Steinberg Cubase Essential 4 Operation Manual

211
MIDI realtime parameters and effects
MIDI Sends section
This allows you to add up to four MIDI send effects. Unlike
audio send effects, you can select and activate send ef-
fects individually for each track. The section contains the
following items:
ÖEffects that display their controls in the Inspector can
be opened in a separate control panel window by press-
ing [Alt]/[Option] and clicking the Edit button.
About presets
Several of the MIDI plug-ins come with a number of pre-
sets for instant...

212
MIDI realtime parameters and effects
Applying a MIDI insert effect – an example
Here is a step-by-step example of how to add a MIDI in-
sert effect to a MIDI track:
1.Select the MIDI track and open the Inspector.
2.Open the MIDI Inserts tab in the Inspector.
3.Click in one of the insert slots to open the MIDI effect
pop-up menu.
4.Select the desired MIDI effect from the pop-up menu.
The effect is automatically activated (the power button for the insert slot
lights up) and its control panel appears,...

22
MIDI processing and quantizing

214
MIDI processing and quantizing
Introduction
This chapter describes the various MIDI processing func-
tions available on the MIDI menu. They offer various ways
to edit MIDI notes and other events, either in the Project
window or from within a MIDI editor.
MIDI functions vs. MIDI modifiers
In some cases, the result of a MIDI function can also be
obtained by using MIDI modifiers and effects (see “MIDI
realtime parameters and effects” on page 205). For exam-
ple, the operations “Transpose” and...

215
MIDI processing and quantizing
Setting up quantize on the toolbar
At its most basic, setting up quantizing consists of select-
ing a note value from the Quantize pop-up menu on the
toolbar (in the Project window or a MIDI editor).
This allows you to quantize to exact note values (straight,
triplet or dotted notes) only.
Setting up quantize in the Quantize Setup
dialog
If you want more options than those available on the pop-
up menu, select “Quantize Setup…” from the MIDI menu
(or “Setup…” from...

216
MIDI processing and quantizing
The Quantize Setup dialog contains the following settings:
The Grid and Type pop-ups
These are used to determine the basic note value for the
quantizing grid. In other words, these have the same func-
tionality as the Quantize pop-up menu on the toolbar.
Swing
The Swing slider is only available when a straight note
value is selected for the grid and Tuplet is off (see below).
It lets you offset every second position in the grid, creating
a swing or shuffle feel....

217
MIDI processing and quantizing
The Non Quantize setting
This additional setting affects the result of the quantizing. It
allows you to set a “distance” in ticks (120ths of sixteenth
notes).
Events that already are within the specified distance from
the quantize grid will not be quantized. This allows you to
keep slight variations when you quantize, but still correct
notes that are too far from the grid.
The Random Quantize setting
This additional setting affects the result of the quantizing. It...

218
MIDI processing and quantizing
Advanced Quantize functions
Quantize Lengths
This function (on the Advanced Quantize submenu on the
MIDI menu) will quantize the length of the notes, without
changing their start positions. At its most basic level, this
function will set the length of the notes to the Length
Quantize value on the MIDI editor toolbar. However, if you
have selected the “Quantize Link” option on the Length
Quantize pop-up menu, the function will resize the note
according to the...

219
MIDI processing and quantizing
Scale Correction
Scale Correction transposes the selected notes by for-
cing them to the closest note of the selected scale type.
This can be used for creating interesting key and tonal
changes, either by itself or in conjunction with the other
settings in the Transpose dialog.
To activate Scale Correction, click the checkbox.
Select a root note and scale type for the current scale
from the upper pop-up menus.
Select a root note and scale type for the new scale from...

220
MIDI processing and quantizing
When you record several MIDI channels at the same
time.
You may for example have a MIDI keyboard with several keyboard zones,
where each zone sends MIDI on a separate channel. Recording on an
“Any” channel track allows you to play back the recording with different
sounds for each zone (since the different MIDI notes play back on sepa-
rate MIDI channels).
When you have imported a MIDI file of Type 0.
MIDI files of Type 0 contain only one track, with notes on up to...
