    Page 11

    Page 11 52 ENGLISHEN At each basic service and intermediate service car- ried out at an authorised workshop, the service log is stamped. A service log presenting these services is a valuable document that improves the ma- chine’s second-hand value. 5.2 PreparationAll service and all maintenance must be carried out on a stationary machine with the engine switched off. Prevent the machine from rolling by al- ways applying the parking brake. Stop the engine. Prevent unintentional starting of the engine by...
    52
ENGLISHEN
At each basic service and intermediate service car-
ried out at an authorised workshop, the service log
is stamped. A service log presenting these services
is a valuable document that improves the ma-
chine’s second-hand value.
5.2 PreparationAll service and all maintenance must be carried out
on a stationary machine with the engine switched
off.
Prevent the machine from rolling by al-
ways applying the parking brake.
Stop the engine.
Prevent unintentional starting of the
engine by...

    Page 12

    Page 12 53 ENGLISHEN 7. Remove 2 drain plugs from the front axle. Use a 12 mm socket. Allow the oil in the front axle and pipes to run out. See fig. 12. 8. Clean the filter (11:X) using a suitable solvent and compressed air. 9. Check that the gaskets on the drain plugs of the front axle are intact. See fig. 12. Reinstall the plugs. Tightening torque: 15-17 Nm. The filter plug will be damaged if it is tightened more to than 5 Nm. 10. Check that the gasket on the filter plug of the rear axle is intact. See...
    53
ENGLISHEN
7. Remove 2 drain plugs from the front axle. Use
a 12 mm socket. Allow the oil in the front axle
and pipes to run out. See fig. 12.
8. Clean the filter (11:X) using a suitable solvent
and compressed air.
9. Check that the gaskets on the drain plugs of the
front axle are intact. See fig. 12. Reinstall the
plugs. Tightening torque: 15-17 Nm.
The filter plug will be damaged if it is
tightened more to than 5 Nm.
10. Check that the gasket on the filter plug of the
rear axle is intact. See...

    Page 13

    Page 13 54 ENGLISHEN 5. Stop the engine. The battery will now be fully charged. 5.8.2 Charging using battery charger When charging using a battery charger, a battery charger with constant voltage must be used. Contact your dealer to purchase a battery charger with constant voltage. The battery can be damaged if a standard type battery charger is used. 5.8.3 Removal/Installation The battery is placed under the engine casing. Dur- ing removal/installation, the following applies re- garding connection of the...
    54
ENGLISHEN
5. Stop the engine. The battery will now be fully
charged.
5.8.2 Charging using battery charger
When charging using a battery charger, a battery
charger with constant voltage must be used.
Contact your dealer to purchase a battery charger
with constant voltage.
The battery can be damaged if a standard type
battery charger is used.
5.8.3 Removal/Installation
The battery is placed under the engine casing. Dur-
ing removal/installation, the following applies re-
garding connection of the...

    Page 14

    Page 14 55 ENGLISHEN 5.13 FuseIn the event of electrical faults, check/replace the fuse, 20 A. See 9:S.6 PATENT - DESIGN REGISTRA-TION This machine or parts thereof is covered by the fol- lowing patent and design registration: SE9901091-0, SE9901730-3, SE9401745-6, US595 7497, FR772384, DE69520215.4, GB772384, SE0301072-5, SE04/000239 (PCT), SE0401554-1, SE0501599-5. GGP reserves the right to make alterations to the product without prior notification.
    55
ENGLISHEN
5.13 FuseIn the event of electrical faults, check/replace the
fuse, 20 A. See 9:S.6 PATENT - DESIGN REGISTRA-TION
This machine or parts thereof is covered by the fol-
lowing patent and design registration:
SE9901091-0, SE9901730-3, SE9401745-6,
US595 7497, FR772384, DE69520215.4,
GB772384, SE0301072-5, SE04/000239 (PCT),
SE0401554-1, SE0501599-5.
GGP reserves the right to make alterations to the
product without prior notification.

    Page 15

    Page 15 www.stiga.com GGP Sweden AB · Box 1006 · SE-573 28 TRANÅS
    www.stiga.com
GGP Sweden AB · Box 1006 · SE-573 28 TRANÅS
