Steinberg Cubase Essential 4 Operation Manual

221
MIDI processing and quantizing
You can specify the desired gap or overlap with the “Legato
Overlap” setting in the Preferences (Editing–MIDI page).
When using Legato with this setting, each note will be extended to end
5 ticks before the next note.
When you activate “Legato Mode: Selected Only”, the
length of the note will be adjusted so that it reaches the
next selected note, allowing you e.g. to only apply Legato
to your bass line (when playing on a keyboard).
Fixed Lengths
This function...

222
MIDI processing and quantizing
OK and Cancel
Clicking OK performs the automatic delete according to
the rules set up. Clicking Cancel closes the dialog without
deleting notes.
Restrict Polyphony
Selecting this item opens a dialog in which you can spec-
ify how many “voices” should be used (for the selected
notes or parts). Restricting the polyphony this way is use-
ful when you have an instrument with limited polyphony
and want to make sure all notes will be played. The effect
is achieved by...

223
MIDI processing and quantizing
Extract MIDI Automation
This option allows you to automatically convert continuous
controller data of a MIDI part into MIDI track automation
data. Proceed as follows:
1.Select the desired MIDI part containing the continuous
controller data.
2.Select “Extract MIDI Automation”. (This command is
also available on the Key Editor context menu.)
The controller data will automatically be removed from the controller lane
in the editor.
3.In the Project window, open the...

23
The MIDI editors

225
The MIDI editors
Introduction
There are several ways to edit MIDI in Cubase Essential.
You can use the tools and functions in the Project window
for large-scale editing, or use the functions on the MIDI
menu to process MIDI parts in various ways (see “What is
affected by the MIDI functions?” on page 214). For
hands-on graphical editing of the contents of MIDI parts,
you use the MIDI editors:
The Key Editor is the default MIDI editor, presenting
notes graphically in an intuitive piano...

226
The MIDI editors
ÖNote that it is also possible to activate a part by select-
ing an event within this part with the Arrow tool.
The button “Edit Active Part Only” lets you restrict edit-
ing operations to the active part only.
For example, if you select “All” from the Select submenu on the Edit menu
with this option activated, only events in the active part will be selected.
Similarly, if you select notes by dragging with the Arrow tool (making a se-
lection rectangle), only the notes in the...

227
The MIDI editors
The Key Editor – Overview
The toolbar
As in other windows, the toolbar contains tools and vari-
ous settings. You can specify which toolbar items should
be shown and store/recall different toolbar configurations
– see “The Setup dialogs” on page 314.
The info line
The info line shows information about selected MIDI
notes. You can edit all values on the info line using regular
value editing (see “Editing on the info line” on page 235
for details). Length and position values are...

228
The MIDI editors
The ruler
The ruler shows the time line, by default in the display for-
mat selected on the Transport panel. You can select a
separate format for a MIDI editor ruler on the Ruler pop-up
menu, opened by clicking the arrow button to the right of
it. For a list of the available formats, see “The ruler” on
page 21.
At the bottom of the pop-up menu, there are two addi-
tional items:
If “Time Linear” is selected, the ruler, note display and
controller display will be linear in...

229
The MIDI editors
To change the size of the controller display, drag the di-
vider between the controller display and the note display.
This will make the controller display larger and the note
display smaller, or vice versa.
Velocity values are shown as vertical bars in the controller
display, with higher bars corresponding to higher velocity
values:
Each velocity bar corresponds to a note in the note display.
Events in the controller display (that is, anything other than
velocity values) are...

230
The MIDI editors
By default, the Trim tool will cut off the end of notes. To
trim the beginning of the note(s), press [Alt]/[Option] while
dragging.
If you press [Ctrl]/[Command] while dragging, you will
get a vertical trim line, allowing you to set the same start or
end time for all edited notes.
You can change the Trim tool key commands in the Pref-
erences (Editing–Tool Modifiers page).
ÖNote that when you trim the beginning of a note in the
List Editor, the note may move to a different...
