] to [50]
Use these buttons...

Pan/Tilt Head Controller  AW-RP400
23 (E)
Parts and their function
MEXT CONT IN/OUT connectors
When an additional AW-RP400 controller is to be
provided, connect these connectors on the two
AW-RP400 controllers using a 10BASE-T (equivalent to
UTP category 5) straight cable.
NCAMERA CONTROL IN FROM RCB [P1] to [P5]
connectors
Connect the WV-CB700A remote control boxes to these
connectors.
The cameras installed on the pan/tilt heads
corresponding to the ports where the WV-CB700A boxes
have been connected...

Pan/Tilt Head Controller  AW-RP400
24 (E)
ENGLISH
Parts and their function
PREMOTE connector
Connect an external unit to this connector to control the
pan/tilt head systems from a PC or other external unit.
Connect the connector to the PC using the AW-CA50T9
RS-232C cable.
QDC 12V IN socket
Connect the AW-PS505 AC adaptor (sold separately) to
this socket.
RCONTROL OUT TO PAN/TILT HEAD [P1] to [P5]
connectors
Connect these connectors to the IP/RP connectors on the
AW-PH400 indoor pan/tilt heads using...

Pan/Tilt Head Controller  AW-RP400
25 (E) $Operation method
1The menu setting items are displayed when the
MENU/LIMIT switch is held down for two or more
seconds.
2If nothing appears on the bottom line of the LCD display,
turn the CONT dial to select a menu item.
3When the CONT dial is pressed, what has been set
appears on the bottom line. If more than one setting is
involved in the menu item, the settings on the bottom line
are switched each time the dial is pressed.
4When a setting is displayed, the...

Pan/Tilt Head Controller  AW-RP400
26 (E)
ENGLISH
Menu settings
$List of menu items and settings
PRIORITY MASTER, SLAVE MASTER
DIRECTION PAN
TILT
ZOOM
NORMAL, REVERSE NORMAL
FOCUS
IRIS
ROTATION
SPEED WITH ZOOM POS. OFF, 1, 2, 3 OFF
MEMORY LENGTH 60s, 120s, 300s, 600s 60s
PRESET SPEED 1 to 25 25
IRIS CONTROL BOTH, RP400, CB400 BOTH
ROTATION SWITCH ROTATION, FOCUS, ZOOM, IRIS ROTATION
OPTION SWITCH A
B
C
NOT USE, LAMP, EFROSTER, WIPER,
D
HEATER/FAN, AF, ND, OPTION, NOT USE
E
EXTENDER
F
G
H
CONTROL SELECT...

Pan/Tilt Head Controller  AW-RP400
27 (E)
Menu settings
DIRECTION settings (PAN, TILT, ZOOM, FOCUS, IRIS, ROTATION NORMAL/REVERSE)
When the lever or dial is operated, the DIRECTION menu item enables the operational direction of PAN, TILT, ZOOM,
FOCUS, IRIS or ROTATION to be set as the user desires.
PAN:When NORMAL is selected, the pan/tilt head moves toward the left when the PAN/TILT lever is tilted to the
LEFT and toward the right when it is tilted to the RIGHT. When REVERSE is selected, the head moves...

Pan/Tilt Head Controller  AW-RP400
28 (E)
ENGLISH
Menu settings
OPTION SWITCH A to H settings
(NOT USE / DEFROSTER / WIPER / HEATER/FAN / AUTO FOCUS / ND / OPTION / EXTENDER)
The following functions can be allocated to OPTION buttons A to H. Different functions can be allocated for different pan/tilt
heads.
NOT USE:The button is disabled.
DEFROSTER:This controls the ON and OFF states of the defroster function when using a pan/tilt head system
equipped with this function.
Each time the button is pressed,...

Pan/Tilt Head Controller  AW-RP400
29 (E)
Menu settings
MONITOR SELECT setting
This menu item is used to select the controller used to switch the images of the AW-RC400’s MONITOR2 output when the
AW-CB400 remote operation panel and a second AW-RP400 have been connected to this AW-RP400 controller and the
AW-RC400 cable compensator is used.
By setting the master AW-RP400 and slave AW-RP400, the camera images which have been selected by the controller given
in the table below are output as the AW-RC400’s...
