61
3. Basic Operation
Recording Motion Picture
This camera can record full high definition motion pictures compatible with the AVCHD
format or motion pictures recorded in MP4.
Audio will be recorded in stereo.
1Start recording by pressing the motion
picture button.
A Elapsed recording time
B Available recording time
•Recording of motion picture appropriate for each mode is
possible.
•The recording state indicator (red)  C will flash while
recording motion pictures.
•If approximately 1 minute elapses...

3. Basic Operation
62
Selecting the Recording Mode
Switching the mode by rotating the mode dial.
•Rotate the mode dial slowly to select the desired mode.
Intelligent Auto Mode  (P75)
The subjects are recorded using settings  automatically selected by the camera.
Intelligent Auto Plus Mode (P75)
Allows you to adjust the brightness and color hue when in Intelligent Auto Mode.
Program AE Mode (P84)
Records at the aperture value and shutter speed set by the camera.
Aperture-Priority AE Mode (P86)
The shutter...

63
3. Basic Operation
Creative Video Mode  (P118)
Records a motion picture with the aperture value and the shutter speed you specify. In
this recording mode, all the motion picture f unctions become available. For example, you
can record motion pictures in 4K.
¢ You cannot take still pictures.
  Custom Mode  (P120)
Use this mode to take pictures wit h previously registered settings.
Scene Guide Mode (P93)
This mode allows you to take pictures that match the scene being recorded.
Creative Control Mode...

3. Basic Operation
64
Switching the Information Displayed on the
recording screen
Press [DISP.] to change.
•You can select between [ ] (monitor style) and [ ]
(viewfinder style) for each of the monitor and the viewfinder
display screen using [Monitor Disp. Style] and [LVF Disp.Style] in
the [Custom] menu.
([ ] monitor style)
•Screen will switch as follows:
(Example of monitor display)
¢ 1 Histograms are displayed when the [Histogram] of the [Custom] menu is set to [ON].
It is also possible to display...

65
3. Basic Operation
([ ] viewfinder style)
•Screen will switch as follows:
(Example of display on viewfinder)
¢ Histograms are displayed when the [Histogram] of the [Custom] menu is set to [ON].
It is also possible to display the exposure meter by setting the [Expo.Meter] of the [Custom]
menu to [ON]. (P84)
•If approximately 1 minute elapses without an oper ation being performed, part of the display will
disappear. Press [DISP.] to make the display reappear. This operation is to prevent screen...

3. Basic Operation
66
Displaying/not displaying the histogram
You can set the position by pressing  3/4/2 /1.
•A Histogram is a graph that displays brightness along the horizontal
axis (black to white) and the number of pixels at each brightness level
on the vertical axis.
It allows you to easily check a picture’s exposure.
A dark
B bright
•When the recorded picture and the histogram do not match each other under the
following conditions, the histogram is displayed in orange.
–When the Manual Exposure...

67
3. Basic Operation
∫ About the tilt sensor display
With the tilt sensor displayed, it is easy to correct the tilt of the camera etc.
1Press [DISP.] to display the tilt sensor.2Check the tilt of the camera.
A Horizontal direction:
Correcting tilt to the left
B Vertical direction:
Correcting downward tilt
•When the tilt of the camera is little, the indicator changes to green.•When recording with a vertical orientation, the display automatically switches to a
vertically orientated display.
•Even after...

3. Basic Operation
68
Playing Back Pictures/Motion Pictures
1Press [ (].
2Press  2/1.
•If you press and hold  2/1, you can play back the
pictures in succession.
•Speed of picture Forwarding /Rewinding changes depending on the playback status.
∫To finish playback
Press [(] again, press the motion picture button or press the shutter button
halfway.
Not available in these cases:
•
This camera complies with the DCF standard “Design rule for Camera File system” established
by JEITA “Japan Electronics and...

69
3. Basic Operation
Rotate the zoom lever towards [ L] (W).
1 screen 12 screens 30 screens Calendar screen
display
•
Pictures displayed using [ ] cannot be played back.
∫To return to Normal Playback
Press  3/4 /2 /1  to select a picture and then press [MENU/SET].
1Rotate the zoom lever towards [ L] (W) to display the calendar screen.2Press  3/4 /2/ 1 to select the date to be played back.
3Press [MENU/SET] to display the images that are
recorded in selected date.
4Press  3/4 /2 /1  to select a picture...

3. Basic Operation
70
This unit was designed to play motion pictures using the AVCHD and MP4 formats.
In Playback Mode, select a picture with the motion
picture icon ([ ]), and then press  3 to play back.
AMotion picture recording time
•After playback starts, the elapsed playback time is displayed on
the screen.
For example, 8 minutes and 30 seconds is displayed as
[8m30s].
•Some information (recording information, etc.) is not displayed
for motion pictures recorded in [AVCHD].
•High Speed Video...
