11
Basic settings[Format] ........................................... P31
[Clock Set] ....................................... P35
How to set menu items .................... P37
[Q.MENU] ........................................ P40
[Beep] .............................................. P49
[Economy] ....................................... P51
[Reset] (initialization) ....................... P54Dioptor adjustment...........................
P58
Display switching ....................... P64, 71
Customization...

12
Connect“ Image App ” .................................. P254
NFC ............................................... P259
[WPS (Push-Button)] ............. P289, 291
Direct connection ........................... P291
Image App Remote recording .......................... P260
Saving images ............................... P261
Sending images ..................... P262, 265
Sending and adding location
information ..................................... P263[Touch Sharing] .............................
P298
In...

13
1.Before Use
Care of the camera
Do not subject to strong vibration, shock, or pressure.
•The lens, monitor, or external case may be damaged if used in the
following conditions.
It may also malfunction or image may not be recorded if you:
–Drop or hit the camera.–Press hard on the lens or the monitor.
•When camera is not in use or when using the playback feature,
ensure that the lens is in the stored position, with lens cap on.
•There are times when rattling sounds or vibrations will come from
the...

1. Before Use
14
Standard Accessories
Check that all the accessories are supplied before using the camera.
•
The accessories and their shape will differ depending on the country or area where the camera
was purchased.
For details on the accessories, refer to “Basic Owner’s Manual”.
•Battery Pack is indicated as  battery pack or battery  in the text.•Battery Charger is indicated as  battery charger or charger  in the text.•SD Memory Card, SDHC Memory Card and  SDXC Memory Card are indicated as card in...

15
1. Before Use
Names and Functions of Main Parts
1 Self-timer indicator  (P174)/
AF Assist Lamp  (P149)
2 Flash  (P201)
3 Lens surface
4 [LVF] button  (P57)/
[Fn5] button (P44)
5 Eye sensor  (P57)
6 Eye Cup  (P361)
7 Viewfinder  (P57)
8 [AF/AE LOCK] button  (P157)
9 Focus mode lever  (P138, 150)
10 Rear dial (P19)
11 Speaker •
Be careful not to cover the speaker with your
finger. Doing so may make sound difficult to
hear.
12 Monitor  (P18)
13 [Q.MENU] button (P40) /
[Fn3] button (P44)
14 [ (]...

1. Before Use
16
19 Focal length scale (35 mm film camera
equivalent)
•
Indicates values for the [3:2] aspect ratio.
(When recording motion pictures, refer to the
focal length displayed on the screen.)
20 Motion picture button  (P215)
21 Zoom lever  (P197)
22 Shutter button  (P59)
23 [Fn1] button (P44)
24 Drive mode dial (P166)
Single  (P166):
Burst  (P167) :
Auto Bracket  (P171):
Self-timer  (P174):
Time Lapse/Animation (P176 , 180) :
25 Hot shoe (Hot shoe cover)  (P319)
26 Stereo microphone  (P223)...

17
1. Before Use
37 Manual ring (P150 , 197)
•Allows you to control the zoom or focus.
38 Manual ring selector switch  (P150, 197)
39 O.I.S. switch (P195)
40 [MIC] socket  (P322)
41 Shoulder strap eyelet  (P23)
•
Be sure to attach the shoulder strap when
using the camera to ensure that you will not
drop it.
42 Flash open lever  (P201)
•The flash opens, and recording with the flash
becomes possible.
43 Diopter adjustment dial  (P58)
44 [REMOTE] socket  (P321)
45 [HDMI] socket  (P301)
46 [AV...

1. Before Use
18
At the time when this camera is purchased, the monitor is stowed in the camera body.
Bring out the monitor as shown below.
1 Place your finger in the notch on the right side of the monitor to open it.
(Maximum 180 o)
2 It can be rotated 180 o forwards.
3 Return the monitor to its original position.
•
Only rotate the monitor after opening it wide enough, and be careful not to use
excessive force as it may be damaged.
∫ Free angle shooting
The monitor can be rotated to suit your needs....

19
1. Before Use
There are 2 ways to operate the rear dial, rotating left or right, and deciding by pressing.
Rotating:
Selection of items or setting of values is performed during the various settings.
Pressing:
Operations that are the same as [MENU/SET] button, such as determine settings,
etc., are performed during the various settings.
•
Rear dial is described as follows in this owner’s manual.
Allows you to set the aperture, shutter speed, and other settings when in  / / /
modes.
¢ Pressing the...

1. Before Use
20
Pressing the cursor button:
Selection of items or setting of values etc., is performed.
Pressing [MENU/SET]:
Confirmation of setting contents, etc., is performed.
•
This owner’s manual expresses the up, down, left, and right of
the cursor button as  3/4/2 /1.
Cursor buttons/[MENU/SET] button
