Sony Mzn10 Portable MiniDisc Recorder Operations Manual

31
5Press and slide zREC.
6Play the source you want to record.
To stop recording
Press x.
The recorder keeps the setting of the
recording mode when you record the next
time.
zAudio components that support the LP2 stereo
or LP4 stereo modes are indicated by the
 or   logo marks.
NotesIt is recommended that you use the AC power
adaptor for long recordings.
When you record in LP4 mode, momentary
noise may be produced on very rare occasions
with certain sound sources. This is because of
the special...

32
Recording from a
microphone
1Connect the stereo microphone to the
MIC (PLUG IN POWER) jack.
The recorder changes to microphone
input automatically.
2Press and slide zREC to start
recording.
To select microphone
sensitivity
1While the recorder is recording or
stopped, press the jog dial.
2Turn the jog dial until “REC SET”
appears in the display, and then press
the jog dial.
3Turn the jog dial until “MIC SENS”
appears in the display, and then press
the jog dial.
4Turn the jog dial until “SENS...

33
Adding track marks
while recording
You can add track marks (track number)
while recording to divide the material into
separate parts.
Adding track marks manually
1While the recorder is recording, press
T MARK (press P MODE/  on the
remote control).
Adding track marks
automatically (Auto Time
Stamp)
Use this feature to add track marks
automatically at specified intervals when
recording through the analog input
connector or a microphone. This function
is convenient for recording long period...

34
z“T” appears before the time display on the
recorder for track marks added by Auto Time
Stamp, and “T” appears after the time display
on the remote control.
NotesIf you add a track mark by pressing T MARK
or X, etc. while recording, Auto Time Stamp
will begin automatically adding track mark
each time the selected time interval as elapsed.
The setting will be lost when the recording
stopped.
Adjusting the recording
level manually
The sound level is adjusted automatically
while recording. If...

35
Various ways of playback
This section explains the operations that
are done on the remote control. For details
on operations done on the recorder, see
the pages indicated for each operation.
Viewing various
information
You can check the track name, disc name,
etc. during playback. Group-related items
appear only when a track with group
settings is played.
1While playing, press DISPLAY.
Each time you press DISPLAY, the
display changes as follows.
Display window on the remote control
Display:...

36
Selecting the play
mode
You can select the various play modes
using the P MODE/  button.
1Press P MODE/  repeatedly.
Each time you press the button, the
play mode changes as follows:
Playing a track repeatedly
(Repeat Play)
You can use the repeat function for
normal play, single-track play, shuffle
play, and program play mode.
1While playing in the selected play
mode, press P MODE/  for 2
seconds or more.
 appears in the display.
To cancel repeat play
Press P MODE/  for 2 seconds or more.
zBy...

37
Listening to selected tracks
only (Bookmark Play)
You can bookmark tracks on a disc and
play them only. The sequence of
bookmarked tracks cannot be changed.
To bookmark the tracks
1While playing the track you want to
bookmark, press the jog lever for 2
seconds or more.
The first track of the bookmark play
is set.
2Repeat step 1 to bookmark the other
tracks.
Bookmarks can be set up to 20 tracks
in a disc.
To play the bookmarked tracks
1While playing, press P MODE/
repeatedly until “ TrPLAY?”...

38
Adjusting the sound
(Virtual-Surround  6-
Band Equalizer)
You can vary the virtual sound to create
different acoustics, or modify the sound to
suit your taste and store it for later use.
The following two effect can be selected.
V-SUR (Virtual-Surround VPT
Acoustic Engine)
Provides 4 kinds of virtual surround
conditions.
6-BAND EQUALIZER
Provides 6 different sound qualities.
Varying the virtual sound to
create different acoustics
(Virtual-Surround)
1While playing, press SOUND
repeatedly to...

39
To modify and store the sound
You can modify the sound and store the
results in “CUSTOM1” and
“CUSTOM2”.
1Do steps 1 to 3 of “Selecting the sound
quality (6-Band Equalizer)” (page 38), and
slide the jog lever until “CUSTOM1” or
“CUSTOM1” appears.
2Press the jog lever.
3Slide the jog lever repeatedly to select the
frequency.
4Turn the volume control repeatedly to adjust
the level.
5Repeat steps 3 and 4 to adjust the level for
each frequency.
6Press the jog lever to enter the selection.
To...

40
To return to the preceding
setting
Press x.
zOnce you open the lid, the playback speed
reverts to the normal speed (0%).
NoteWhen using digital pitch control, you may hear
noise or an echo in the playback.
For the recorder operation, see
page 67.
Setting the alarm
(Melody Timer)
The alarm is convenient way to remind
yourself of important times, such as when
to get off the train. The alarm can be set to
go off in 1 to 99 minutes. The alarm will
also go off while the recorder is stopped.
1Press...
