Recording pictures (advanced)
51
This mode allows you to record motion
images.
1Select [MOTION RATE].
 [10fps]:
Recording motion images for a longer
time is available though less smooth.
The file size is smaller, so the files are
suitable to be attached to e-mails.
 [30fps]:
The motion of the recorded image is
smooth, but the file size is large.
 fps (frame per second); This refers to
the number of frames used in 1 second.
 Close the menu by pressing the shutter
button halfway or the [MENU]...

Recording pictures (advanced)
52
∫Available recording time (seconds)
 The remaining recording time
(approximation) appears on the screen.
 The recordable time is an approximation.
 You cannot play audio only with the
camera. When you want to play audio,
connect the camera to TV (P82) or PC
(P85).
 The motion images cannot be recorded
without audio.
 The picture size is fixed to
320k240 pixels.
 If using a MultiMediaCard, after recording
motion images, the card access indication
may appear...

Recording pictures (advanced)
53
Press the [MENU] button to display the
scene menu. When [SCENE MENU] (P23)
on the [SETUP] menu is set to [AUTO], set
the mode dial to [ ] to display the scene
menu automatically.
 Select a menu item with 3/4 and press
1 to determine the setting.
 When rotating the zoom lever toward T,
the page of the menu screen can be
forwarded. (vice versa)
 If you press the [MENU] button while the
scene menu is displayed, you can set the
[SETUP] menu (P20) and the [REC]...

Recording pictures (advanced)
54
This mode allows you to make the subject
stand out from a background and adjust the
exposure and the hue to achieve a healthy
complexion on the subject.
∫Technique for Portrait mode
To make this mode more effective:
1 Rotate the zoom lever to Tele as far as
possible.
2 Be close to the subject.
3 Select a background which is far from
the camera.
 This mode is suitable for outdoors in the
daytime.
 White balance works best when recording
outdoors in the daytime....

Recording pictures (advanced)
55
This mode allows you to take a picture of a
wide landscape. This mode is suitable
when the distance between the camera
and the subject is 16.4 feet (5 m) or more in
the open air. You can take pictures of a far
landscape even through a windowpane.
 The focus range is 16.4 feet (5 m) –¶.
 The Flash setting is fixed to Forced OFF
[].
 The setting on the AF assist lamp is
disabled.This mode allows you to take a picture of a
nightscape. The landscape can be...

Recording pictures (advanced)
56
This mode allows you to take pictures
against a night landscape. The subject can
be recorded with brightness in real life by
using the flash and the slow shutter speed.
∫Technique for Night portrait mode
 When you take pictures holding the  camera in your hands, hold it firmly and
use the stabilizer function (P43).
The shutter speed becomes slow in this
mode. We recommend using a tripod.
 Keep the subject still for about 1 second  after taking a picture.
 Take a...

Recording pictures (advanced)
57
This mode allows you to take a picture in a
dim room (e.g. a wedding reception, a
party, a banquet in a bar, etc.) clearly.
The shutter speed or the exposure is
automatically adjusted according to the
brightness of the room.
∫Technique for Party mode
 The shutter speed is slowed down. Hold
the camera firmly to take a picture.
 The flash mode of the built-in flash can be
set to Forced ON/Red-eye reduction
[ ] or Slow sync./Red-eye reduction
[].This mode allows...

Recording pictures (advanced)
58
This mode allows you to take a picture of
yourself.
ªTechnique for Self-portrait mode
 When you are focused by pressing the
shutter button halfway, the self-timer
indicator 1 lights up. Fix the camera
firmly and then press the shutter button
fully.
 The captured picture automatically
appears on the LCD monitor for
reviewing. Refer to P21 for operations on
the review function.
 When the picture may be blurred by slow
shutter speed, we recommend using the
2...

Recording pictures (advanced)
59
Using the [REC] mode menu
Setting the hue, picture quality adjustment,
etc. allows you to create wide variations on
taking pictures.
 Set the mode dial to the desired recording
mode.
 When rotating the zoom lever toward T,
the page of the menu screen can be
forwarded. (vice versa)
 Close the menu by pressing the shutter
button halfway or the [MENU] button after
finishing the setting.: [W.BALANCE] (P60)
: [SENSITIVITY] (P62)
: [PICT.SIZE] (P62)
: [QUALITY]...

Recording pictures (advanced)
60
This function allows you to reproduce a
white color closer to the tone in real life on
the pictures recorded under sunlight,
halogen lighting, etc. in which the white
color may appear reddish or bluish.
 When setting the white balance to the
mode except [AUTO], you can finely
adjust the white balance.∫Auto White Balance
Use of auto white balance adjustment in
inappropriate lighting conditions may result
in reddish or bluish pictures. Where the
subject is...
