Toshiba Strata Dk14, Dk40i, Dk424 General Description Manual

PC Attendant Console
PC Attendant Console Features
Strata DK Feature Description 5/99227
Dial Outside Number for Station User
The Attendant can access a CO line and dial an outside destination number for a station user. To
perform this operation, the Attendant must be in the talking state with either a station user, an
outside caller, or a caller on an incoming Tie trunk.
Benefits
Provides convenience and saves time for station users.
System Availability
Optional on Strata DK424 with RCTUBA/
BB,...

PC Attendant Console
PC Attendant Console Features
228Strata DK Feature Description 5/99
Direct Station Selection (DSS)
The Attendant can click on the station DN on the internal directory screen to perform direct station
calling or transfer operation.
Benefits
Provides rapid and easy DSS calling, because the DN and name directory is on-screen. This
provides the convenience and functionality of having a DSS module with the Attendant Console.
System Availability
Optional on Strata DK424 with RCTUBA/
BB,...

PC Attendant Console
PC Attendant Console Features
Strata DK Feature Description 5/99229
Directory Display and Dialing
The directory listing area of the screen can display both names and DNs of internal station users.
The Attendant can point and click on a name or DN, or use the keyboard to automatically dial the
number. These may be accessed using Name Dialing or Department Dialing.
The directory includes each employee’s name and DN. The directory display also includes busy/
idle status of each name...

PC Attendant Console
PC Attendant Console Features
230Strata DK Feature Description 5/99
DTMF Tone Signaling
The Attendant Console can generate DTMF tones from the dial pad to signal external devices such
as voice mail, auto attendants, and answering machines on outgoing calls. This makes the
Attendant Console efficient to use for both outgoing and incoming calls.
Both the Strata DK424 and the PC Attendant Console work with DTMF or dial pulse CO lines.
The Attendant can change the CO line out-dialing...

PC Attendant Console
PC Attendant Console Features
Strata DK Feature Description 5/99231
Emergency Calls
Emergency Calls from internal stations to an Attendant Console always receive the highest answer
priority. They have priority over the first in, first out or priority sequence established in
programming. Emergency calls are initiated by station users by dialing a special number. They
display on the screen in the incoming call area. If the call is placed on hold, the hold time appears
in red to...

PC Attendant Console
PC Attendant Console Features
232Strata DK Feature Description 5/99
Emergency Page
An Attendant Console equipped with an assigned Emergency Page button can page the All Call
Telephone Page Group. The page sounds over the speakers of all idle telephones in the All Call
Page Group, but does not sound over the external paging speakers. An Emergency Page pre-empts
an existing page connection.
Benefits
Provides quick and easy access to station paging, either for emergency situations or...

PC Attendant Console
PC Attendant Console Features
Strata DK Feature Description 5/99233
Employee Profile Information
By typing a name (first, last, or both) or a directory number, the console Attendant can display a
complete profile for an employee. A special search by department can also be used to direct a
caller to the appropriate person available to handle the call. Calls for employees not on-site can
have information displayed on how they can be reached, or the Attendant can use the Transfer to...

PC Attendant Console
PC Attendant Console Features
234Strata DK Feature Description 5/99
Feature Online Help
Feature Online Help provides feature user instructions at the touch of a button or click of the
mouse. This functions the same as other Windows PC applications. Online help provides
information that is more detailed than routine feature prompting Soft Key instructions, but less
detailed than the examples and instructions contained in the PC Attendant Console User Guide.
Online Help is context...

PC Attendant Console
PC Attendant Console Features
Strata DK Feature Description 5/99235
Feature Prompting with Soft Keys
Feature prompting with Soft Key operation provides access to various console features. On-screen
instructions and Soft Key functions and choices change according to the state of the Attendant
Console, making the console easy to use.
Examples:
©Sending a message waiting indication to a station
©Breaking into an ongoing conversation
©Performing a transfer, conference, or voice page...

PC Attendant Console
PC Attendant Console Features
236Strata DK Feature Description 5/99
Flexible Programmable Buttons
The console has 16 buttons on the display screen that can be programmed by the Attendant with a
variety of feature assignments, trunk access, or as Incoming Call (In) buttons.
Benefits
Provides customization by the Attendant. Commonly used functions can be programmed on
flexible buttons to provide one-touch access to these features, making the console easy and
efficient to use.
System...
