Panasonic Dmc Fz200 Owners Manual

- 71 -
Recording
Taking Pictures with the Zoom
Applicable modes:
You can zoom in to make people and objects appear closer or zoom out to record landscapes
in wide angle.
Extended Optical Zoom works except when the maximum recordable pixels are set. This
function allows you to take a picture with additional enlargement without deteriorating the
image quality.
∫ Changing the zoom speed
The zoom speed becomes slower when the rotation
angle is small and the zoom speed becomes faster
when the rotation...

- 72 -
Recording
(DMC-FZ200)
∫Control the zoom with the side lever
Using the side lever to control the zoom when taking pictures
with the Viewfinder is useful fo r reducing shaking as the camera
can be kept stable.
Using the side lever can also increase techniques used for
taking pictures.
•
When controlling the zoom with the side lever, set [Side Lever] in
the [Setup] menu to [ZOOM].  (P57)
•You can operate the zoom at 2 speeds. The zoom speed becomes
slower when the sliding distance is small and...

- 73 -
Recording
∫Types of zooms
¢1 This includes the optical zoom magnification.  The magnification level differs depending on
[Picture Size] setting.
The zoom functions below can also be used  to further increase the zoom magnification.
¢22 k when [i.Resolution] in the [Rec] menu is set to [i. ZOOM].
∫ Screen display
•
When using the zoom function, an estimate of the focus range will appear in conjunction with
the zoom display bar. [Example: 0.3 m (0.98 ft.) – ¶]
FeatureOptical ZoomExtended Optical...

- 74 -
Recording
Note
•The indicated zoom magnification is an approximation.
•“EZ” is an abbreviation of “Extended Optical Zoom”. It is possible to take more magnified pictures
with the optical zoom.
•The lens barrel extends or retracts according to the zoom position. Take care not to interrupt the
motion of the lens barrel while the zoom lever is rotated.
•When you rotate the zoom lever, you may hear some sound from the camera or the camera may
shake. This is not a malfunction.
•When using the...

- 75 -
Recording
Taking Pictures using the Flash
Applicable modes:
∫To open/close the flash
Note
•
Be sure to close the flash when not in use.
•The flash setting is fixed to [ Œ] while the flash is closed.•Be careful not to catch a finger when closing a flash bulb.•Be sure to keep the flash clean, clear of dust and avoid exposure to anything sticky. This may cause
the flash to stick and not open.
•You cannot close the flash by pushing the microphone or its periphery. Forcibly closing the flash can...

- 76 -
Recording
Set the flash to match the recording.
•Open the flash.
1Select [Flash] in the [Rec] menu. (P52)
2Press 3/4 to select a mode and then press [MENU/SET].
•Exit the menu after it is set.
Switching to the appropriate flash setting
SettingsDescription of settings
‡ ([Auto]) The flash is automatically activated when the recording conditions
make it necessary.
([iAuto])
¢ 1
([Auto/
Red-Eye])¢2
The flash is automatically activated when the recording conditions
make it necessary.
It is activated...

- 77 -
Recording
∫Available flash settings in Recording Mode
The available flash settings depend on the Recording Mode.
(± : Available, —: Not available,  ¥: Scene Mode initial setting)
¢[ ] is displayed.
•The flash setting may change if the Recording Mode is changed. Set the flash setting again if
necessary.
•The flash setting is memorized even if the camera is turned off. However, the Scene Mode flash
setting is reset to the initial setting when the Scene Mode is changed.
•Flash will not be activated...

- 78 -
Recording
∫The available flash range
•The available flash range is an approximation.
¢ 1 When the [ISO Limit Set]  (P138) is set to [AUTO].
∫Shutter speed for each flash setting
¢2 When [Sensitivity] is set to [AUTO]. The shutter speed may vary depending on the [ISO Limit Set]
setting.
•In Intelligent Auto Mode, shutter speed changes depending on the identified scene.•In Scene Mode, the shutter speeds will differ from those described above.
Note
•When recording with the flash, white saturation...

- 79 -
Recording
Compensating the Exposure
Applicable modes:
Use this function when you cannot achieve appropriate exposure due to the difference in
brightness between the subject and the background.
Note
•
Set the value to [0] when you do not compensate the exposure.•The set exposure value is memorized even if the camera is turned off.•The compensation range of the exposure will be limited depending on the brightness of the subject.
1Press the rear dial to set Exposure
Compensation to a selected...

- 80 -
Recording
Taking Pictures Using Burst Mode
Applicable modes:
Pictures are taken continuously while the shutter button is pressed.
Burst speed can be selected to match the recording conditions or subjects.
1Press [ ˜].
2Press 2/ 1 to select the burst speed and then press
[MENU/SET].
•Description of recording conditions suitable for each burst speed is
displayed by pressing [DISP.].
OFF1240605 5
