Sega Harley Davidson Std Type Service Manual

58
Reinstall Fiber Lid to the original position.
Take out the 2 screws, unlock and remove the Front
Door, and the Shield Case appears. the communica-
tion cable insertion connector is with the Filter Board
in front of the Shield Case. Take off the Cap from the
connector and insert the communication cable.6
7

59
EXAMPLE OF HOW CABINETS SHOULD BE SET UP FOR COMMUNICATION PLAY

60
Install joint parts used to join interactive play machines together.
Loosen the hexagon bolt on the lower rear of the cabinet. Loosen the hexagon bolt onthe side where
machines are to be linked for communication play.
Insert the notch portion of the lower joint to the loosened hexagon bolt and retighten the hexagon bolt.
8
9

61
As in the rear of the cabinet, loosen the
hexagon bolt of the side where the lower
joint in front of the cabinet is to be in-
stalled.
Insert the Joint Plate’s notch portion
to the loosened hexagon bolt and
retighten the hexagon bolt. At this
time, align the Joint Plate’s hole and
the lower joint’s screw hole, then
retighten the hexagonal bolt.
Secure the joint Plate and Lower Joint
with the 2 hexagon bolts.10
11
12

62
Remove the Shipping Hook
Bracket from the side where the
Joint Parts are to be installed.
Secure the Upper joint by using
the 2 hexagon bolts which
secured the Shipping Hook
Bracket.
Remove the 2 screws out of a total
of 4 screws, which secure the
Lamp Holder, from the rear side
and utilize these to install the POP
HOLDER.13
14
15

63
In the similiar manner shown as on the previous page, connect the communication cable for the other machine and
install joint parts.
By using 2-sided tape, install the POP PANEL to the POP HOLDER installed for the adjoining machines.16
17

64
During communication play, if communication is interrupted due to a certain
cause, ERROR MESSAGE will be displayed, then NETWORK check mode appears on
the screen automatically.
Cause all of the seats to enter the Test Mode and change the NETWORK ASSIGNMENTS of each seat for communica-
tion play. For the Changing procedure, refer to the explanations of Section 7.
Press the TEST  button to enter the test mode and choose “NETWORK ASSIGNMENTS”.
Bring the arrow to COMMUNICATION and select “NETWORK”.
Bring...

65
With the communication play setting, NETWORK check is executed when the power is turned on or the test mode is
exited.
During the network check, the screen shown right
will be displayed. If communication play setting and
communication cable connection are correct, the
Game mode (the ADVERTISE MODE) is
displayedand the network check is finished.
If communication play setting error or communica-
tion cable error is found, the screen shown right
appears. Press the TEST BUTTON to enter the TEST
MODE....

66
17 .  DESIGN RELATED PARTS
ITEM NO.PART NO. DESCRIPTION
1 4230-0318-91 BILLBOARD PLATE HLD STD
2 HLD0-1110X STICKER CABI L
3 HLD0-1111X STICKER CABI R
4 4220-0654 PLAY INSTR HLD STD A
5 4220-0655-91 PLAY INSTR HLD STD B
6 4220-0656-91 SUB INSTR HLD STD
7 HLD0-1117 STICKER CABI FRONT L
8 HLD0-1118 STICKER CABI FRONT R
9 HLD0-1104-A STICKER MASK COVER L
10 HLD0-1104-BX STICKER MASK COVER R
11 HLD0-1082-B STICKER FUEL TANK A
12 HLD0-1082-C STICKER FUEL TANK B
13 HLD0-1082-DX STICKER TANK L
14...

67
18 .  PARTS LIST
TOP ASSY HARLEY-DAVIDSON STD
