Panasonic Kx-Td816e, Kx-td1232e User Manual

Station Programming2-47
2.2Station Programming
To store a name
—Be sure that you are in the Station Programming mode:Press [PROGRAM] [9] [9].
1.Press .
2.Enter the Station Speed Dial number(0 through 9).
•The STORE indicator light turns off.
•The display shows the current status.

(—The outside call,431-2111,
is now programmed.)
3.Press the NEXT(S3) button or MODEbutton to store a name.
– NEXT(S3) button:for KX-T7433 users
– MODEbutton:for KX-T7431 users
4.Enter the name.
•Refer to the Combination Table...

2-48Station Programming
2.2Station Programming
Combination Table
Characters can be entered using the dial key pad,various buttons or the Jog Dial for
storing names.
Combination Table 1shows the combination of keys and the number of times to press
the SELECT (AUTO ANSWER/MUTE) button,or the combination of keys and the
SHIFT and Soft buttons to enter characters.
(The AUTO ANSWER/MUTE button becomes the
SELECT button when using the overlay.)
To enter a character,find the key and number of times to press...

Station Programming2-49
2.2Station Programming
Combination Table 2
Keys012345678
11QqRrSsTt
22AaBbCcDd
33DdEeFfGg
44GgHhIiJj
55JjKkLlMm
66MmNnOoPp
77PpQqRrSs
88TtUuVvWw
99WwXxYyZz
00!?.,’:;
*/+-=#$
##$%&@()Aa
Rotating
Jog Dial
(Pulses)
  To enter “Mike”
— Using the SELECT button (With a KX-T7431 / KX-T7433 / KX-T7436 / KX-T7235)
See Combination Table 1.
1. Press 6 and then press the SELECT button onceto enter “M.”
2. Press 4 and then press the SELECT button sixtimes to enter “i.”
3. Press 5 and then...

2-50Station Programming
2.2Station Programming
— Using the Jog Dial (With a KX-T7431 / KX-T7433 / KX-T7436)
See Combination Table 2.
1. Press 6 and then rotate the Jog Dial one pulse to enter “M.”
2. Press 4 and then rotate the Jog Dial sixpulses to enter “i.”
3. Press 5 and then rotate the Jog Dial fourpulses to enter “k.”
4. Press 3 and then rotate the Jog Dial fourpulses to enter “e.”
OR
1. Press 2 and then rotate the Jog Dial until “M”appears.
2. Press 2 and then rotate the Jog Dial until...

Section 3
User Programming
(Manager Programming)
Contents
3.1 User Programming Instructions .........................................
3-2
General Programming Instructions......................................3-2
Programming Ways...............................................................3-5
3.2 User Programming (Manager Programming) ...................3-7

3-2User Programming (Manager Programming)
3.1User Programming Instructions
General Programming Instructions
User Programming (Manager Programming) allows you,the proprietary telephone (PT)
user,to program the following features of the system from your telephone individually.
• Date and Time Set
• System Speed Dialling Number Set
• System Speed Dialling Name Set
• Extension Number Set
• Extension Name Set
• Flexible CO Button Assignment
• Operator / Manager Extension Assignment – Day / Night
• DSS...

User Programming (Manager Programming)3-3
3.1 User Programming Instructions
KX-T7230 KX-T7235
PROGRAM
VOLUME
SHIFT
1
4
75
8
0 2
6
9 3
FLASH PREV END
STORE
SELECT
NEXT
SECRETPAUSE CLEAR
Soft-1 Soft-2 Soft-3
SECRETPAUSE CLEAR
PROGRAM
Soft 1 Soft 2 Soft 3
SHIFT
VOLUME1
4
75
8
0 2
6
9 3
FLASH PREV END
STORE
SELECT
NEXT
KX-T7433 KX-T7436
SECRETPAUSEPROGRAM CLEAR
STORE
FLASH SELECT
END PREV NEXT
ABC DEF
JKL MNO GHI
TUV WXYZ
OPER PQRS
SHIFT Soft-1 Soft-2 Soft-3
SECRETPAUSEPROGRAMCLEAR
STORE
FLASHSELECT
END...

3-4User Programming (Manager Programming)
3.1User Programming Instructions
Before entering the programming mode
Before entering programming mode,confirm that:
• Your telephone is on-hook.
• No calls are on hold at your telephone.
Entering the programming mode
To enter the User Programming (Manager Programming) mode:
Press PROGRAM + ++ User Password (default:1234)
• The display shows the Initial Message:
USR-PGM NO?®
Notes:
• If nothing is entered in five seconds after the PROGRAM button is pressed,it is...

User Programming (Manager Programming)3-5
3.1User Programming Instructions
Programming Ways
Advancing to the next stage
When “USR-PGM NO?®”is displayed,you can select one of the following:
• To go to program [000],press the NEXT button.
• To go to another program,enter the 3-digit program address.
Rotation of jack number
Each jack of our Digital Super Hybrid System supports the connection of a digital
proprietary telephone and an analogue device with different extension numbers (eXtra
Device Port:XDP...

3-6User Programming (Manager Programming)
3.1User Programming Instructions
Making another selection within the same program address
•To make the next higher selection,press NEXT.
•To make the previous selection,press PREV.
•To make a specific selection,press SELECTand then enter the number.
Going to another program address
After pressing STORE,you can go to another program with either of the following two
methods:
(1)•To go to the next larger program address:
Press Soft 1 (SKP+)or VOLUME(DOWN).
•To go to...
