Stiga PARK RANGER, PRESIDENT, EXCELLENT Swedish Version Manual

51
DEUTSCHDE
5.8.2 Laden mit Batterieladegerät
Beim Aufladen mithilfe eines Batterieladegeräts
ist ein Gerät mit Konstantspannung zu verwenden.
Hinweise zum Kauf eines Batterieladegeräts mit
Konstantspannung erhalten Sie von Ihrem Fach-
händler.
Bei Verwendung eines Standardladegeräts
kann die Batterie beschädigt werden.
5.8.3 Demontage/Montage
Die Batterie befindet sich unter der Motorhaube.
Bei einer Demontage/Montage gilt Folgendes für
den Anschluss der Kabel:
• Bei der Demontage: Trennen Sie...

52
DEUTSCHDE
5.11 LufteinlassSiehe 10, 11, 12:W. Der Motor ist luftgekühlt. Ver-
stopfungen im Kühlsystem schaden dem Motor.
Der Lufteinlass des Motors ist alle 50 Betriebss-
tunden zu reinigen. Eine gründlichere Reinigung
des Kühlsystems wird bei jedem Grundservice
ausgeführt.
5.12 SchmierungSämtliche Schmierpunkte entsprechend der fol-
genden Tabelle sind alle 50 Betriebsstunden sowie
nach jedem Waschen zu schmieren.
5.13 SicherungenWenn einer der unten aufgeführten Fehler auftritt,
ist die...

53
ENGLISHEN
1 GENERAL
This symbol indicates WARNING. Seri-
ous personal injury and/or damage to
property may result if the instructions
are not followed carefully.
You must read these instructions for use
and the accompanying pamphlet
“SAFETY INSTRUCTIONS” careful-
ly, before starting up the machine.
1.1 SYMBOLSThe following symbols appear on the machine.
They are there to remind you of the care and atten-
tion required during use and maintenance.
This is what the symbols mean:
Warning!
Read the...

54
ENGLISHEN
2.4.3 Inhibitor, parking brake (3:A)
The inhibitor locks the “clutch-brake”
pedal in the depressed position. This func-
tion is used to lock the machine on slopes,
during transport, etc., when the engine is
not running.
The parking brake must always be re-
leased during operation.
Locking:
1. Depress the pedal (3:B) fully.
2. Move the inhibitor (3:A) to the right.
3. Release the pedal (3:B).
4. Release the inhibitor (3:A).
Unlocking:
Press and release the pedal (3:B).
2.4.4...

55
ENGLISHEN
2.4.9 Ignition lock/headlight (4, 5, 6:I)
The ignition lock is used for starting and stopping
the engine. The ignition lock is also the switch for
the headlight.
Do not leave the machine with the key
in position 2 or 3. There is a fire risk,
fuel can run into the engine through the
carburettor, and there is a risk of the
battery being discharged and damaged.
Four positions:
1. Stop position – the engine is short-cir-
cuited. The key can be removed.
2. Operating position – headlight...

56
ENGLISHEN
2.4.16Quick-release mounting (27:H)
The quick connections can be separated,
which makes it very easy to shift between
the different implements.
The quick connections allow the deck to
be moved easily between the two posi-
tions:
• Normal position with fully tensioned belt.
• 4 cm behind the normal position with slackened
belt so that the deck gets closer to the base ma-
chine.
As the belt idler is released from the belt, the quick
connections simplify belt and deck replacement,
and...

57
ENGLISHEN
4.1 Filling with petrolAlways use lead-free petrol. You must never use 2-
stroke petrol mixed with oil.
The tank holds 12 litres. The level can easily be
read through the transparent tank.
NOTE! Ordinary lead-free petrol is a perishable
and must not be stored for more than 30 days.
Environmental petrol can be used, i.e. alkylate
petrol. This type of petrol has a composition that is
less harmful for people and nature.
Petrol is highly inflammable. Always
store fuel in containers that are...

58
ENGLISHEN
4.  Do not keep your foot on the drive pedal.
5. Ranger, President:
Starting cold engine – put the throttle control in
the choke position.
Starting warm engine – put the throttle control
at full throttle (approx. 2 cm behind the choke
position).
Excellent
:Put the throttle control at full throttle.
Starting cold engine – pull the choke control out
fully.
Starting warm engine – the choke control
should be pressed in.
6.  Depress the clutch-brake pedal fully.
7.  Turn the ignition key...

59
ENGLISHEN
Servicing carried out at an authorised workshop
guarantees professional work using genuine spare
parts.
At each basic service and intermediate service car-
ried out at an authorised workshop, the service log
is stamped. A service log presenting these services
is a valuable document that improves the ma-
chine’s second-hand value.
5.2 PreparationAll service and all maintenance must be carried out
on a stationary machine with the engine switched
off.
Prevent the machine from rolling by...

60
ENGLISHEN
5.5 Fuel filterRanger, PresidentReplace the fuel filter every season.
Excellent
Replace the fuel filter after 1,500 hours of opera-
tion.
Check for fuel leaks once the new filter has been
installed.
5.6 Belt transmissionsAfter 5 hours of operation, check that all the belts
are intact and undamaged.
5.7 SteeringThe steering must be checked/adjusted after 5
hours of operation and thereafter after 100 hours of
operation.
5.7.1 Checks
Briefly turn the steering wheel back and forth.
There...
