Comdial Multi Cell Wireless Telephone Users Guide

Storing Speed
Dial Numbers
9.1 Storing Speed Dial Numbers
You can store up to 70 speed dial numbers in your handset. You can also
edit and delete numbers and names you have already stored.
To store a speed dial number,
1. Enter the number you want to store.
The handset displays the number. If it’s longer than 18 digits, the
display scrolls to another line.
To erase a digit you’ve entered, pressCLR. To erase all digits,
press and holdCLR.
You can dial digits 0–9, *, and #. To enter a one-second pause,...

2. To store a name associated with the number (optional),
A. PressABC.
B. Enter a 1–8 character name. SeeEntering Speed Dial Names
for information on how to enter characters.
C. PressSTO.
D. The handset displays a memory location and asks if you want
to store the number there.
3. PressSTOto accept the memory location, or enter a number
(00–69) and pressSTO.
4. To cancel storing the number, pressEND.
NOTE: You should reserve memory locations 0–9 for numbers you dial
most frequently.
If you enter a memory...

9.2 Entering Names For Speed Dial Numbers
1. Enter the number of the speed dial you wish to assign a name.
2. PressABC.
3. Press the key containing the character/number you want one or
more times until the display contains the character/number.
For example, to enter the letterF, press3 DEFquickly three times.
To enter the number 3, press the same key four times.
To erase a letter, pressCLR; to erase everything you’ve entered,
press and holdCLR.
The following tables explain how to press keys to get...

Other Conventions
Press: To get:
1 once 1
1 twice -
*­*
#¯space
0 0 (zero)
2.
Wait or press#¯to advance to the next letter position before
entering another character.
You can tell when the handset is ready to accept another character
when you see the underscore(_).
9 – 4 MCW Handset User’s Guide
Storing Speed Dial Numbers GCA70–351

To edit a stored speed dial number,
1. Dial a memory location and pressRCL.
—OR—
PressRCLand use the search keys to locate the number you want
to edit.
2. PressABC.
The handset displays the speed dial number.
3. UseCLRto delete digits. Enter the new digits.
4. To edit the name, press ABC, use CLR to delete characters, and
enter a new name (seeEntering Speed Dial Names).
5. When you’re done editing, pressSTO.
To cancel the editing process at any time, pressEND.
To delete a stored speed dial number,
1....

To delete all stored speed dial numbers,
1. In idle mode, dial11, then pressFCN.
2. PressFCN.
3. PressFCNagain to confirm, or pressENDto cancel deleting the
numbers.
To find the number of free memory locations,
1.
Press#¯, then pressRCL.
2.FULLreports the number of locations filled;FREEreports the
number of available locations.
3. Wait or pressEND.
9 – 6 MCW Handset User’s Guide
Storing Speed Dial Numbers GCA70–351

Menu Operation
10.1 Menu Operation
You can configure some aspects of handset operation from the handset
menu.
To find a menu option,
1. In idle mode, pressFCN. Then press the search keys to scroll
through the menu options.
—OR—
In idle mode, dial a menu option number (1–13). Then pressFCN.
Menu options are listed on the next page. Instructions for working with
the various menu options are on the following pages.
CAUTION!
All menu changes, except changes to the idle message, are lost if you
remove the...

10.2 Menu Options
Menu Options Table
1. READ PAGER MSG retrieve pager messages (future)
2. RING TYPE OPTION set ringer type
3. RINGER VOLUME set ringer volume
4. KEY CLICK VOLUME adjust volume of key press beep
5. PAGER VOLUME set page beeper volume (future)
6. TIME FORMAT set time format
7. AUTO ANSWER turn on/off auto-answer
8. DISPLAY CONTRAST set display contrast
9. DISP TEST OPTION test icon display
10. SYSTEM CONFIG. configure system and handset IDs
11. DEL ALL SPEEDDIAL delete all speed dial...

10.3 Setting Ringer Type
1. PressFCN. Then press untilRING TYPE OPTIONSappears
in the display.
—OR—
Press2, then pressFCN.
2. Press FCN until you hear the ringer type you want. (There are
eight ringer types.)
3. PressENDto exit menu mode.
10.4 Setting Ringer Volume
1. PressFCN. Then press untilRINGER VOLUMEappears in
the display.
—OR—
Press3, then pressFCN.
2. PressFCNuntil you hear the ringer volume you want orRINGER
SILENTappears in the display.
3. PressENDto exit menu mode.
MCW Handset User’s Guide 10...

10.5 Setting Keypad Beeper Volume
The Key Click Volume menu option adjusts the volume of a beeper that
sounds when you press a key on the handset.
1. PressFCN. Then press untilKEY CLICK VOLUMEappears
in the display.
—OR—
Press4, then pressFCN.
2. Press FCN until the beeper volume you want orKEY CLICK
SILENTappears in the display.
3. PressENDto exit menu mode.
10.6 Setting Time Format
1. PressFCN. Then press untilTIME FORMATappears in the
display.
—OR—
Press 6, then pressFCN.
2. PressFCNuntil the format...
