Panasonic Dmc Fz1000 Owners Manual

41
2. Preparations before Recording
Using Quick Menu items on the on-monitor recording
information screen of [ ] (monitor style)  (P64)
(Press [DISP.] repeatedly until the screen is displayed.)
Press [Q.MENU], rotate the rear dial to select an item, and
then press the rear dial.
Rotate the rear dial to select the setting, and then press the
rear dial to set it.
•
You can also set with  3/4/2/1 and [MENU/SET].
Switching the method for setting Quick Menu items
> [Custom]  > [Q.MENU]
[PRESET]:
The...

2. Preparations before Recording
42
When [Q.MENU]  (P41) in the [Custom] menu is set to [CUSTOM], the Quick Menu can be
changed as desired.
Up to 15 items can be set to the Quick Menu.
1Press  4 to select [ ] and then press [MENU/SET].
2Press  3/4 /2 /1  to select the menu item in the top
row and then press [MENU/SET].
3Press  2/1  to select the empty space in the bottom
row and then press [MENU/SET].
A Items that can be setup as Quick Menus.
B Items that can be displayed in the Quick Menu screen.
•If...

43
2. Preparations before Recording
4Press [ ].
•It will return to screen of step1.
Press [MENU/SET] to switch to the recording screen.
[Motion Picture] menu [Custom] menu
–[Motion Pic. Set]
([Rec Format]  (P212)/[Rec Quality]
(P212) )
–[Picture Mode] (P219)
–[Silent Mode]  (P186)–[Peaking] (P152)
–[Histogram]  (P66)–[Guide Line]  (P66)–[Zebra Pattern]  (P193)
–[Monochrome Live View]  (P194)–[Rec Area] (P216)–[Zoom Lever]  (P200)
–[Manual ring (Zoom)]  (P200)

2. Preparations before Recording
44
Assigning frequently used functions to the
buttons
(function buttons)
You can assign frequently-used functions to particular buttons.1Select the menu.
2Press  3/4  to select [Setting in REC mode] or [Setting in PLAY mode] and then
press [MENU/SET].
3Press  3/4  to select the function button you want to
assign a function to and then press [MENU/SET].
4Press  3/4 to select the function you want to assign
and then press [MENU/SET].
•
Refer to P45  for [Setting in REC...

45
2. Preparations before Recording
You can use assigned functions  by pressing a function button when recording.
•The following functions can be assigned to the button [Fn1], [Fn2], [Fn3], [Fn4] or [Fn5].
¢ Function button settings at the time of purchase.
Making the function button settings for recording
[Rec] menu/Recording functions
–[Wi-Fi]  (P251): [Fn2]¢
–[Q.MENU]  (P40): [Fn3]¢
–[LVF/Monitor Switch]  (P58): [Fn5]¢
–[AF/AE LOCK]  (P151)–[AF-ON] (P151, 157)–[Preview]  (P91): [Fn4]¢
–[One Push AE]...

2. Preparations before Recording
46
•Some functions cannot be used depending on the mode or displayed screen.
•When set to [Focus Area Set], it is possible to display the position setting screen of either AF
area or MF Assist.
Not available in these cases:
•
[Fn1] cannot be used in the following cases.–[Miniature Effect]/[One Point Color]/[Sunshine] (Creative Control Mode)
–[Multi Exp.]•[Fn2] cannot be used during Time Lapse Shooting.
You can directly set an assigned function to a selected image by...

47
2. Preparations before Recording
Configuring basic settings of this unit (Setup Menu)
For details on how to select the [Setup] menu settings, refer to  P37.
[Clock Set] and [Economy] are important items.
Check their settings before using them.
•
Refer to P35  for details.
•Press 3 if you are using Daylight Savings [ ]. (The time will move forward by 1 hour.)
Press  3 once more to return to the normal time.
•If you cannot find the travel destination in the areas displayed on the screen, set by the time...

2. Preparations before Recording
48
•The number of days that have passed since the departure date can be printed out using the
“ PHOTOfunSTUDIO ” bundled software on the DVD (supplied).
•The travel date is calculated using the date in the clock setting and the departure date you set.
If you set [World Time] to the travel destination, the travel date is calculated using the date in
the clock setting and the travel destination setting.
•[Travel Date] cannot be set for motion pictures recorded with...

49
2. Preparations before Recording
•When [Silent Mode] is set to [ON], [Beep Volume] and [Shutter Vol.] is set to [OFF].
•When [Live View Mode] is set to [30fps] the image quality on the recording screen may be
worse than when it is set to [60fps], but this does not affect the recorded image.
•In a dark environment, the frame rate may become slower.•When using the AC adaptor (optional),  [Live View Mode] is fixed to [60fps].
•It will adjust the monitor when the monitor is in  use, and the viewfinder...

2. Preparations before Recording
50
•The brightness of pictures displayed on the monitor is enhanced, so some subjects on the
monitor may appear different from the actual subjects. However, this enhancement does not
affect recorded pictures.
•The monitor automatically returns to standard brightness if no operations are performed for
30 seconds when recording in [MODE1]. It will light up brightly again with button operation.
•When [AUTO] or [MODE1] is set, the usage time is reduced.
•[AUTO] is only...
