Stiga Lawn Mower 8214-2211-80 Silex 40-G Silex 40R-G Silex 50-G Silex 50-H Silex 50R-B Instructions Manual

STIGA
Silex 40-G
Silex 40R-G
Silex 50-G
Silex 50-H
Silex 50R-B
8214-2211-80
BRUKSANVISNING
KÄYTTÖOHJEET
BRUGSANVISNING
BRUKSANVISNING
GEBRAUCHSANWEISUNG
INSTRUCTIONS FOR USE
MODE D’EMPLOI
GEBRUIKSAANWIJZING
ISTRUZIONI PER L’USO
INSTRUCCIONES DE USO
INSTRUÇõES DE UTILIZAÇÃO
INSTRUKCJA OBS£UGI
»HC“P”K÷»fl œOÀ‹«Œ¬¿“EÀfl
NÁVOD K POU®ITÍ
HASZNÁLATI UTASÍTÁS
NAVODILA ZA UPORABOSV .... 4
FI ... 11
DA .. 18
NO . 23
DE ... 30
EN... 40
FR.... 47
NL... 55
IT..... 63
ES .... 71
PT ... 79
PL .... 87
RU... 95
CZ 104
HU...

2
ABCD
F
G
KL
O
RKL
MN
E
JST
PH
Q
U
W
R ST
Q
U
V
X
1
23

3
AB
C
D
EG
12
34
4
6
85
7

40
ENGLISHGB
1 SYMBOLS
The following symbols can be found on the rotary
cultivator/in these instructions. These will provide
a reminder of the care and attention that is required
during operation. If any symbol is missing, has
been damaged or is illegible, it must immediately
be replaced with a new one.
This is what the symbols mean:
Warning! Read the owner’s manual before
operating the machine.
Warning! Rotating blade.
Warning! This symbol highlights impor-
tant text in these instructions. Risk of...

41
ENGLISHGB
• The carbon monoxide in the engines exhaust
fumes is poisonous and can cause death.
• Wear tightly fitting clothes and heavy-duty
shoes which completely cover the feet.
• The tank should only be half full when operat-
ing on slopes. Petrol can leak out.
• The engine must be stopped in the following
circumstances:
• When the machine is left unattended
• Before the machine is filled up with petrol
• Always make sure you have a good footing, es-
pecially on slopes.
• Check that no one...

42
ENGLISHGB
3.4 Throttle controlInstall the throttle on the left handle according to
fig. 6.
3.5 Throttle cable1. Install the throttle cable on the engine if not al-
ready installed. See the engine supplier’s man-
ual.
2. Pull up the cable under the support’s (4:U) up-
per section over the screw (5:C).
3. Install the cable in the throttle. See fig. 7.
4. Install the electric cable to the stop control
which is located on top of the throttle.
3.6 Cable for reverse controlOnly applies to 40R-G and...

43
ENGLISHGB
4.9 Handle height adjustment (1:G)Slacken off the knobs and set the handle to a com-
fortable height.
Then retighten the knobs again.
4.10 Oil filling/drainingAlways check the oil level before start-
ing the engine.
Plug for oil filler and checking the oil level.
To drain the oil, the machine must be tilted so that
the oil runs out from the same hole.
The plug is shown according to the table below:
4.11  Auxiliary wheel (1:T)The auxiliary wheels are designed to facilitate
transportation of...

44
ENGLISHGB
5 OPERATION
5.1 Fuel
Read and understand all safety instruc-
tions.
No fires or smoking near to petrol.
Use 92-95 octane lead free petrol.
Oil-mixed petrol designed for 2-stroke engines
must never be used.
Filling
Read and understand all safety instruc-
tions.
If the engine has been running, wait a
few minutes until it has cooled before
filling up.
Fill carefully to prevent the spillage of
fuel.
Move the rotary cultivator at least 3 me-
tres from the filling site before starting.
Fill...

45
ENGLISHGB
6 STORAGE
Store the rotary cultivator in a dry place. Also see
section “Safety instructions”.
After draining the petrol, start the engine and allow
it to run until it runs out of petrol.
7 MAINTENANCE
WARNING!Repairs must be carried out
by the dealer. Otherwise the guarantee
becomes invalid.
WARNING!Before carrying out repairs
and maintenance, the spark plug con-
nection must be disconnected.
7.1 Periodic maintenanceBefore each operation
• Check for fuel leaks.
• Check that all screws...

46
ENGLISHGB
7.4 Changing the oilChange the oil the first time after 2 hours of oper-
ation, and subsequently every 25 hours of opera-
tion or at least once a season. Change oil when the
engine is warm.
The engine oil may be very hot if it is
drained off directly after the engine is
shut off. So allow the engine to cool a few
minutes before draining the oil.
1.  Unscrew the cap for oil filling/oil draining. See
“4.10”.
2.  Place a container on the floor.
3. Tilt the machine so that the hole is above...
