Panasonic Network Camera Wv Sud638 Information Guide

11
or excessive heat resulting in a fire. Do not use
damaged power plugs or power outlets.
Securely connect the power cable.
Loose connection may cause electric shock or
heat resulting in fire.
Regularly remove any dust, etc. from the
power plug.
Accumulated dust may cause an insulation
defect from moisture, etc., resulting in a fire.
Disconnect the power plug, then wiping with a
dry cloth.
Always hold the plug when unplugging the
power cord.
Otherwise, the cord may be damaged and
result in a...

12
Do not hang down from this product or
use this product as a pedestal.
Failure to observe this may cause injury or
accidents.
Do not use this product in an inflammable
atmosphere.
Failure to observe this may cause an explosion
resulting in injury.
Avoid installing this product in the loca-
tions where corrosive gas is produced.
Otherwise, the mounting portions may deterio-
rate and thus the product may fall down,
resulting in injury or accidents.
Do not install this product in a place that
is...

13
unplugged easily from the AC outlet. If the
power cord cannot be unplugged easily due to
installation conditions, connect the power cord
to an outlet such as an AC outlet or a power
control unit that goes through a circuit breaker
of a distribution board with a cut-off capacity.
Handle this product with care.
Do not drop this product, nor apply shock or
vibration to the product. Doing so may result
in failure or water penetration.
About the battery
A battery is installed inside the camera. Do...

14
Cleaning of the front glass
Use lens cleaning paper (used to clean camera
or spectacles lenses) to remove any dirt on the
front glass. (If dust or the like is adhered at this
time, the front glass may get scratched.We
recommend rinsing for stubborn stains.)
Consumable parts
The following are consumables: Replace them
in accordance with their operating lifetimes.
Their operating lifetimes vary depending on the
usage environment and conditions. The oper-
ating lifetimes below are just guides for...

15
Precautions for installation
In order to prevent injury, the product
must be securely mounted to a ceiling or
floor according to Installation Guide.
Always connect to the main power outlet
with protective grounding.
About grounding
 •	 Please	make	sure	that	the	grounding	is
installed securely and correctly before
usage. Please check the ground resistance
value (100 Ω or less) when using an outlet
with a ground terminal.
	 •	 	 Always	perform	ground	connection	before
connecting the power plug to...

16
	 •	 Locations	where	a	radiation,	an	X-ray,	a	strong radio wave or a strong magnetic
field is generated
	 •	 Locations	directly	exposed	to	seawater,	or	 where corrosive gas is generated such as
volcanic regions/hot springs
	 •	 Locations	where	the	temperature	is	not	 within the specified range (
☞ page 22)
	 •	 Locations	subject	to	vibrations,	such	as	on	 vehicles or above product lines (This prod-
uct is not designed for on-vehicle use.)
	 •	 Locations	subject	to	condensation	as	a	 result of severe...

17
Radio disturbance
Noise may appear in video or audio near a
strong electric field from a TV or radio antenna,
motors and transformers, or a strong electric
field/magnetic field from a power line (lamp line)
of AC100 V or more.
Power supply from a tested PoE injector
Connect the tested PoE injector to a normal
hub/device.
This product will not operate with only the
power supply from a PoE+ hub/device that is
compliant with IEEE802.3at standard.
Router
When connecting this product to the...

18
Before asking for repairs, check the symptoms with the following table.
Contact your dealer if a problem cannot be solved even after checking and trying the solution in th\
e
table or a problem is not described below.
SymptomCause/solution Reference
pages
Power is not turned
on. When using a tested PoE injector for power supply
	•
Are the tested PoE injector and the RJ45 female con-nector (cable coupler) connected using an Ethernet
cable (category 5e or better)?
Check whether the connection is...

19
SymptomCause/solution Reference
pages
When the power is
turned on, the
STATUS indicator
lights or blinks
orange. 	•	 Is	the	ethernet	cable	connected	appropriately?

Connect the ethernet cable appropriately.
	•	 Is	the	hub	or	router	connected	to	the	camera	operat- ing appropriately?
    Check if the hub or router in use is operating appro-
priately.
	•	Isn't	the	ethernet	cable	connected	to	the	camera
broken?
    Replace the cable with another one.
“Connecting”  in  Installation  Guide...

20
SymptomCause/solution Reference
pages
Audio input contains
noise. 	•	 Check	the	following.
	 •
	 Grounding	of	the	camera,	a	switching	hub	or
peripheral devices are not done.
	 •	 	 The	camera	is	used	near	an	power	line	(lamp	line)
of AC100 V or more.
	 •	 	 The	camera	is	used	near	a	device	which	produces
strong magnetic field or radio waves (such as near
a TV/radio antenna, a motor of an air conditioning
system, a transformer, etc.)
    When audio input still contains noise even after...
