Panasonic Dmc Fz200 Owners Manual

- 191 -
Connecting to other equipment
Select and set the items both on the screen in step 2 of the “Selecting a single picture
and printing it” and in step
3 of the “Selecting multiple pictures and printing them”
procedures.
•
When you want to print pictures in a paper size or a layout which is not supported by the camera, set
[Paper Size] or [Page Layout] to [ {] and then set the paper size or the layout on the printer. (For
details, refer to the operating instructions of the printer.)
•When [Print...

- 192 -
Connecting to other equipment
•Paper sizes not supported by the printer will not be displayed.
[Paper Size]
ItemDescription of settings
{ Settings on the printer are prioritized.
[L/3.5 qk5q]
89 mmk127 mm
[2L/5 qk7q] 127 mmk178 mm
[POSTCARD] 100 mmk148 mm
[16:9] 101.6 mmk180.6 mm
[A4] 210 mmk297 mm
[A3] 297 mmk420 mm
[10 k15cm] 100 mmk150 mm
[4 qk6 q] 101.6 mmk152.4 mm
[8 qk10q ] 203.2 mmk254 mm
[LETTER] 216 mmk279.4 mm
[CARD SIZE] 54 mmk85.6 mm

- 193 -
Connecting to other equipment
•An item cannot be selected if the printer does not support the page layout.
∫Layout printing
When printing a picture several times on 1 sheet of paper
For example, if you want to print the same picture 4 times on 1 sheet of paper, set [Page
Layout] to [ ä] and then set [Num.of prints] to 4 for the picture that you want to print.
When printing different pictures on 1 sheet of paper
For example, if you want to print 4 different  pictures on 1 sheet of paper, set...

- 194 -
Others
Optional accessories
With the optional conversion lenses, you can record even more faraway pictures and take
close-up pictures of smaller subjects.
Preparations: Remove the lens cap and lens hood.
1Attach the lens adaptor.
•Rotate the lens adaptor slowly and carefully.
2Attach the tele conversion lens.ALens adaptor (optional)
B Tele conversion lens (DMW-LT55: optional)
•Close-up lens (DMW-LC55: optional) can be
attached in a similar manner.
3Select [Conversion] on the [Rec] menu. (P52)...

- 195 -
Others
Note
•Lens adaptor (optional) is needed to use the conversion lens.
•MC protector (DMW-LMC52: optional) or ND filters (DMW-LND52: optional) cannot be used together
with the conversion lens. Remove them before attaching the conversion lens.
•Do not use with anything other than DMW-LC55 or DMW-LT55.
•When there is dirt (water, oil, and fingerprints, etc.) on the surface of the lens, the image may be
affected. Lightly wipe the surface of the lens with a soft, dry cloth before and after...

- 196 -
Others
After attaching the external flash (DMW-FL220, DMW-FL360, DMW-FL500: optional), the
effective range will be increased when compared to the camera’s built in flash.
Preparations:
Turn off the camera and close the built-in flash.
∫Using the dedicated flash (DMW-FL220: optional)
1Attach the dedicated flash to the hot shoe and then turn on the camera and the
dedicated flash.
•
Be sure to firmly secure to the dedicated flash with the lock ring.
2Select [Flash] on the [Rec] menu.  (P52)
3Press...

- 197 -
Others
Note
•You can set the aperture value, the shutter speed and the ISO sensitivity on the camera even when
attaching the external flash.
•Some commercial external flashes have synchro terminals with high-voltage or reversed polarity.
Using such extra flashes may cause a malfunction or the camera may not operate normally.
•If you use commercially available external flashes with communication functions other than the
dedicated one, they may not operate normally or they may be damaged. Do not...

- 198 -
Others
If you use the remote shutter (DMW-RSL1: optional), you can avoid jitter (camera shake) when
using a tripod and you can keep the shutter pressed fully when taking pictures with Burst Mode.
The remote shutter works similar to the shutter button on the camera.
Note
•
Always use a genuine Panasonic remote shutter (DMW-RSL1: optional).•You cannot operate the camera with the remote shutter in the following cases.
–When the Sleep Mode is canceled–When starting/ending the recording of motion...

- 199 -
Others
The AC adaptor (optional) can only be used with the designated Panasonic DC coupler
(optional). The AC adaptor (optional) cannot be used by itself.
Preparations:
Turn this unit off and confirm that the lens barrel is retracted.
ACard/battery door
B DC coupler
C DC coupler cover
D AC adaptor
E AC cable
1Pull open the card/battery door and the DC coupler
cover.
2Insert the DC coupler into this unit.
•Insert by pushing the center of the DC coupler.
•Press on the DC coupler until it is...

- 200 -
Others
Screen Display
∫In recording
1 Custom Settings  (P127)
2 Photo Style  (P133)
Color Mode  (P38)
: Creative control adjustment display (P117)
3 Zoom Microphone (P151)
4 Flash Mode  (P75)
Flash output adjustment  (P145)
5 Recording Mode (for recording motion pictures)
(P148)
Recording quality  (P149)
6 Picture Size (P135)
7 Stabilizer Off  (P143)
: Jitter Alert (P29)
8 Quality  (P137)
9 AF Macro Mode  (P97)
10 AF Style  (P139)
: MF (P99)
: AF lock (P102)
11 AF Mode  (P92)
12 Burst  (P80)
:...
