Sony Mzn10 Portable MiniDisc Recorder Operations Manual

41
6Slide the jog lever repeatedly to select
the elapsed time.
Each time you slide the jog lever, the
elapsed time setting (TIME :)
changes by 1 minute, within a range
of 1 to 99 minutes.
7Press the jog lever to enter the setting.
The time remaining until the alarm is
shown in the display while the
recorder is stopped.
To cancel the procedure
Press x for 2 seconds or more.
To return to the preceding
setting
Press x.
To check the time remaining
until the alarm
Stop playback. The remaining time...

42
Connecting to a stereo
system (LINE OUT)
You can listen to the playback sound from
connected component. Connect the i/
LINE OUT jack of the recorder to the
LINE IN jacks of an amplifier or a tape
player with a line cable.
When connecting a line cable to the i/
LINE OUT jack of the recorder, be sure to
set the “AUDIO OUT” parameter for the
i/LINE OUT jack.
1Press the jog dial.
2Turn the jog dial until “USEFUL”
appears in the display, and then press
the jog dial.
3Turn the dial until “AUDIO...

43
Editing recorded tracks
This section explains the operations that
are done on the recorder. For details on
operations done on the recorder, see the
pages indicated for each operation.
Before editing
You can edit your recordings by adding/
erasing track marks or labeling tracks and
MDs.
NotesPremastered MDs cannot be edited.
Close the record-protect tab on the side of the
MD before editing
When “TOC Edit” is flashing, the editing
results are being recorded.
—Do not move or jog the recorder....

44
Labeling
You can label a track or disc while the
recorder is stopped, recording or playing.
Note that if you label a track while the
recorder is stopped, the track must be the
currently selected.
1Press the jog dial.
2Turn the jog dial until “EDIT”
appears in the display, and then press
the jog dial.
3Turn the jog dial until “Name”
appears in the display, and then press
the jog dial.
4Turn the jog dial until the following
item appears in the display, and then
press the jog dial.
The cursor...

45
7Repeat step 6, and then enter all
characters of the label name.
8Press the jog dial for 2 seconds or
more.
A track or disc is labeled.
NoteWhen the recording is stopped while labeling a
track or a disc during recording, or when the
recording moves on to the next track while
labeling a track, the input at that point is entered
automatically.
Re-labeling
You can change the label of the disc or a
track by doing the procedure for
“Labeling a track or a disc (Name)”
(page 43).
To re-label a...

46
Moving recorded tracks
(Move)
You can change the order of the recorded
tracks.
NoteTo move tracks in a disc with group settings,
see page 55.
Example
Move track C (track number 3) from the
third to the second track.
1While playing the track you want to
move, press the jog dial.
2Turn the jog dial until “EDIT”
appears in the display, and then press
the jog dial.
The recorder plays the selected track
repeatedly.
3Turn the jog dial until “Move”
appears in the display, and then press
the jog...

47
Dividing a track (Divide)
You can divide a track with a track mark,
creating a new track from the part
following the track mark. You can also
make fine adjustments to the track mark
position before making the actual
division. The track numbers will increase
as follows.
This function can be set with the recorder
only.
NoteYou cannot add a track mark on a track that has
been checked-out from your computer.
Dividing a track directly
1While playing or pausing an MD,
press T MARK on the recorder...

48
To add track marks while
recording (except while
synchro-recording)
Press T MARK on the recorder
(P MODE/  on the remote control) at
the point you want to add a track mark.
You can use Auto Time Stamp to add
track marks automatically at specified
intervals (except while digital recording)
(page 33).
Combining tracks
(Combine)
When you record with analog (line) input,
unnecessary track marks may be recorded
where recording level is low. You can
erase a track mark to combine the tracks...

49
To erase a track
Note that once a recording has
been erased, you cannot retrieve it.
Make sure of the track you are
erasing.
1While playing the track you want to
erase, press the jog dial.
2Turn the jog dial until “EDIT”
appears in the display, and then press
the jog dial.
3Turn the jog dial until “Erase”
appears in the display, and then press
the jog dial.
4Turn the jog dial until “ : Erase”
appears in the display, and then press
the jog dial.
“Erase OK?” and “PushENTER”
appear in the...

50
Using the group function
What is the group
function?
The group function is provided to allow
playback of discs with group settings. The
group function is convenient for playback
of MDs on which several albums or CD
singles have been recorded in MDLP
(LP2/LP4) mode.
What is a disc with group
settings?
The recorder can operate various
functions in units of group; that is tracks
that have been recorded on a disc as part
of separate groups, as shown below.
You can create a maximum of 99 groups...
