Recording pictures (basic)
41
Compensating the Exposure
Use this function when you cannot achieve
appropriate exposure due to the difference
of brightness between the subject and the
background.
1Press 3 several times until
[ EXPOSURE] appears and
then compensate the exposure.
 You can compensate from j2EV to
i2 EV in steps of 1/3 EV.
 EV is an abbreviation of Exposure Value,
and it is the amount of light given to the
CCD by the aperture value and the shutter
speed.
 The compensation range...

Recording pictures (basic)
42
Taking Pictures using Auto Bracket
In this mode, 3 pictures are automatically
recorded by each press of the shutter
button according to the compensation
range of the exposure.
You can select the desired exposure
among the 3 types of pictures.
1Press 3 several times until
[ AUTO BRACKET] appears
and then set the compensation
range of the exposure.
 You can select the exposure from
j1EV to i1 EV in steps of 1/3 EV.
 When you do not use auto bracket,
select [OFF].
...

Recording pictures (basic)
43
Optical Image Stabilizer [STABILIZER]
This mode recognizes and compensates
jitters. You can reduce blurring caused by
jitters when you hold the camera with one
hand for taking a picture of yourself or
when you take pictures indoors where the
shutter speed is slowed down.
1 Optical Image Stabilizer button
1Keep pressing the stabilizer
button until [STABILIZER]
appears and then select the
stabilizer function mode.
 The stabilizer function may not work
sufficiently in...

Recording pictures (basic)
44
Taking Pictures using Burst Mode
1Press the Single/Burst Mode
Button to switch the burst mode
setting and then take pictures.
: High speed
;
: Low speed
;
: No limit
;
No display (canceled)
∫Number of pictures recorded in burst
mode
¢When the shutter speed is higher than
1/60 and the flash is not activated
 In simple mode [ ], the burst speed is
fixed to Low. (P32)
 Keep pressing the shutter button fully to
activate the burst mode.
 If the flash is activated, you...

Playback (basic)
45
Playback (basic)
Playing Back Pictures
1Select the picture.
2 : Play back the previous picture.
 1 : Play back the next picture.
 The picture following the last one is the  first picture.
∫ Fast forwarding/Fast rewinding
When you keep pressing  2/1  during
playback, the file number and the page
number are updated. If you release  2/1
when the number of the desired picture
appears, you can play back the picture.
1 : Fast forward
2 : Fast rewind
 The number of files...

Playback (basic)
46
9 Pictures Multi Playback
1Switch to multi screen. 2Select the pictures.
∫ To return to the normal playback
Rotate the zoom lever towards [ ] or
press the [MENU] button.
 The picture with the number colored in  orange appears.
∫ To delete a picture during a 9 pictures
multi playback.
Press the [ ] button.
When the confirmation screen appears,
press  4 to select [YES], and press  1.
(P48)
 Rotated pictures are displayed in the
direction oriented when they are recorded.
(P71)...

Playback (basic)
47
Using the Playback Zoom
1Enlarge the picture.
:1 k> 2k> 4k> 8k > 16k
:16 k> 8k> 4k> 2k > 1k
 When you rotate the zoom lever  towards W after the picture is enlarged,
the magnification becomes lower.
 When you change the magnification,  the zoom position indication  A appears
for about 1 second to check the position
of the section enlarged.
 When you press the [MENU] button, the
magnification reverts to 1 k.
2Shift the picture.
 When you move the position to be
displayed,...

Playback (basic)
48
Deleting Pictures
∫To delete a single picture
1Select the picture to be deleted.
2: Play back the previous picture.
 1: Play back the next picture.
2 Delete the picture.
 While deleting the picture, [ ] appears
on the screen.
∫ To delete multiple pictures
1Select [MULTI DELETE].
2Select the pictures to be deleted.
 The selected pictures appear with [ ].
When  4 is pressed again, the setting is
canceled.
 The icon [ ] blinks red if the selected  picture cannot be deleted....

Playback (basic)
49
3Delete the pictures.
 It is possible to delete up to 50 pictures
all at once.
∫ To delete all pictures
1Select [ALL DELETE].
2Delete all of the pictures.
 Once deleted, pictures cannot be
recovered. Please double-check before
deleting pictures.
 Do not turn off the camera while deleting.
 Pictures that are protected (P74) or that  do not conform to DCF standards (P45)
will not be deleted.
 When you delete pictures, use a battery  with sufficient battery power (P13) or use...

Recording pictures (advanced)
50
Recording pictures (advanced)
Using the Mode Dial
This mode allows you to take pictures
closely focusing on the subject. (e.g. When
taking pictures of flowers.)
You can take pictures with the lens at a
distance of up to 0.16 feet (5 cm) (Wide)
from the subject.
∫Focus range
 Normal
 Macro mode [ ]
 We recommend using a tripod.
 When the camera lens is at a distance
beyond the available range from the
subject, the subject may not be focused
even if the focus...
