Proxima Pro Av 9400 Projector User Manual

21
video/y
c/cb (b-y) cr (r-y)
S-video
RL(mono)audio
S-video
RL(mono)audio
S-video
RLaudio
VIDEO IN-1
VIDEO IN-2
MONITOR OUT
video/y
c/cb (b-y) cr (r-y)
video/y
c/cb (b-y)
cr (r-y)
NOTE: The hook up should be done as per the above illustration. After hook up, turn on the projector, video equipment, in
that order.
VIDEO EQUIPMENT
Video Cassette RecorderDVD Player
Video Disc PlayerSatellite
TV Tuner
MONITORAUDIO
INPUT AUDIO
OUTPUT S-VIDEO
OUTPUT
S-VIDEO
INPUT
SPEAKERSAUDIO AMP.
Video Camera
Y
OUTPUT
(BNC)...

22
memu mode
auto imagenormal
select volume zoom focus lens shift power
5
697
12
11
10
13
14
8
15
TOP CONTROLS
FRONT INDICATORS
FRONT INDICATORS
TOP CONTROLS
readylamp
lamp
replacewarning
temp
1234
BEFORE OPERATION
CONTROLS AND  INDICATORS

23
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
LAMP REPLACEMENT INDICATOR
Light is orange when projection lamp is nearing end of service life.
TEMPERATURE WARNING INDICATOR
Flashes red when internal projector temperature is too high.
READY INDICATOR
Light is green when projector lamp is ready to be turned on.
LAMP POWER INDICATOR
Light is dim when the projector is on.
Light is brightened when the projector is in stand-by mode.
VOLUME BUTTONS
Used to adjust volume.
ZOOM BUTTONS
Used to operate power zoom lens....

P-TIMER
MENUAUTO IMAGE
MUTE
VOLUME COMPUTER
FOCUS
ZOOM
POWER
FREEZE/NO SHOW
LENS SHIFT
NORMAL
1
2
3
4
5
6
9
7
12
11
1013
14
8
VIDEO
CURSOR
D.ZOOMLASER15
17
18
16
19
24
FRONTSIDE
OPERATION OF THE REMOTE CONTROL
BEFORE OPERATION
LASER POINTER
button
LASER POINTER button
This remote control emits a laser beam light as the Laser
Pointer from the Laser Light Window.
When the LASER POINTER button is pressed, laser light goes
on: when the button is released, light goes off.
Laser light is emitted with the RED...

25
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
COMPUTER SELECT BUTTON
Used to select computer mode. (Computer 1 or Computer 2 Input)
VIDEO SELECT BUTTON
Used to select video mode. (Video 1 or Video 2 Input)
LAMP POWER ON/OFF BUTTON
Used to turn the projection lamp on or off.
VOLUME BUTTONS
Used to adjust volume.
ZOOM BUTTON
Used to select power zoom lens adjust.
P-TIMER BUTTON
Used to operate the P-TIMER function.
FOCUS BUTTON
Used to select focus adjust.
FREEZE/NO SHOW BUTTON
Used to freeze on-screen image or...

26
Remote Control Battery Installation
Using the Remote Control Unit
16.4
(5 m)
60° 60°
1
Remove the battery
compartment lid.
2
Slide the batteries into the
compartment.
3
Replace the compartment lid.
Note :For correct polarity (+ and -
terminal), be sure the battery
terminals are in contact with the
pins in the compartment.
Point the remote control toward the projector (Receiver window) whenever pressing the buttons. Maximum operating range
for the remote control is about 16.4 (5m) and 60° front and...

WIRED REMOTE JACK
When using the wired remote control, connect the remote
cable to this jack.
COMPUTER SELECT BUTTON
Used to select computer mode.
(Computer 1 or Computer 2 Input)
VIDEO SELECT BUTTON
Used to select video mode. (Video 1 or Video 2 Input)
LAMP POWER ON/OFF BUTTON
Used to turn projection lamp on or off.
VOLUME BUTTONS
Used to adjust volume.
ZOOM BUTTONS
Used to operate power zoom lens.
FOCUS BUTTONS
Used to operate power focus system.
SOUND MUTE BUTTON
Used to mute sound.
LENS SHIFT...

28
60°
R/C JACKSERIAL PORT
OPENOPEN
Connect a remote control cable to R/C jacks located on the wireless/wired
remote control unit and the side of the projector.
60° The remote control unit can be used as wireless or wired remote control.
WIRED REMOTE
CABLE
1
Remove the battery
compartment lid.
2
Slide the batteries into the
compartment.
3
Replace the compartment lid.
Note :For correct polarity (+ and -
terminal), be sure the battery
terminals are in contact with the
pins in the compartment.
Point the...

ADJUST ITEM
29
The projector has two types of operation: DIRECT OPERATION and MENU OPERATION. DIRECT OPERATION allows you
to operate the projector by using one button without showing the MENU. In MENU OPERATION mode, you display menus
where you can adjust the projectors settings. Follow the instruction for each control.
DIRECT OPERATION
WIRELESS/WIRED
REMOTE CONTROLWIRELESS
REMOTE CONTROL
LAMP POWER ON/OFFLAMP POWER ON-OFF LAMP POWER ON-OFF LAMP POWER ON-OFF
MODE
COMPUTER
VIDEOCOMPUTER
VIDEO
VOLUME (+)...

30
BEFORE OPERATION
WIRELESS
REMOTE CONTROL
COLOR SYSTEM
WIRELESS
REMOTE CONTROL
ADJUST ITEM
MODE SELECTWIRELESS
REMOTE CONTROL
SOUND
SOUND VOLUME
TREBLE
BASS
BUILT-IN SP.
SOUND MUTE
WIRELESS/WIRED
REMOTE CONTROL
MENU
POINT LEFT/RIGHT
SELECT
POINT UP/DOWN
SELECTMENU
POINT LEFT/RIGHT
SELECT
POINT UP/DOWN
SELECTMENU
POINT (LEFT/RIGHT)
SELECT (REAR CLICK)
POINT (UP/DOWN)
SELECT (REAR CLICK) TOP CONTROL OF
THE PROJECTOR
1. COMPUTER/VIDEO MODE
2. VIDEO MODE
MENU OPERATION
ADJUST  ITEMWIRELESS/WIRED
REMOTE...
