Comdial Multi Cell Wireless Telephone Users Guide

10.7 Setting Auto-Answer
In auto-answer mode, the handset automatically connects you with
incoming calls after playing a tone.
1. PressFCN. Then press untilAUTO ANSWERappears in the
display.
—OR—
Press7, then pressFCN.
2. PressFCNuntil the mode you want,AUTO ANSR ONorAUTO
ANSR OFF, appears in the display.
3. PressENDto exit menu mode.
10.8 Setting Display Contrast
The display contrast menu option controls the amount of contrast in the
handset display.
1. PressFCN. Then press untilDISPLAY CONTRASTappears...

10.9 Testing Icon Displays
1. PressFCN. Then press untilDISP TEST OPTIONappears in
the display.
—OR—
Press9, then pressFCN.
2. PressFCNto turn the test on and off.
When the test is off,PRESS FCN FOR TESTappears in the
display. When the test is on, all icons are lit and the display is
filled with boxes.
3. PressENDto exit menu mode.
10.10 Configuring System And Handset IDs
The handset stores up to eight system and associated handset IDs, which
allows it to operate in eight different Air Impact systems....

10.11 Deleting All Speed Dial Numbers
This option deletes all speed dial numbers stored in the handset at once.
1. PressFCN. Then press untilDEL ALL SPEEDDIALappears
in the display.
—OR—
Dial11, then pressFCN.
2. PressFCN.
PRESS FCN TO DELETEappears in the handset display.
3. PressFCNagain to confirm, or pressENDto cancel deleting the
numbers.
4. PressENDto exit menu mode.
MCW Handset User’s Guide 10 – 7
GCA70–351 Menu Operation

10.12 Deleting Last Number Dialed
The handset stores the last number dialed. When you pressCALL, the
handset displays that number. You can use the following procedure to
delete the current last number dialed so that it does not appear when you
pressCALL.
1. PressFCN. Then press untilDEL LAST # DIALEDappears
in the display.
—OR—
Dial12, then pressFCN.
2. PressFCN.
PRESS FCN TO DELETEappears in the handset display.
3. PressFCNagain to confirm, or pressENDto cancel deleting the
number.
4. PressENDto exit...

10.13 Changing The Handset Idle Message
The handset can display a message when it is in idle mode. You can
change or delete this message.
1. PressFCN. Then press untilCHANGE IDLE MSGappears
in the display.
—OR—
Dial13, then pressFCN.
2. PressFCN.
The handset changes to alpha mode.
3. Use the instructions described inEntering Speed Dial Namesfor
entering a new idle message or deleting the existing one.
The message may be up to 18 characters. Note that in idle mode
the second line of the display contains...

This page remains blank intentionally.

Battery Operations
11.1 Battery Operations
When the battery gets low, the handset displays a*LOW BAT*warning
and beeps every 30 seconds in standby mode or every minute in
conversation before shutting off.
MCW Handset User’s Guide 11 – 1
GCA70–351 Battery Operations
11

11.2 Removing And Replacing Batteries
The handset battery is attached to the back panel of the handset as shown
below.
To remove the battery,
1. Power off the handset (to permanently save menu changes and
speed dial numbers added since the last power on).
2. Push the battery release towards the top of the handset and lift out
the battery.
11 – 2 MCW Handset User’s Guide
Battery Operations GCA70–351
Press battery release
towards top of handset
to release battery.

To reattach a battery,
1. Fit the base of the battery into the notches at the base of the
handset.
2. Snap the upper part of the battery in place.
MCW Handset User’s Guide 11 – 3
GCA70–351 Battery Operations
Handset battery
Fit these notches into
handset before
snapping battery into
battery release.Handset base without battery

11.3 Charging Batteries
Handset batteries are Nickel Metal Hydride (NiMH) and support 4 hours
of talk time and 40 hours of standby time (on and available for calls).
The battery charger charges a handset and spare battery. Charging takes
approximately 2 hours.
To charge a battery,
1. Remove the handset carrying case if it has one.
2. Insert handset (power off) with battery in the front pocket of the
charger.
3. Insert spare battery in the rear pocket of the charger.
The front pocket LED changes to amber...
