Panasonic Kx-Td816c, Kx-td1232c Digital Super Hybrid System User Manual

DSS Console Features
User Manual351
5.1.3 Feature Buttons
DSS Consoles have the following types of Feature Buttons:
DSS Buttons with Busy Lamp Field (BLF)
Used to access extensions. The BLF indicates the busy or idle status of each extension in the
system. These buttons can also be changed to other function buttons.
PF (Programmable Feature) Buttons [KX-T7240 only]
These buttons are provided with no default settings. With a paired telephone, you can program
the buttons as other function buttons.
ANSWER...

DSS Console Features
352User Manual
5.2 Station Programming
5.2.1 Station Programming Instructions
PF buttons are provided with no default settings, while each DSS button has a default setting
as follows. DSS 01-32: extension numbers 101-132 (DSS 33-66: not stored).
To meet your various needs, DSS buttons can be changed to other function buttons.
Every DSS or PF button can be assigned to another extension number, telephone number or
feature number through Station Programming.
Conditions
DSS buttons...

DSS Console Features
User Manual353
   indicates that the feature is available.
When the STORE button is pressed after programming, you will hear beep tones as follows.
– One beep: The entry is changed from one that was stored previously.
– Two beeps: The entry is the same as on stored previously.
Programming Guide References
[007] DSS Console Port and Paired Telephone Assignment
User Manual References
2.2.2 Flexible Button Assignment * Available when the Digital Super Hybrid System is connected to a...

DSS Console Features
354User Manual
5.2.2 Extension Number Assignment
You can assign the desired extension number to a DSS button.
– Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
– To exit the Station Programming mode: Press [PROGRAM] or lift the handset.
PT and DSS Console
Dial 1. Enter the desired
extension number.
extension no.
Press the desired
DSSbutton.
(DSS)
[DSS Console][Paired telephone]
Press STORE.
AUTO DIAL
STORE
[Paired telephone][Paired telephone]...

DSS Console Features
User Manual355
5.2.3 One-Touch Dialing Assignment
You can assign a DSS or PF button as a One-Touch Dialing button. The number can be an
extension number or a telephone number. Up to 16 digits can be stored into each memory
location.
—Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
—To exit the Station Programming mode: Press [PROGRAM] or lift the handset.
PT and DSS Console
Dial 2. Enter the desired  number
(extension number, phone
number, etc.)....

DSS Console Features
356User Manual
5.2.4 One-Touch Access Assignment for System Features
You can assign the desired feature number to a DSS or PF button.
—Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
—To exit the Station Programming mode: Press [PROGRAM] or lift the handset.
PT and DSS Console
Dial 2. Enter the desired
feature number.
2feature no.
Press the desired
DSSor PFbutton.
[DSS Console]
or[Paired telephone]
Press STORE.
AUTO DIAL
STORE
[Paired telephone] [Paired...

DSS Console Features
User Manual357
5.3 DSS Console Features
5.3.1 Direct Station Dialing
An extension can be called and accessed, simply by pressing a DSS button. The BLF shows if
the extension is busy.
PT and DSS Console
Lift the handset or press
SP-PHONE/MONITOR.Press the desired DSS button.
[DSS Console] [Paired telephone]
(DSS)

DSS Console Features
358User Manual
5.3.2 One-Touch Dialing
The stored number is dialed automatically by pressing a programmed DSS or PF button.
PT and DSS Console
Lift the handset or press
SP-PHONE/MONITOR.Press the desired
DSS or PF button.
[DSS Console]
or [Paired telephone](DSS) (PF)

DSS Console Features
User Manual359
5.3.3 One-Touch Access for System Features
You can access system features by pressing a programmed DSS or PF button.
PT and DSS Console
Lift the handset or press
SP-PHONE/MONITOR.Press the desired
DSS or PF button.
[DSS Console]
or [Paired telephone]
(DSS) (PF)

DSS Console Features
360User Manual
5.3.4 Call Transfer
A call can be transferred to an extension by using the DSS button.
One-Touch Transfer
An outside call can be transferred to an extension with an One-Touch operation.
 The One-Touch Transfer function must be set through System Programming.
Programming Guide References
[108] Automatic Hold by CO / DSS Button
PT and DSS Console
Press TRANSFER.
TRANSFER
Press the desired DSS button.
[DSS Console] [Paired telephone]
During  a conversation;
(DSS)
PT and...
