Panasonic Color Television Ct 27d11 Operating Instructions

10
1 TUNER PIP OPERATION WITH A VCR - NO CABLE BOX
1 Tuner PIP Operation with a VCR - No Cable Box
Note:Refer to the FEATURE COMPARISON CHART on page 3 for your television PIP capability.
This television includes a Picture In Picture (PIP) feature. A second video source
(VCR) is required to provide a second picture.
Connect your television to a VCR, as shown:
Note:The Remote Control must be programmed with the supplied codes to operate the VCR. See
Programming the Remote Control in the Remote Control...

11
2 TUNER PICTURE IN PICTURE (PIP) OPERATION
2 Tuner Picture In Picture (PIP) Operation
Note:Refer to the FEATURE COMPARISON CHART on page 3 for your television PIP capability.
PIP Operation with a VCR and Cable Box
This television includes a two tuner Picture In Picture (PIP) feature. This allows
watching two (2) live broadcasts at the same time without or with an external video
source (VCR).
Without A VCR (External Video Source)
Procedure
7. Connect incoming cable to antenna (ANT) input on back of...

12
2 TUNER PIP OPERATION WITH A VCR - NO CABLE BOX
2 Tuner PIP Operation with a VCR - No Cable Box
Note:Refer to the FEATURE COMPARISON CHART on page 3 for your television PIP capability.
This television includes a two tuner Picture In Picture (PIP) feature. This allows
watching two (2) live broadcasts at the same time without or with an external video
source (VCR).
Connect your television to a VCR, as shown.
Note:The Remote Control must be programmed with the supplied codes to operate the VCR. See...

13
MAIN MENU
Main Menu

Procedures
1. Press the ACTION button on the remote control to display Main Menu.
2. Press the CH up/down or VOL right/left button to highlight the desired icon.
3. Press the ACTION button to display icon features and submenus.
4. Press the CH up/down buttons to select desired icon features.
5. Press the VOL right button to highlight submenus.
6. Press the CH up/down to select desired submenu.
7. Press the VOL right/left button to select or adjust submenu.
8. Press the ACTION...

14
MAIN MENU FEATURE CHART
Main Menu Feature Chart
MENUDESCRIPTION
SET UP
LANGUAGESrSelect English, Spanish, or French menu.
PROG. CHAN
(Program Channels)
rMODE - Select Cable or TV. See Installa-
tion section in manual.
rAUTO PROGRAM - Automatically program
channels having a signal into memory.
rMANUAL PROGRAM - Manually add or
delete channels from memory.
CC
(Closed Captioning)
rCC ON MUTE -  Activate C1-C2 for Closed
Captioning display when the remote MUTE
button is pressed.
rCC MODE - Select C1 or...

15
MAIN MENU FEATURE CHART
 SPEAKERS
rON - TV speakers operate normally.
rOFF & VAO (Variable Audio Output) -
TV speakers off - audio adjustable by TV.
rOFF & FAO (Fixed Audio Output)-
TV speakers off - audio adjustable only by
the external amplifier.
TIMER
CLOCK SET
rSet the time and the day of the week.
(Time will display onscreen after turning on
the television, pressing the RECALL button
or changing channels).
SLEEPrSet timer to turn off TV in 30, 60 or
90 minutes.  Select NO to turn timer off.
TIMER...

16
MAIN MENU FEATURE CHART
CAPTION
rMANUAL CAPTION - Enter channel
numbers and captions manually.
rINPUT LABEL - Label video connections
for onscreen display of optional equipment.
Note:This receiver has a skip feature, which will
allow the user to skip Input modes when
pressing TV/VIDEO button.
LOCK
MODE
rLock All Channels or Game with a secret
code.
Note:For more information about Block
Programs, see the V-CHIP Parental Lock
manual provided with the TV package.
HOW LONG?rSelect the period of time...

17
SPECIAL FEATURES
Special Features
SET UP
Menu Languages
In SET UP Menu, select IDIOMA / LANGUE to change menu language to ENGLISH,
ESPAÑOL (Spanish), or FRANÇAIS (French).
Prog Chan (Program Channels)
In SET UP menu under PROG CHAN select:
rMODE to select TV (antenna) or CABLE mode depending on the signal source.
r
AUTO PROGRAM to automatically program all channels with a signal.
rMANUAL PROGRAM to manually add or delete channels.
  (Closed Captioning)
This television contains a built-in...

18
SPECIAL FEATURES
TIMER
Sleep
In TIMER menu, select SLEEP to turn TV off in 30, 60 or 90 minutes.  Select NO to
turn off timer
.
Timer 1 and Timer 2
In TIMER menu, select one or both timers to turn the television on and off at selected
times, on selected channels, and on selected days.
Note:TIME must be entered in CLOCK SET to operate TIMER features.
  Turn Off After 90 Minutes
The TV automatically turns OFF after 90 minutes
when turned on by the TIMER.  If the OFF time is
selected or if a key is...

19
SPECIAL FEATURES
Video Adjustments
In Picture menu under VIDEO ADJ. select:
rCOLOR - Adjust desired color intensity.
rTINT - Adjust natural flesh tones.
rBRIGHTNESS - Adjust dark areas for crisp detail.
rPICTURE - Adjust white areas of picture.
rSHARPNESS - Adjust clarity of outline detail.
rNORMAL - Reset all picture adjustments to factory default settings.
Note: Video adjustments can be individually set for each video input mode.
Other Adjustments
In Picture menu under OTHER ADJ. select:...
