HP Slate 6 Service Manual

▲
Remove the proximity/light sensor board (1) from the retention mold built into the display
panel assembly.
NOTE:The display panel assembly also contains alignment pins (2) that ensure proper
installation of the proximity/light sensor board.
Reverse this procedure to install the proximity/light sensor board.
Proximity/light sensor board
25

6 Specifications
 Metric U.S.
Dimensions
Width8.32 cm3.28 in
Depth0.90 cm0.35 in
Height16.51 cm6.50 in
Weight (lowest weight configuration)0.16 g0.35 lb
Input power
The voice tablet operates on DC power, which can be supplied by an AC or a DC power source. The AC power source must
be rated at 100—240 V, 50/60 Hz, 0.3-1.0 A.
NOTE:The voice tablet can operate on DC power using an industry-standard micro-A or micro-B USB cable. The HP adapter
included with your voice tablet is recommended for charging the...

7 Backing up and recovering your
data
Updating apps, widgets, and the operating system
HP recommends that you update your apps, widgets, and the operating system on a regular basis to
the latest versions. Updates can resolve issues and bring new features and options to your tablet.
Technology is always changing, and updating apps, widgets, and the operating system allows your
tablet to run the latest technology available. For example, older apps and widgets might not work well
with the most recent...

Factory data reset
To reset all settings and delete all data on the device:
1.
Touch
, and then touch .
2.Under PERSONAL, touch Back up & reset.
3.Under PERSONAL DATA, select Factory data reset, and then follow the on-
screen instructions.
28 Chapter 7   Backing up and recovering your data

8 Power cord set requirements
The wide-range input feature of the tablet permits it to operate from any line voltage from 100 to 120
volts AC, or from 220 to 240 volts AC.
The 3-conductor power cord set included with the tablet meets the requirements for use in the country or
region where the equipment is purchased.
Power cord sets for use in other countries and regions must meet the requirements of the country or
region where the tablet is used.
Requirements for all countries
The following requirements...

Country/region Accredited agency Applicable note number
Germany VDE 1
Italy IMQ 1
Japan METI 3
The Netherlands KEMA 1
Norway NEMKO 1
The Peoples Republic of China COC 5
South Korea EK 4
Sweden CEMKO 1
Switzerland SEV 1
Taiwan BSMI 4
The United Kingdom BSI 1
The United States UL 2
1.The flexible cord must be Type HO5VV-F, 3-conductor, 1.0-mm² conductor size. Power cord set fittings (appliance coupler
and wall plug) must bear the certification mark of the agency responsible for evaluation in the country or...

9 Recycling
When a non-rechargeable or rechargeable battery has reached the end of its useful life, do not dispose
of the battery in general household waste. Follow the local laws and regulations in your area for
battery disposal.
HP encourages customers to recycle used electronic hardware, HP original print cartridges, and
rechargeable batteries. For more information about recycling programs, see the HP Web site at
http://www.hp.com/recycle.
31

Index
A
AC adapter, spare part numbers
7
antenna board
removal 20
spare part number 6, 8, 20
audio, product description 1
audio-in jack 3
audio-out jack 3
B
back cover
removal 13
spare part number 6, 8, 13
battery
removal 14
spare part number 6, 7, 14
bottom speaker
removal 19
spare part number 7, 8, 19
bottom speaker/vibrator module
assembly
removal 19
spare part number 7, 8, 19
buttons
power 3
volume control 4
C
cables, service considerations 9
connectors, service
considerations 9
D
display panel...

networking 1
operating system 2
ports 2
power requirements 2
processors 1
product name 1
sensor 1
serviceability 2
video 1
wireless networking 2
product name 1
proximity/light sensor board
removal 24
spare part number 6, 8, 24
R
rear-facing webcamera
location 3
removal 23
spare part number 6, 8, 23
S
Screw Kit, spare part number 7
sensor, product description 1
service considerations
cables 9
connectors 9
plastic parts 9
serviceability, product description
2
speakers
location 4
removal 19
spare part...
