Playback (advanced)
81
 Usually, it is not necessary to format the
card. Format the card when the message
[MEMORY CARD ERROR] appears.
 Do not format the card on a computer.
Always format on the camera.
 Once the card is formatted, all data
including protected images are
irretrievably erased. Please confirm
that all data is transferred to your PC
before proceeding with format
function.
 During formatting, do not turn the camera
off.
 When you format the card, use a battery
with sufficient...

Playback (advanced)
82
Playing Back Pictures with a TV Screen
∫Playing back pictures with the
supplied cable
 Turn the camera and the TV off.
1Connect the AV cable A
(supplied) to the [AV OUT] socket
of the camera.
 Connect the AV cable with the [ ]
mark facing the [1] mark on the
[AV OUT] socket.
 Hold B and then insert or pull the AV
cable straight.
2Connect the AV cable to the video
input and the audio input sockets
of the TV.
1 Yellow: to the video input socket
2 White: to the audio...

Connecting to a PC or Printer
83
Connecting to a PC or Printer
Before Connecting with USB Connection Cable
[ : USB MODE]
Select the USB communication system according to the OS of your PC or your printer
before connecting them to the camera with the USB connection cable (supplied).
Set the items on [USB MODE] in the [SETUP] menu. (P23)
1Select [USB MODE]. 2Select [PC] or [PictBridge (PTP)].
 When [PC] is selected, the camera is connected via USB Mass Storage communication
system.
 When [PictBridge...

Connecting to a PC or Printer
84
∫When using Windows 98/98 SE
When using Windows 98/98 SE, install the USB driver before connecting. (When using
Windows Me/2000/XP, Mac OS 9.x and Mac OS X, you do not have to install the USB
driver.)
∫When using Windows 2000 Professional, Windows Me, Windows 98/98 SE or Mac
OS 9.x
Even if the [PictBridge (PTP)] is selected in [USB MODE], the camera cannot be
connected by a PC with the following OS’s: Windows 2000 Professional, Windows Me,
Windows 98/98 SE or Mac OS...

Connecting to a PC or Printer
85
Connecting to a PC
 Refer to the separate operating
instructions for details about PC
connection.
 If you use Windows 98/98SE, install the
USB driver and then connect it to the
computer.
 When using Windows Me/2000/XP, Mac
OS 9.x and Mac OS X, you do not have to
install the USB driver.
A: AC adaptor (DMW-CAC2; optional)
B: USB connection cable (supplied)1Turn the camera on and set the
[USB MODE] according to the OS
you use.
 Set to [PC] or [PictBridge (PTP)]....

Connecting to a PC or Printer
86
∫PC
[Windows]
The drive appears on the [My Computer]
folder.
• If it is the first time you are connecting the  camera to a PC, the required driver is
installed automatically so that the camera
can be recognized by the Windows Plug
and Play, then it appears on the
[My Computer] folder.
[Macintosh]
The drive is shown on the screen.
∫ PictBridge (PTP)
[Windows]
The camera icon appears on the
[My Computer] folder.
 If it is the first time you are connecting the...

Connecting to a PC or Printer
87
Connecting to a PictBridge-compliant Printer
By connecting the camera directly to a
printer supporting PictBridge via the USB
connection cable (supplied), you can select
the pictures to be printed or start printing.
A: USB connection cable (supplied)
B : AC adaptor (DMW-CAC2; optional)
1Turn the camera on and then set
the USB mode to [PictBridge
(PTP)]. (P83)
2Turn on the printer.
3Connect the camera to a printer
via the USB connection cable  A
(supplied).
•...

Connecting to a PC or Printer
88
 Set the print settings such as paper size
or print quality on the printer beforehand.
(Read the printer operating instructions.)
 Connect the camera to a printer. (P87)
∫Single picture
1Select a picture to be printed.
 A message displays for about
2 seconds.
2Set the print settings.
 The items which are not supported by
the printer are displayed in gray and
cannot be selected.
 When you want to print pictures in a
paper size or a layout which is not...

Connecting to a PC or Printer
89
∫[PAGE LAYOUT]
(Possible layouts on the camera)
3Select [PRINT START] and then
print out the picture.
 Press the [MENU] button to cancel
printing.
∫DPOF picture
 Set the DPOF print with this camera in
advance. (P72)
1Select [DPOF PICTURE].
 When printing under the new settings,
disconnect the USB connection cable
and connect it to the printer again.
 You can change the DPOF print setting
by pressing the [MENU] button. (P72)
2Select [PRINT START] and then
print...

Connecting to a PC or Printer
90
∫Setting the date printing with the
DPOF print in advance
When the printer supports the date printing
by DPOF setting, we recommend setting
the date printing with the DPOF print in
advance. (P73)
The recording date can be printed by
selecting [DPOF PICTURE] to start
printing.
 Do not disconnect the USB connection
cable when the cable disconnection
warning icon [ ] is indicated.
 When the [¥] indication lights in yellow
during printing, make sure there is no...
