5. Nach dem Einfüllen von Öl den Motor starten
und 30 Sekunden lang im Leerlauf arbeiten las-
sen.
6. Das Gerät auf Öllecks überprüfen.
7. Motor ausstellen. 30 Sekunden warten und den
Ölstand gemäß 4.2 kontrollieren.
5.5 Kraftstofffilter (9:Q)Tauschen Sie den Kraftstofffilter jede Saison aus.
Kontrollieren Sie, dass keine Kraftstoffleckage
auftritt, wenn der neue Filter montiert wurde.
5.6 RiemenübertragungÜberprüfen Sie nach 5 Betriebsstunden, ob sämtli-
che Riemen intakt und...

42
DEUTSCHDE
Durch das Vertauschen der Kabel wer-
den Generator und Batterie zerstört.
Ziehen Sie die Kabel fest an. Lose Kabel
können Brände verursachen.
Der Motor darf nie bei getrennter Bat-
terie betrieben werden. Dadurch be-
steht die Gefahr für Schäden an
Generator und elektrischem System.
5.8.4 Reinigung
Oxidierte Batteriepole müssen gereinigt werden.
Verwenden Sie dazu eine Stahlbürste und schmie-
ren Sie die Pole mit Polfett ein.
5.9 LuftfilterDer Vorfilter (Schaumstofffilter) ist alle 25...

43
DEUTSCHDE
6 PATENT- UND MUSTER-
SCHUTZ
Dieses Gerät oder Teile von ihm unterliegen fol-
gendem Patent- und Musterschutz:
9900627-2 (SE), SE00/00250 (PCT), 9901091-0
(SE), SE00/00577 (PCT), 9901730-3 (SE), SE00/
00895 (PCT), 9401745-6 (SE), SE95/00525
(PCT), 595 7497 (US), 95920332.4 (EPC).99 1095
(SE), 499 11 740.9 (DE), M1990 000734 (IT), 577
251-253 (FR), 115325 (US).
GGP behält sich das Recht vor, ohne vorherige An-
kündigung Änderungen am Produkt vorzunehmen.

44
ENGLISHEN
1 GENERAL
This symbol indicates WARNING. Seri-
ous personal injury and/or damage to
property may result if the instructions
are not followed carefully.
You must read these instructions for use
and the accompanying pamphlet
“SAFETY INSTRUCTIONS” careful-
ly, before starting up the machine.
1.1 SYMBOLSThe following symbols appear on the machine.
They are there to remind you of the care and atten-
tion required during use and maintenance.
This is what the symbols mean:
Warning!
Read the...

45
ENGLISHEN
The pedal (2:B) has the follow-
ing three positions:
•Released. The clutch is not activated. The park-
ing brake is not activated.
•Depressed halfway. Forward drive disengaged.
The parking brake is not activated.
•Fully depressed. Forward drive disengaged.
The parking brake is fully activated but not
locked. This position is also used as emergency
brake.
2.4.4 Inhibitor, parking brake (1, 3:C)
The inhibitor locks the “clutch-brake”
pedal in the depressed position. This func-
tion is...

46
ENGLISHEN
NOTE! You must make sure the machine is quite
stationary before changing from reverse to forward
gear or vice versa. If a gear does not engage im-
mediately, release the clutch pedal and then press
it in once again. Engage the gear once again. Never
force a gear in.
2.4.10 Power take-off (2; 4:E)
A lever for engaging and disengaging the power
take-off for operating cutting decks and front-
mounted accessories. Two positions:
1.Forward position – power take-off dis-
engaged.
2. Backward...

47
ENGLISHEN
4 STARTING AND OPERATION
The machine may not be operated un-
less the engine casing is closed and
locked. Risk of burns and crushing in-
juries.
4.1 Filling with petrolAlways use lead-free petrol. You must never use 2-
stroke petrol mixed with oil.
The tank holds 14 litres. The level can easily be
read through the transparent tank.
NOTE! Ordinary lead-free petrol is a perishable
and must not be stored for more than 30 days.
Environmental petrol can be used, i.e. alkylate
petrol. This...

48
ENGLISHEN
5. Starting cold engine – put the throttle control in
the choke position.
Starting warm engine – put the throttle control
at full throttle (approx. 2 cm behind the choke
position).
6.  Depress the clutch-brake pedal fully.
7.  Turn the ignition key and start the engine.
8 Once the engine has started, move the throttle
control gradually to full throttle (approx. 2 cm
behind the choke position) if the choke has been
used.
9. When starting from cold, do not make the ma-
chine work under...

49
ENGLISHEN
5.2 PreparationAll service and all maintenance must be carried out
on a stationary machine with the engine switched
off.
Prevent the machine from rolling by al-
ways applying the parking brake.
Prevent unintentional starting of the
engine by disconnecting the spark plug
cable(s) from the spark plug(s) and re-
moving the ignition key.
5.3 Tyre pressureAdjust the air pressure in the tyres as follows:
Front: 0.4 bar (6 psi).
Rear: 1.2 bar (17 psi).
5.4 Changing engine oilChange engine oil...

50
ENGLISHEN
1. Install the battery in the machine as shown be-
low.
2. Place the machine outdoors or install an extrac-
tion device for the exhaust fumes.
3. Start the engine according to the instructions in
the user guide.
4. Allow the engine to run continuously for 45
minutes.
5. Stop the engine. The battery will now be fully
charged.
5.8.2 Charging using battery charger
When charging using a battery charger, a battery
charger with constant voltage must be used.
Contact your dealer to purchase a...
