Steinberg Cubase Essential 4 Operation Manual

4
Playback and the Transport panel

42
Playback and the Transport panel
Background
This chapter describes the various methods available for
controlling Playback and Transport functions in Cubase
Essential.
The Transport panel
Below you can find a brief description of each item on the
Transport panel.
The pictures below show the Transport panel with all con-
trols visible and in their default position. The Transport
panel is divided into sections, from left to right.
ÖNote that the Output Activity and Clipping indicator as
well as the...

43
Playback and the Transport panel
Hiding and showing the Transport Panel
The Transport panel is shown by default when you launch
a new project. To hide or show it, select “Transport Panel”
on the Transport menu (or use a key command – by de-
fault [F2]).
About Preroll and Postroll
These items are described in the chapter “Recording”,
see “About Preroll and Postroll” on page 59.
Changing the Transport panel setup
You can customize the appearance of the Transport panel
by right-clicking anywhere on...

44
Playback and the Transport panel
ÖThere are also numerous key commands available for
moving the project cursor (in the Transport category in the
Key Commands dialog).
For example, you can assign key commands to the “Step Bar” and “Step
Back Bar” functions, allowing you to move the project cursor in steps of
one bar, backwards and forwards.
About the Transport panel display formats
Primary time display (left) and secondary time display (right).
The time unit shown in the ruler can be independent...

45
Playback and the Transport panel
You can also adjust the locators numerically on the
Transport panel.
Clicking the L/R buttons in the locator section on the Transport panel will
move the project cursor to the respective locator. If you press [Alt]/[Op-
tion] and click the L or R button, the corresponding locator will be set to
the current project cursor position.
Options and Settings
The “Return to Start Position on Stop”
preference
This setting is found on the Transport page in the Prefer-
ences...

46
Playback and the Transport panel
You now play back the song. It begins with the piano
sound and then switches to the string sound. In the middle
of the chorus you stop and rewind to some point between
the beginning and the second program change. The synth
will now still play the string sound although in this section
it really should be a piano!
The Chase function takes care of that. If program change
events are set to be chased, Cubase Essential will track
the music back to the beginning, find...

5
Recording

48
Recording
Background
This chapter describes the various recording methods
that you can use in Cubase Essential. As it is possible to
record both audio and MIDI tracks, both recording meth-
ods are covered in this chapter.
Before you start
This chapter assumes that you are reasonably familiar with
certain basic recording concepts, and that the following
initial preparations have been made:
You have properly set up, connected and calibrated
your audio hardware.
You have opened a project and set...

49
Recording
Activating recording in Sync mode
If you are synchronizing the Cubase Essential transport to
external equipment (Sync is activated on the Transport
panel) and you activate recording, the program will go into
“record ready” mode (the record button on the Transport
panel will light up). Recording then starts when a valid
timecode signal is received (or when you click the Play
button). See the chapter “Synchronization” on page 278
for more information.
Automatically activating recording...

50
Recording
Audio pre-record
This feature allows you to capture up to 1 minute of any in-
coming audio you play in Stop mode or during playback,
“after the fact”. This is possible because Cubase Essential
can capture audio input in buffer memory, even when not
recording.
Proceed as follows:
1.Open the Preferences (Record-Audio page).
2.Specify a time (up to 60 seconds) in the “Audio Pre-
Record Seconds” field.
This activates the buffering of audio input, making Pre-Record possible.
3.Make sure an...
