Page 31
30 Playing games in game mode LIGHT ASPECT MUTE TV/VIDEO VCR DVDAUXRCVR TV DTVCBLDBSCH VOL VOL CH MENU INFO/RECALL AV-ADJNORMALRH-SPLIT EXITVCR RECGUIDE REWSEARCH STOPPLAYSPLITFF FREEZETV/VCR SLOWSWAPPAUSE OPEN/CLOSEVCR/DBS CHANNEL STILL 123 456 789 0 R-TUNE PROG ACTION POWER GAME 1 2 3Turn on the TV. Press the GAME button to switch to game mode. When finished, press the GAME button again. (Turn off the game mode by switching input modes or changing the channel.) GAME POWER Confirming connections Confirm...
Page 32
31 Recall / Mute LIGHT ASPECT TV/VIDEO VCR DVDAUXRCVR TV DTVCBLDBSCH VOL VOL CH MENU AV-ADJNORMALGAME RH-SPLIT EXITVCR RECGUIDE REWSEARCH STOPPLAYSPLITFF FREEZETV/VCR SLOWSWAPPAUSE OPEN/CLOSEVCR/DBS CHANNEL STILL 123 456 789 0 R-TUNE PROG ACTION POWER MUTE INFO/RECALL Press this button to display channel number, off-timer remaining time, screen modes, and other settings. For approximately 10 seconds, only the channel number remains,..... The channel number remains, but other information disappears after...
Page 33
32 (The previously selected screen appears.) Example: Two screen mode set to NORMAL aspect. • Returning to one screen. Split screen LIGHT MUTE TV/VIDEO VCR DVDAUXRCVR TV DTVCBLDBSCH VOL VOL CH MENU INFO/RECALL AV-ADJNORMALGAME RH-SPLIT EXITVCR RECGUIDE REWSEARCH STOPPLAY SLOW VCR/DBS CHANNEL 123 456 789 0 R-TUNE PROG ACTION POWERASPECT SPLITFF SWAPPAUSE STILL FREEZETV/VCR OPEN/CLOSE Split screen enables you to search other channels on the right screen or check video recording status. Splitting the...
Page 34
33 Screen mode names: SPLIT SCREEN FULL SPLIT SCREEN NORMAL PoutP 1 2 Changing the channel of the right screen during SPLIT SCREEN FULL, SPLIT SCREEN NORMAL, and PoutP. RH-SPLITPress to operate right screen. 5While is displayed on the screen, press to switch modes. Example: Change to channel 5. Viewing videos TV/VIDEO While is displayed on the screen, press to switch modes. • The channels for the left screen can be changed in the same way as when the screen is single. Swapping left and...
Page 35
34 Adjusting screen position and size LIGHT MUTE TV/VIDEO VCR DVDAUXRCVR TV DTVCBLDBS INFO/RECALL AV-ADJNORMALGAME RH-SPLIT EXITVCR RECGUIDE REWSEARCH STOPPLAYSPLITFF FREEZETV/VCR SLOWSWAPPAUSE OPEN/CLOSEVCR/DBS CHANNEL STILL 123 456 789 0 R-TUNE PROG POWERASPECT MENU CH VOL VOL CH ACTION Adjusting screen ASPECTPress to select the screen mode to adjust. Press to display the MENU screen. Notes: • This TV is equipped with various screen modes. If a screen mode with a different aspect from the broadcast...
Page 36
35 Switching screen width During NORMAL mode, if noise appears on the ends of the image in SIZE 1, switch to SIZE 2. CH VOL VOL CH ACTION CH VOL VOL CH ACTION CH VOL VOL CH ACTION CH VOL VOL CH ACTION Press to narrow (SIZE 2). Press to widen (SIZE 1).(SIZE 1) (SIZE 2) During JUST mode, if noise appears on the ends of the image in SIZE 1, switch to SIZE 2. Press to enlarge image horizontally (SIZE 2). Press to shrink image horizontally (SIZE 1). (SIZE 1) (SIZE 2) Changing vertical size During ZOOM modes....
Page 37
36 Audio Adjustments Automatically adjusts quiet sound and loud sound for ease of listening. Emits the original sound. Gives contrast to sound. For programs consisting mainly of music. Enhances high sounds (around 4 kHz). Enhances high sounds even more. (Recommended for those who have slight hearing deficiencies.) When GAME is selected for the picture, sound setting also changes to GAME. During GAME mode, sound mode cannot be changed in this menu. Press to select AUDIO ADJUST. Press to display AUDIO...
Page 38
37 CH VOL VOL CH ACTION AUDIO ADJUST NORMAL AUTO OFF ON OFF ON AUDIO MENU SURROUND CENTER SP– Turning the center speaker ON and OFF to enhance the mood During AUDIO ADJUST menu: Press to select CENTER SP. Press to select switch. ON : • Sound given off from the center is enhanced and stability is increased. OFF: • Use when certain scenes are hard to hear or to enhance and increase stability. • To end adjustments MENU Turning the speaker sound ON and OFF SPEAKERS OFF Turns off the...
Page 39
38 Picture Adjustments Press the MENU button to display the MENU screen and select ADJUST.1 2 Press to select to PICTURE ADJUST. CH VOL VOL CH ACTION Press to display the PICTURE ADJUST screen. MENU ADJUST CUSTOM PICTURE AUDIO PICTURE ADJUST POSITION/SIZE SELECT AUDIO ADJUST SET UP EXITPAGEACTION PICTURE ADJ. NORMAL NORMAL OFF ONAUTO SELECT PICTURE PICTURE MENU BRIGHTNESS COLOR TINT SHARPNESS COLOR TEMP ADVANCED ADJ. EXITACTION 20 0 0 0 0– y+ – y+...
Page 40
39 CH VOL VOL CH ACTION PICTURE ADJ. NORMAL NORMAL OFF ONAUTO SELECT PICTURE PICTURE MENU BRIGHTNESS COLOR TINT SHARPNESS COLOR TEMP ADVANCED ADJ. EXIT ACTION 20 0 0 0 0– y+ – y+ – y+ – y+ PICTURE Selects proper brightness and density for the room. BRIGHTNESS Adjusts for easier viewing of dark pictures such as night scenes and hair. COLOR Adjusts slightly to a lighter color. TINT Adjust for nice skin color....
