Steinberg Cubase Essential 4 Operation Manual

31
The Project window
Audio and MIDI parts can also be duplicated by press-
ing [Alt]/[Option] + [Shift] and dragging.
This creates a shared copy of the part. If you edit the contents of a
shared copy, all other shared copies of the same part are automatically
edited in the same way.
Shared copies are indicated by showing the name in italic text and an
icon in the right corner of the part.
Note:
When you duplicate audio events, the copies are al-
ways shared. This means that shared copies of audio...

32
The Project window
Select “Split at Cursor” from the Edit menu.
This splits the selected events at the position of the project cursor. If no
events are selected, all events (on all tracks) that are intersected by the
project cursor will be split.
Select “Split Loop” from the Edit menu.
This splits events on all tracks at the left and right locator positions.
ÖIf you split a MIDI part so that the split position inter-
sects one or several MIDI notes, the result depends on the
option “Split MIDI...

33
The Project window
You can also resize events with the Scrub tool.
This works just the same as when resizing with the Arrow tool, but the
audio under the pointer is played back (scrubbed) while you drag.
It is also possible to resize events by using the Trim but-
tons (located in the Nudge palette) on the toolbar.
This will move the start or end position of the selected Event(s) by the
amount set on the Grid pop-up menu. The sizing type currently selected
applies to this method too, with the...

34
The Project window
Grouping Events
Sometimes it is useful to treat several events as one unit.
This can be done by grouping them: Select the events (on
the same or different Tracks) and select “Group” from the
Edit menu.
Grouped events are indicated by a group icon in the right corner.
If you edit one of the grouped events in the Project window,
all other events in the same group are affected too (if appli-
cable).
Group editing operations include:
 Selecting events.
 Moving and duplicating...

35
The Project window
To mute or unmute several events, select them – either
by using the standard selection techniques, or by using
one of the options on the Select submenu on the Edit
menu – and click on one of the selected events with the
Mute tool.
All selected events will be muted.
You can also click in an empty area with the Mute tool
and drag a selection rectangle around several events you
want to mute or unmute, and then click on one of them
with the Mute tool.
You can mute events by...

36
The Project window
When the Range Selection tool is selected, the Select
submenu on the Edit menu has the following items for
making selection ranges:
Double-clicking on an event with the Range Selection
tool creates a selection range encompassing the event.
If you hold down [Shift] you can double-click several events in a row, and
the selection range will expand to encompass them all. Double-clicking a
second time on an event opens it for editing in the Sample Editor.
Adjusting the size of the...

37
The Project window
Making selection ranges for several non-contiguous
tracks
You can create selection ranges that cover several tracks
by pressing [Alt]/[Option]+[Shift]. However, it is also pos-
sible to exclude tracks from a selection range:
1.Create a selection range from the first to the last de-
sired track.
2.Press [Alt]/[Option] and click in the selection range on
the tracks you want to exclude from the selection.
3.In the same manner, you can add a track to the selec-
tion range by...

38
The Project window
Other functions
On the Range submenu on the Edit menu, you will find
three more range editing functions:
Options
Snap
The Snap function helps you to find exact positions when
editing in the Project window. It does this by restricting
horizontal movement and positioning to certain positions.
Operations affected by Snap include moving, copying,
drawing, sizing, splitting, range selection, etc.
You turn Snap on or off by clicking the Snap icon in the
toolbar.
Snap activated....

39
The Project window
Grid Relative
When you move events and parts in this mode they will not
be “magnetic” to the grid. Rather, the grid determines the
step size for moving the events. This means that a moved
event will keep its original position relative to the grid.
For example, if an event starts at the position 3.04.01 (one
beat before bar 4), Snap is set to Grid Relative and the
Grid pop-up is set to “Bar”, you can move the event in
steps of one bar – to the positions 4.04.01, 5.04.01 and
so...

40
The Project window
Autoscroll
Autoscroll activated
When this option is activated, the waveform display will
scroll during playback, keeping the project cursor visible
in the window.
If the option “Stationary Cursors” is activated in the
Preferences (Transport page), the project cursor will be
positioned in the middle of the screen (if possible).
