Panasonic Dmc Fz200 Owners Manual

- 201 -
Others
25 Aperture value (P31)
26 Program Shift (P32)
27 Metering Mode (P140)
28 AE lock  (P102)
29 Current date and time/ “: World Time (P55)
Number of days that have passed since the departure date  (P56)
Location  (P56)
Name  (P114)
Age  (P114)
Exposure meter  (P61)
30 Date Stamp  (P147)
31 Elapsed Recording Time  (P41):
¢
32 Built-in Memory  (P23)
: Card (P23)  (displayed only during recording)
33 Backlight Compensation (P37)
34 Recording Mode  (P30)
¢“h” is an abbreviation for hour, “m” for...

- 202 -
Others
∫In playback
1 Playback Mode  (P156)
2 Protected Picture  (P173)
3 Favorites  (P170)
4 Date/Text stamped display  (P147, 164)
5 Photo Style  (P133)
Color Mode  (P38)
6 After Auto Retouch  (P152)
After Creative Retouch  (P153)
7 Picture Size (P135)
8 Quality  (P137)
9 Battery Indication (P19)
10 Built-in Memory  (P23)
Elapsed playback time  (P47):
¢
11 Picture Number/Total Pictures
12 Folder/File Number (P184)
13 Histogram  (P60)
15 Location  (P56)
Recording information  (P70)
Name  (P114)...

- 203 -
Others
Cautions for Use
Keep this unit as far away as possible from electromagnetic equipment (such as
microwave ovens, TVs, video games etc.).
•
If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be disrupted by
electromagnetic wave radiation.
•Do not use this unit near cell phones because doing so may result in noise adversely affecting the
pictures and/or sound.
•Recorded data may be damaged, or pictures may be distorted, by strong magnetic fields...

- 204 -
Others
•Do not press the LCD monitor with excessive force. Uneven colors may appear on the LCD monitor
and it may malfunction.
•If the camera is cold when you turn it on, the picture on the LCD monitor/Viewfinder will be slightly
darker than usual at first. However, the picture will return to normal brightness when the internal
temperature of the camera increases.
•Do not press the lens with excessive force.•Do not leave the camera with the lens facing the sun as rays of light from the sun may...

- 205 -
Others
•The [CHARGE] indicator may blink under the influence of static electricity or electromagnetic wave.
This phenomenon have no effects on charging.
•If you use the battery charger near a radio, the radio reception may be disturbed.•Keep the charger 1 m (3.3 feet) or more away from radios.
•The charger may generate whirring sounds when it is being used. This is not a malfunction.•After use, be sure to disconnect the power supply  device from the electrical outlet. (A very small
amount of...

- 206 -
Others
If a name or birthday is set for [Baby1]/[Baby2]/Face Recognition function, this personal
information is kept in the camera and recorded in the image.
Disclaimer
•
Information including personal information may be altered or vanish due to erroneous operation,
effect of static electricity, accident, malfunction, repair, or other handlings.
Please note in advance that Panasonic is not liable in any way for any direct or indirect damage from
the alteration or vanishing of information or...

- 207 -
Others
Message Display
Confirmation messages or error messages will be displayed on the screen in some cases.
The major messages are described below as examples.
[This picture is protected]
>Delete the picture after canceling the protect setting.  (P173)
[This picture cannot be deleted]/[Some pictures cannot be deleted]
•
Pictures not based on the DCF standard cannot be deleted.
> If you want to delete some pictures, format the card after saving necessary data on a PC etc.
(P68)
[Cannot be set...

- 208 -
Others
[Memory card error.
This card cannot be used in this camera.
Format this card?]
•
It is a format that cannot be used with this unit.> Insert a different card.
> Format the card again with the camera after saving necessary data on a PC etc.  (P68) The data
on the card will be deleted.
[Please turn camera off and then on again]/[System Error]
•
This is displayed when the lens has stopped operating normally due to being pressed on by a hand
etc. > Turn the camera off and on. If the...

- 209 -
Others
[A folder cannot be created]
•
A folder cannot be created because there are no remaining folder numbers that can be used.> Format the card after saving necessary data on a PC etc.  (P68) If you execute [No.Reset] in the
[Setup] menu after formatting, the folder number is reset to 100.  (P64)
[Picture is displayed for 16:9 TV]/[Picture is displayed for 4:3 TV]
•
Select [TV Aspect] in the [Setup] menu if you want to change the TV aspect.  (P66)•This message also appears when the USB...

- 210 -
Others
Troubleshooting
First, try out the following procedures (P210 to 219) .
•
The battery is exhausted. Charge the battery.•If you leave the camera on , the battery will be exhausted.
> Turn the camera off frequently by using the [Economy] etc.  (P63)
•If you connect to a TV compatible with VIERA Link with a HDMI mini cable (optional) and turn the TV
off with the remote control for the TV, this unit is also turned off.
> If you are not using VIERA Link, set [VIERA Link] to [OFF].  (P66)...
