Panasonic Pt D5700e Projector Specifications

The 6,000-lm projector that's easy to see
even in brightly lit rooms

 


6,000lm
XGA
PT- PT-

1
High brightness and high picture quality
System daylight view High-power 6,000-lm
brightness
The PT-D5700E/D5700EL offer full 6,000 lumens of
brightness, thanks to the newly developed AC lamp,
more efficient reflectors and a synthetic mirror. This
enables crisp, sharp images even when projecting in
a classroom, meeting room, or other location with
ordinary daytime lighting.The system daylight view function uses an image processing circuit to
compensate for the loss of colour saturation that...

Conference rooms Classrooms ChurchesControl roomsProjection of bright, high-quality
images in large spaces such as
halls, conference rooms,
classrooms, control rooms,
and churches.
2
More effective
noise reduction
Dynamic
sharpness controlVivid colour
control
Progressive cinema
scan
(3/2 Pulldown)
A unique control technology is
used to maximise the colour
segment areas of the colour
wheel. Compared to conventional
projectors, the brightness of each
colour is increased by an average
of...

3
NEWWeb browser control/
monitoring and
e-mail message alert
•Colour matching functionThe Colour Matching function corrects the
subtle variations in colour reproduction
between projectors. Originally developed
''adjustment assist'' software quickly and
precisely optimises images, so the colours
on each screen are uniformly reproduced.
•Edge blending functionThis function controls luminance at the
edges where screens overlap. By eliminating
unnatural screen joints, it produces...

4
NEW
Other valuable features
A mechanical lens shutter minimises annoying
light leakage when the PT-D5700E/
D5700EL is on standby or temporarily not in
use, such as during a meeting.
Mechanical lens shutter
Built-in capacitor provides power to cool the
internal parts. This means that you can switch
off the room's main power as soon as the
presentation ends. PT-D5700E/D5700EL
doesn't make you wait around and helps
minimise lamp damage.
Direct power off
Dust filter is replaced from the...

NOTES ON USE1. Do not install the projector in locations that are subject to excessive water, humidity, steam, or oily smoke.
    Doing so may result in fire, malfunction, or electric shock.
2. The projector uses a high-voltage mercury lamp that contains high internal pressure. This lamp may break,
    emitting a large sound, or fail to illuminate, due to impact or extended use.
3. The projector uses of high-wattage lamp that becomes very hot during operation. Please observe the
    following...
