Panasonic Dmc Fz200 Owners Manual

- 61 -
Basic
•Set to [ON] to display the [Expo.Meter] when correcting exposure,
performing Program Shift, setting aperture, and setting shutter speed.
•Unsuitable areas of the range are displayed in red.
•When [Expo.Meter] is not displayed, switch the display information for
screen by pressing [DISP.]. (P69)
•The [Expo.Meter] disappears after approximately 4 seconds if no operation is performed.
[Remaining Disp.]
This will switch display between the number of recordable pictures and
available...

- 62 -
Basic
•MF position will be memorized in the following cases:
–Turning the camera off–When switching to a type of focus other than Manual Focus–When switched to Playback Mode
•Zoom position will be set all the way to wide when the [Zoom Resume] is set to [OFF].•When [MF Resume] is set to [OFF], MF position will be the distance focused at the time of recording
in Manual Focus.
•Depending on the recording conditions, the memorized MF positions and resumed MF positions
might be different.
•Refer to...

- 63 -
Basic
•Press the shutter button halfway or turn the camera off and on to cancel [Sleep Mode].
•[Sleep Mode]  is set to  [5MIN.]  in the Intelligent Auto Mode.•Press any button to turn on the LCD monitor again.•[Sleep Mode] does not work in the following cases.
–When using the AC adaptor–When connecting to a PC or a printer–When recording or playing back motion pictures
–During a slide show–[Auto Demo]•[Auto LCD Off] does not work in the following cases.
–When using the AC adaptor–When connecting...

- 64 -
Basic
•[Auto Review] is activated regardless of its setting in the following cases.–When using Auto Bracket
–During the Burst Mode•The Auto Review function is fixed to [2 SEC.] in the following cases.–Intelligent Auto Mode
•[Auto Review] does not work when recording motion pictures.
•The folder number is updated and the file number starts from 0001.
•A folder number between 100 and 999 can be assigned.
When the folder number reaches 999, the number cannot be reset. We recommend formatting the...

- 65 -
Basic
•When the [Reset] setting is selected during recording, the operation that resets the lens is also
performed at the same time. You will hear the sound of the lens operating but this is normal and not
indicative of malfunctioning.
•When the Recording Mode settings are reset, data registered with [Face Recog.] will be also reset,
too.
•The folder number and the clock setting are not changed.•When [Setup] menu settings are reset, the following settings are also reset.
–The birthday and name...

- 66 -
Basic
•This will work when the HDMI mini cable (optional) is connected.•Refer to P178 for details.
•This will work when the HDMI mini cable (optional) is connected.•Refer to P180 for the method to playback 3D pictures in 3D.
[Output]
This sets how the unit connects to a television etc.
[TV Aspect]:
Set to match the type of TV.
W  [16:9]:
When connecting to a 16:9 screen TV.
X  [4:3]:
When connecting to a 4:3 screen TV.
•
This will work when the AV cabl e (optional) is connected.
[VIERA Link]
Set...

- 67 -
Basic
•Refer to P45 for information about how to play back pictures.
•When you play back pictures on a PC, they cannot be displayed in the rotated direction unless the
OS or software is compatible with Exif. Exif is a  file format for still pictures which allows recording
information, etc. to be added. It was established by “JEITA (Japan Electronics and Information
Technology Industries Association)”.
•It may not be possible to rotate pictures that have been recorded with other equipment.
•The...

- 68 -
Basic
•Use a battery with sufficient battery power or the AC adaptor (optional) when formatting. Do not turn
the camera off during formatting.
•If a card has been inserted, only the card is formatted. To format the built-in memory, remove the
card.
•If the card has been formatted on a PC or other equipment, format it on the camera again.•It may take longer to format the built-in memory than the card.
•If you cannot format, contact the dealer or Panasonic.
•If you set a different language by...

- 69 -
Recording
About the LCD Monitor/Viewfinder
Press [DISP.] to change.
•When the menu screen appears, the [DISP.] button is not
activated. During Playback Zoom, while playing back Motion
Pictures and during a Slide Show, you can only select E or G.
•You can select between [ ] (LCD monitor style) and [ ]
(viewfinder style) for each of the LCD monitor and the
Viewfinder display screen using [LCD Disp.Style] and [EVF Disp.Style] in the [Setup] menu.
¢ You can switch between available recording time...

- 70 -
Recording
¢1 If the [Histogram] in [Setup] menu is set to [ON], Histogram will be displayed.
¢ 2 Name of the registered person in [Face Recog.] is displayed when [DISP.] is pressed.
In Playback ModeE Normal display FDisplay with recording
information¢1G No display¢2
1/13
100-0001
(&
5HWRXFK
1/13
100-0001
(&
5HWRXFK100F2.8 30AWB
