Mitsubishi XL2 Projector User Manual

EN – 21
ENGLISH
Mouse remote control
By connecting to personal computer through the USB or PS/2 port, you can operate your computer with the
projector remote control.
Connection
Projector + PC with USB connector
Operation
• Turn off PC and the projector before connecting with PS/2 port. When connecting the PC with the projector
when the personal computer is on, the remote control does not work as a mouse. In that case, turn the projec-
tor on, then restart the personal computer.
• When the projector is...

EN – 22
The lamp is designed to project the image on the LCD
panels. When the lamp no longer functions, replace it
with a new one.
Caution:
•Do not remove the lamp immediately after turning
off the lamp of the projector, you may get burned
because of the high temperature of the lamp.
•For lamp replacement, press the power button to
power off, then wait for 60 seconds in stand-by mode
to allow the lamp and LCD panels to cool. Then
turn off  the main switch,  unplug the power cord
from the outlet, and wait...

EN – 23
ENGLISH
Maintenance
Caution:
Be sure to turn off the projector and unplug the power
cord from the wall outlet before you perform any main-
tenance on the projector.
Cleaning the air-filter
Clean the air-filter frequently. If the filter or ventilation
grille become clogged with dirt or dust, the temperature
inside the projector may rise and shut off the power (the
TEMP indicator starts to blink red).
1. To remove the filter cover, press the
ridged area gently, push the cover in
the direction of...

EN – 24
Troubleshooting
The following offers solutions to some of the common problems you may encounter. We suggest that you consult
this chart before contacting your dealer.
CAUSE
•The air inlet grille, outlet grille  or air filter is
clogged with dust or some objects.
POWER indicator does not light up.
•Power cord is unplugged from the outlet.
•Power cord is disconnected from the projector.
•The main switch is turned off.
•The lamp lid is open.
POWER indicator blinks red.
•The projector has been turned...

EN – 25
ENGLISH
Indicators
The projector has three LED Indicators which shows the working condition of the projector.
The following offers solutions to possible problems. If a problem persists, turn the projector off and consult your
dealer.
Normal condition
Abnormal condition
Steady
red
Steady
green
Steady
greenBlinking
green
Steady
green
POWER LAMP TEMPCONDITION Notes
The POWER is ON. (Normal condition) Lamp stand-by (about for 1 minute) The power button cannot be used to switch
ON and OFF...

EN – 26
Specifications
LCD projector
XL2U
AC100V - 240V,  50 / 60Hz
2.3 A
0.7-inch LCD panel: 3 pieces (for R, G, B)
Pixels 1,024 ×   768 = 786,432 pixels
Total 2,359,296 pixels
Active pixel rate: 99.99 % or more (each panel)
16,770,000 colors
F 1.9 - 2.2      f = 27 mm - 32 mm
150 W HS
30 inch - 300 inch (aspect ratio 4:3)
Resolution : 640 x 400 (Expand) - 1024 x 768 (Real) - 1280 x 1024 (Compress)
Sync on Green available
NTSC / 4.43NTSC / PAL (including PAL-M, N) / SECAM / PAL-60 /
DVD (Component) /...

EN – 27
ENGLISH
Connectors
PC analog RGB input
Use to input video signals (analog
RGB) of a personal computer.
(Pin assignment of Mini D-SUB 15P jack)
PIN NO. SPEC PIN NO. SPEC
1R(RED)/PR/CR9—
2G(GREEN)/Y10 GROUND
3B(BLUE)/PB/CB11 GROUND
4 GROUND 12 DDC Data
5 GROUND 13 HD/CS
6 GROUND 14 VD
7 GROUND 15 DDC Clock
8 GROUND
1 5
116 10
15RS-232C input
Use to control the projector with the
personal computer, or control the
personal computer with remote con-
trol.
Use the provided RS-232C cable (Mini DIN...

EN – 28
Specification of RGB signals in each computer mode of the projector
*1: The EXPAND MODE and the PinP mode don’t
function with this signal.
•When the EXPAND MODE of FEATURE menu is
set to real screen display, by pressing the EXPAND
button on the remote control, it will switch to the
screen displaying the picture as its original size
(real screen display).  In the real screen display,
pictures will be black-framed when picture resolu-
tion is lower than 1,024 x 768.
Important:
•Some computers may...
