- 181 -
Connecting to other equipment
Note
•When the picture is not appropriate to view in 3D (disparity is too large, etc.)–[Slide Show]:
The picture will be played back in 2D.
–[Filtering Play]:
Confirmation screen is displayed. Select whet her or not to play back the picture in 3D.
•2 pictures may be displayed side by side when a 3D  picture is played back on a TV that is not 3D
compatible.
•When a picture recorded in 3D is displayed on the screen of this unit, it is played back in 2D...

- 182 -
Connecting to other equipment
Saving still pictures and motion pictures on your
PC
You can acquire recorded pictures to a PC by connecting the camera and the PC.
•Some PCs can read directly from the card removed from the camera. For details, refer to the
operating instructions of your PC.
•If the computer being used does not support SDXC Memory Cards, a message prompting you
to format may appear. (Doing so will cause recorded images to be erased so do not choose to
format.)
If the card is not...

- 183 -
Connecting to other equipment
1Connect the camera to a PC via the USB connection cable A (supplied).
2Press 3/4 to select [PC], and then press [MENU/SET].
•If [USB Mode]  (P65) is set to [PC] in the [Setup] menu in advance, the camera will be
automatically connected to the PC without displaying the [USB Mode] selection screen.
•When the camera has been connected to the PC with [USB Mode] set to [PictBridge(PTP)], a
message may appear on the PC’s screen. Close the screen by selecting [Cancel],...

- 184 -
Connecting to other equipment
Note
•“PHOTOfunSTUDIO” is not compatible with Mac.•Use a battery with sufficient battery power or the AC adaptor (optional). If the remaining battery
power becomes low while the camera and the PC are communicating, the status indicator blinks and
the alarm beeps.
Refer to
“Disconnecting the USB connection cable safely”  (P185)  before disconnecting the USB
connection cable. Otherwise, data may be destroyed.
•Before connecting or disconnecting the AC adaptor...

- 185 -
Connecting to other equipment
∫Disconnecting the USB connection cable safely
Select the [ ] icon in task tray displayed on the PC, and then click [Eject DMC-XXX]
(XXX varies by model).
•
Depending on your PC’s settings, this icon may not be displayed.•If the icon is not displayed, check that [Access] is not displayed on the LCD monitor of the digital
camera before removing the hardware.
∫ Connection in the PTP Mode
Set [USB Mode] to [PictBridge(PTP)].
•
Data can now be read only from this unit...

- 186 -
Connecting to other equipment
Saving still pictures and motion pictures on a
Recorder
If you insert a card holding content recorded with this unit into a Panasonic recorder, you can
dub the content to a Blu-ray Disc or DVD etc.
•
See the operating instruction for the recorder about the details of copying and playing back.•Note that the equipment described may not be available in certain countries and regions.
∫Dubbing with non-compatible equipment
You can dub the content played back using this...

- 187 -
Connecting to other equipment
2Start the playback of this unit.
3Start the recording on the recording equipment.
•When ending the recording (copying), stop the playback on this unit after stopping the
recording in recording equipment.
Note
•When you play back motion pictures on 4:3 aspect ratio TV, you must set [TV Aspect]  (P66) on this
unit to [4:3] before starting a copy. The image will be vertically long if you play back motion pictures
copied with [16:9] setting on a [4:3] aspect TV.
•See...

- 188 -
Connecting to other equipment
Printing the Pictures
If you connect the camera to a printer supporting PictBridge, you can select the pictures to be
printed out and instruct that printing be started on the camera’s LCD monitor.
•
Some printers can print directly from the card removed from the camera. For details, refer to the
operating instructions of your printer.
Preparations:
Turn on the camera and the printer.
Remove the card before printing the pictures in the built-in memory.
Perform the...

- 189 -
Connecting to other equipment
Note
•Use a battery with sufficient battery power or the AC adaptor (optional). If the remaining battery
power becomes low while the camera and the printer are connected, the status indicator blinks and
the alarm beeps. If this happens during printing, stop printing at once. If not printing, disconnect the
USB connection cable.
•Do not disconnect the USB connection cable while [ å] (Cable disconnect prohibit icon) is displayed.
(may not be displayed depending on...

- 190 -
Connecting to other equipment
Selecting a single picture and printing it
1Press 2/1 to select the picture and then press
[MENU/SET].
2Press 3 to select [Print start] and then press [MENU/
SET].
•Refer to  P191 for the items which can be set before starting to print
the pictures.
•Disconnect the USB connecti on cable after printing.
Selecting multiple pictures and printing them
1Press 3.
2Press 3/4 to select an item and then press [MENU/SET].
ItemDescription of settings
[Multi Select] Multiple...
